3 - Description

Filters

An EasyClean suction filter is fitted in the working zone.
A Cyclone pressure filter is fitted to the sprayer's right side just in front of the ChemLocker. It has a built-in self-cleaning
function.
In-line pressure filters can be fitted at each boom section as an option.
All filters should always be in use and their function checked regularly. Pay attention to the correct combination of filter and
mesh size (see "Filters and nozzles" on page 106).

EasyClean Filter

To ensure proper function of filter and its built-in valve, the filter must be
opened at least once every month. A label on the lid also designates this.
• To open filter, turn it counterclockwise and pull it up as shown in
picture.
• Pull out the two locks (A) to remove filter element from the lid.
An EasyClean clogging indicator is located beside the spray pressure
gauge on the platform:
Clogging indicator color
Green indicator.
Yellow indicator.
Red indicator.
24
Filter status
No cleaning necessary.
It is possible to finish an ongoing spraying job and
then clean the filter afterwards.
Clean the EasyClean Filter immediately, as the filter is
clogged.
