8 - Technical specifications

Specifications

Diaphragm pumps

Pump model 364/5.5
Pump model 364/10.0
Pump model 464/6.5
Pump model 464/12.0

Centrifugal pumps

Pump model 150 - ACE 206 hydraulic
Output will vary with PSI and usage.
Pump model 200 - ACE 304 hydraulic
Output will vary with PSI and usage.
Pump model 650 - ACE 650 hydraulic
Output will vary with PSI and usage.

Filters and nozzles

Filter gauze width
30 mesh: 0.58 mm
50 mesh: 0.30 mm
80 mesh: 0.18 mm
100 mesh: 0.15 mm

Temperature and pressure ranges

Spray liquid:
Operating temperature range: 36° F to 104° F (2° to 40° C)
Operating pressure for safety valve: 220 psi (15 bar)
Max. pressure on the pressure manifold: 290 psi (20 bar)
Max. pressure on the suction manifold: 22 psi (1.5 bar)
Hydraulics:
Operating temperature range: 36° F to 176° F (2° to 80° C)
Max. operating pressure:
Tractor: 3046 psi (210 bar)
106
PSI RPM
0 1000
220 1000
PSI RPM
0 540
220 540
PSI RPM
0 1000
220 1000
PSI RPM
0 540
220 540
GPM HP
51.2 4.2
47.6 7.8
GPM HP
51.2 2.4
47.0 8.3
GPM HP
92.2 4.3
78.7 13.8
GPM HP
88.2 3.0
81.9 13.0
