8 - Technical specifications

Electrical Schematic for Boom and Work Lights (DTZ Booms)

LEFT
A Input from tractor to activate
B Sensor for work light
C Work light
D Cable to JobCom
E Boom lights
110
A
3 A
5 A
D
E E
B C
E E
RIGHT
E E
