- Page 1 Manual WAGO-TO-PASS® 761 Telecontrol Module Compact, 2 AI 761-111 Telecontrol module for fault detection/indication, monitoring and remote control Version 2.0.0...
- Page 2 WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI © 2013 by WAGO Kontakttechnik GmbH & Co. KG All rights reserved. WAGO Kontakttechnik GmbH & Co. KG Hansastraße 27 D-32423 Minden Phone: +49 (0) 571/8 87 – 0 Fax: +49 (0) 571/8 87 – 1 69 E-Mail: info@wago.com...
-
Page 3: Table Of Contents
Shielding ..................... 21 3.4.4.1 General ................... 21 3.4.4.2 Bus Lines ..................21 3.4.4.3 Signal Lines ................... 21 3.4.4.4 WAGO Shield Connecting System ..........22 3.4.5 Digital Inputs ..................23 3.4.6 Counter Inputs ..................24 3.4.7 Analog Inputs ..................25 3.4.8 Digital Outputs ................... - Page 4 Table of Contents WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 3.6.6 Counter Inputs ..................31 3.6.7 Analog Inputs ..................31 3.6.8 Digital Outputs ................... 32 Approvals ....................33 Standards and Guidelines ................ 33 Mounting ..................... 34 ® Mounting the TO-PASS telecontrol module to the DIN rail ....
- Page 5 WAGO-TO-PASS® 761 Table of Contents 761-111 Telecontrol Module Compact, 2 AI 8.2.1 Telecontrol via SMS ................78 8.2.1.1 Setting or Resetting a Digital Output ..........78 8.2.1.2 Changing the Counter Value or Status .......... 79 ® 8.2.2 Telecontrol with the TO-PASS Operator Program ......
-
Page 6: Notes About This Documentation
Manual by third parties that violate pertinent copyright provisions is prohibited. Reproduction, translation, electronic and phototechnical filing/archiving (e.g., photocopying) as well as any amendments require the written consent of WAGO Kontakttechnik GmbH & Co. KG, Minden, Germany. Non-observance will involve the right to assert damage claims. Manual... -
Page 7: Symbols
WAGO-TO-PASS® 761 Notes about this Documentation 761-111 Telecontrol Module Compact, 2 AI Symbols Personal Injury! Indicates a high-risk, imminently hazardous situation which, if not avoided, will result in death or serious injury. Personal Injury Caused by Electric Current! Indicates a high-risk, imminently hazardous situation which, if not avoided, will result in death or serious injury. - Page 8 Notes about this Documentation WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Additional Information: Refers to additional information which is not an integral part of this documentation (e.g., the Internet). Manual Version 2.0.0...
-
Page 9: Number Notation
WAGO-TO-PASS® 761 Notes about this Documentation 761-111 Telecontrol Module Compact, 2 AI Number Notation Table 1: Number notation Number code Example Note Decimal Normal notation Hexadecimal 0x64 C notation Binary '100' In quotation marks, nibble separated with '0110.0100' dots (.) -
Page 10: Important Notes
2.1.1 Subject to Changes WAGO Kontakttechnik GmbH & Co. KG reserves the right to provide for any alterations or modifications that serve to increase the efficiency of technical progress. WAGO Kontakttechnik GmbH & Co. KG owns all rights arising from the granting of patents or from the legal protection of utility patents. -
Page 11: Disclaimer
GPL. According to Section 3b of GPL, we offer you the source code. You can obtain the source code with licensing terms of the Open Source software from WAGO Kontakttechnik GmbH & Co. KG on request. Send your request to support@wago.com with the subject "Open Source TO-PASS Compact". -
Page 12: Safety Advice (Precautions)
Important Notes WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Safety Advice (Precautions) For installing and operating purposes of the relevant device to your system the following safety precautions shall be observed: Do not work on components while energized! All power sources to the device shall be switched off prior to performing any installation, repair or maintenance work. - Page 13 WAGO-TO-PASS® 761 Important Notes 761-111 Telecontrol Module Compact, 2 AI Please note the following information about FCC Part 15! FCC Part 15.19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1. this device may not cause harmful interference, and 2.
- Page 14 Important Notes WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Protect the components against materials having seeping and insulating properties! The components are not resistant to materials having seeping and insulating properties such as: aerosols, silicones and triglycerides (found in some hand creams).
-
Page 15: Device Description
Please note that one SIM card is required to operate each TO-PASS telecontrol module and may be obtained from typical service providers such as T-Mobile, VODAFONE or EPlus. WAGO Kontakttechnik GmbH & Co. K.G. is prepared to assist with the selection of the most cost-effective tariff for your application. ®... -
Page 16: Table 3: Overview Of Functions
Device Description WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Table 3: Overview of functions Functionality FW 2.20 FW 2.31 FW 2.32 FW 2.33 Module name length 8 characters*) 16 characters*) 16 characters*) 16 characters*) (Identity) “Prepaid” request Always active... -
Page 17: View
WAGO-TO-PASS® 761 Device Description 761-111 Telecontrol Module Compact, 2 AI View Figure 1: Front view Position Description SIM Card insert Antenna connection Statusindication PC interface Connecting terminals for the supply, inputs and outputs Manual Version 2.0.0... -
Page 18: Connectors
Device Description WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Connectors 3.4.1 Antenna The screw connector (SMA socket) for the GSM antenna is located at the top of the housing. Figure 2: Antenna connection Observe the maximum length of the antenna cable! -
Page 19: Operating Voltage
WAGO-TO-PASS® 761 Device Description 761-111 Telecontrol Module Compact, 2 AI 3.4.2 Operating Voltage Use SELV/PELV power source only! ® The TO-PASS telecontrol module must only be powered from a PELV (Protective Extra Low Voltage) or SELV (Safety Extra Low Voltage) power source complying with the limited power source (LPS) requirements per DIN EN 60950-1. -
Page 20: Grounding
The separate grounding of the carrier rail can be easily set up with the aid of the WAGO ground wire terminals. Table 5: WAGO ground wire terminals Item No. Description 283-609 1-conductor ground (earth) terminal block make an automatic contact to the carrier rail;... -
Page 21: Shielding
Higher shielding performance is achieved via low-impedance connection between shield and ground. To achieve this, connect the shield over a large surface area, e.g., WAGO shield connecting system. This is especially recommended for large- scale systems where equalizing current or high impulse-type currents caused by atmospheric discharge may occur. -
Page 22: Wago Shield Connecting System
3.4.4.4 WAGO Shield Connecting System The WAGO shield connecting system consists of shield clamping saddles, busbars and various mounting carriers to enable a wide variety of setups. For more information on this, refer to the "Accessories" section of the main catalog. -
Page 23: Digital Inputs
WAGO-TO-PASS® 761 Device Description 761-111 Telecontrol Module Compact, 2 AI 3.4.5 Digital Inputs Only connect SELV/PELV voltages! Only SELV/PELV voltages shall be connected to the device terminals. Table 6: Terminal assignment for digital inputs Figure 5: Terminal assignment for digital inputs... -
Page 24: Counter Inputs
Device Description WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 3.4.6 Counter Inputs Only connect SELV/PELV voltages! Only SELV/PELV voltages shall be connected to the device terminals. Digital inputs D1 … D4 can be configured as counter inputs. Table 7: Counter input pin assignments... -
Page 25: Analog Inputs
WAGO-TO-PASS® 761 Device Description 761-111 Telecontrol Module Compact, 2 AI 3.4.7 Analog Inputs Only connect SELV/PELV voltages! Only SELV/PELV voltages shall be connected to the device terminals. Table 8: Terminal assignment for analog inputs Figure 7: Terminal assignment for analog inputs... - Page 26 Device Description WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Analog inputs are single-ended! The analog inputs are single-ended and the “Aix–” connections are connected internally to the “GND” connections. Connect shielding! Shielded cables are required for analog inputs. The cable shield must be connected to the grounded DIN rail (see section "Connections"...
-
Page 27: Digital Outputs
WAGO-TO-PASS® 761 Device Description 761-111 Telecontrol Module Compact, 2 AI 3.4.8 Digital Outputs Only connect SELV/PELV voltages! Only SELV/PELV voltages shall be connected to the device terminals. Table 9: Terminal assignment for digital outputs Figure 8: Terminal assignment for digital outputs... -
Page 28: Serial Interface To Pc
Device Description WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 3.4.9 Serial Interface to PC Table 10: Serial interface to the PC Description Not assigned Not assigned Not assigned Not assigned Figure 9: Serial interface to the PC Not assigned... -
Page 29: Display Elements
WAGO-TO-PASS® 761 Device Description 761-111 Telecontrol Module Compact, 2 AI Display Elements Table 12: Display Elements Busy Description Green 0.5 Hz Ready to operate blinking Communication via RS232 Green interface Green 1 Hz Firmware update blinking GSM modem is activated Initialization (takes approx. -
Page 30: Technical Data
-40 °C ... +85 °C Type of mounting DIN 35 rail Degree of protection IP 20 Wire connection Terminal strips (WAGO 250 Series) with push-wire connection Cross section 0,5 mm² … 1,0 mm² AWG 22 … AWG 14 „sol“ Stripped length 9 mm …... -
Page 31: Gsm Communication
WAGO-TO-PASS® 761 Device Description 761-111 Telecontrol Module Compact, 2 AI 3.6.4 GSM Communication Table 16: Technical Data GSM Communication Number of recipients Recipient types PC, SMS, e-mail, phone, fax Communication GSM quad-band Communication types SMS (bidirectional), telecommunication dial-up connection (CSD) 3.6.5... -
Page 32: Digital Outputs
Device Description WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 3.6.8 Digital Outputs Table 20: Technical Data Digital Outputs Number of outputs Output type Semiconductor outputs Output current 0.5 A/30 V DC, short-circuit protected Type of load Resistive, inductive, lamps Energy dissipation W 125 mJ;... -
Page 33: Approvals
WAGO-TO-PASS® 761 Device Description 761-111 Telecontrol Module Compact, 2 AI Approvals The following approvals have been granted to 761-111 telecontrol modules: Conformity Marking UL508 R&TTE Complaint with 1999/5/EG directive (per Article 3.2) RoHS Device complies with European RoHS directive. Verification per FCC 15b... -
Page 34: Mounting
IP20 degree of protection ® The protection class of the TO-PASS telecontrol module is IP 20. For this reason, WAGO Kontakttechnik GmbH & Co. KG recommends mounting in a housing or in a switching cabinet. Ambient temperature -20 °C to +70 °C ®... -
Page 35: Removing The To-Pass ® Telecontrol Module From The Din Rail
WAGO-TO-PASS® 761 Mounting 761-111 Telecontrol Module Compact, 2 AI ® Removing the TO-PASS telecontrol module from the DIN rail ® Figure 12: Removing the TO-PASS telecontrol module from the DIN rail ® Press the undersurface against the lower DIN rail edge until the TO-PASS telecontrol module is no longer locked in place. -
Page 36: Connect Devices
If more than one conductor must be routed to one connection, these must be connected in an up-circuit wiring assembly, for example using WAGO feed- through terminals. Terminate both solid and ferruled conductors without actuation by simply pushing them in. -
Page 37: Connection Examples
WAGO-TO-PASS® 761 Connect Devices 761-111 Telecontrol Module Compact, 2 AI Connection Examples Connect the shield connection to the DIN rail! ® The shield connection of the TO-PASS telecontrol module (shield, terminal 38) must be connected to the DIN rail. The DIN rail must have a low-impedance ground (see section "Connections"... -
Page 38: Counter Inputs
Connect Devices WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 5.2.2 Counter Inputs Only connect SELV/PELV voltages! Only SELV/PELV voltages shall be connected to the device terminals. Connect shielding! Shielded cables are recommended for the counter inputs. When using shielded cables, the shield must be routed to the grounded DIN rail (see Section "Connections"... -
Page 39: Analog Inputs
WAGO-TO-PASS® 761 Connect Devices 761-111 Telecontrol Module Compact, 2 AI 5.2.3 Analog Inputs Only connect SELV/PELV voltages! Only SELV/PELV voltages shall be connected to the device terminals. Analog inputs are single-ended! The analog inputs are single-ended and the “Aix–” connections are connected internally to the “GND”... -
Page 40: Voltage Measurement
® since the internal resistance of the TO-PASS telecontrol module depends on the input current. WAGO 857 Series JUMPFLEX Isolation Amplifiers for level conversion may be ® used for voltage measurement via TO-PASS telecontrol modules. Figure 16: Connection example for voltage measurement via U/I converter at input AI1 Manual Version 2.0.0... -
Page 41: Digital Outputs
WAGO-TO-PASS® 761 Connect Devices 761-111 Telecontrol Module Compact, 2 AI 5.2.4 Digital Outputs Only connect SELV/PELV voltages! Only SELV/PELV voltages shall be connected to the device terminals. Figure 17: Connection example for a relay at DO1 output Manual Version 2.0.0... -
Page 42: Commissioning
Select the CD drive in which you have placed the CD with the operating software. Start the "WAGO TO-PASS_SETUP(2.17).EXE" program, or a newer version in the main directory on the CD. Follow the menu prompting to choose a default installation path. -
Page 43: Starting The To-Pass Telecontrol Module
WAGO-TO-PASS® 761 Commissioning 761-111 Telecontrol Module Compact, 2 AI ® Starting the TO-PASS Telecontrol Module Do not switch on yet! ® Do not switch on the TO-PASS telecontrol module until you are prompted to do so; do not insert the SIM card for this procedure. - Page 44 Commissioning WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI When generating a new configuration file, select the firmware version for the device that implements the required functionality as the first version in the Function selection field. The device versions, along with the associated enabling firmware indices are displayed to make selection easier.
-
Page 45: Parameterizing
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Parameterizing General Settings Select the menu item File Settings for making general settings, such as type of > ® connection, interface or language for the TO-PASS operating interface. Figure 18: General settings... - Page 46 Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Table 21: General settings Interface COM1 ... COMx Here, select the serial interface where the communication cable is connected with a RS-232 connection. Language ® English / Select the langauge for the TO-PASS operator interface here.
-
Page 47: Reading Parameters From The Module
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Reading Parameters from the Module ® After you have set the type of connection for communicating with the TO-PASS telecontrol module, you are then able to read out the parameters of the connected module. -
Page 48: Identity
Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Identity ® Select the TO-PASS telecontrol module to be configured from the project tree; under it, select the Identity option. On the right side you will find the selection field for the function, the display field for the name, the input field for the telephone number, buttons and input fields for the PIN, roaming and prepaid and the input field for the alarm counter. -
Page 49: Table 22: Configuring The Identity
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Table 22: Configuring the identity General Function selection You can redifine the firmware version in this selection field, that is to say the available scope of functions (e.g., to ensure compatibility with devices already in use). -
Page 50: Addresses
Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Addresses ® The TO-PASS telecontrol module can communicate with a maximum of four ® transmitters/receivers via GSM. Messages are sent by the TO-PASS telecontrol module as SMS; however, they can also be sent as an e-mail, fax or voice mail, as defined in configuration. -
Page 51: Table 23: Configuring The Addresses
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Table 23: Configuring the addresses Phone/Fax/Mail Address 1 ... Enter the target addresses in these fields: Address 4 Transmission as SMS: Enter the mobile phone number of the recipient. Click the button [T2T] when the SMS recipient is also a TO- ®... - Page 52 In this field enter the port for the Web portal (e.g., "80" for most http applications) Script (value), In this field enter the script name for data transmission, for for transmitting test purposes, e.g., "wago/saveTO-PASS.php". alarms and status The "saveTO-PASS.php" script checks the version messages indications from transmitted data and forwards this information to the processing script.
-
Page 53: Configuring Inputs And Outputs
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Configuring Inputs and Outputs 7.5.1 Digital Inputs ® Select your TO-PASS telecontrol module from the left side of the project tree using the identifier. Select the input to be configured under Digital Inputs. -
Page 54: Figure 22: Configuring Digital Inputs 5
Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Figure 22: Configuring digital inputs 5 … 8 (when provided) Table 24: Configuring of digital inputs Counters (only for digital inputs 1 … 4) Counters Check this box to use the selected digital input as a counter input. - Page 55 WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Table 24: Configuring of digital inputs Alarm settings First value Check this box to have a message sent when the first limit is exceeded for upward counting or when the first lower limit is violated for downward counting.
- Page 56 Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Table 24: Configuring of digital inputs Deactivation text In this field enter the text to be contained in the message transmitted when the digital input has been reset, or when the counted value has violated the second limit.
-
Page 57: Multiplex Input
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI 7.5.2 Multiplex Input You can configure digital inputs DI1 ... DI4 as multiplex inputs. These four inputs will then additionally be read in as a combination and intepreted as a binary number. -
Page 58: Multiplex Settings
Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 7.5.2.1 Multiplex Settings ® Select your TO-PASS telecontrol module from the left side of the project tree using the identifier. Select the Multiplex Settings option under Multiplex Input. The buttons for enabling multiplex operation and the selection of the recipients of the analog values to be transmitted are provided on the right side. -
Page 59: Multiplex Alarm Text
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI 7.5.2.2 Multiplex Alarm Text ® Select your TO-PASS telecontrol module from the left side of the project tree using the identifier. Select the Multiplex Table option under the Multiplex Input entry. The input fields for the alarm texts pertaining to the 16 statuses are provided on the right side. -
Page 60: Analog Inputs
Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 7.5.3 Analog Inputs ® Select your TO-PASS telecontrol module from the left side of the project tree using the identifier. Select the input to be configured under Analog Inputs. The parameters of the input are given on the right side. - Page 61 WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Table 27: Configuring the analog inputs Alarm settings First value In this field enter the first limit for which a message is to be sent when this limit is violated (upper/lower limit) (see below).
-
Page 62: Digital Outputs
Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 7.5.4 Digital Outputs ® Select your TO-PASS telecontrol module from the left side of the project tree using the identifier. Select the output to be configured under the entry Digital Outputs. -
Page 63: Configuring Error Detectors
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Configuring Error Detectors ® The TO-PASS telecontrol module can transmit error messages to a maximum of four recipients. The recipients are informed either directly one after another or (if configured) after expiration of the time delay for acknowledgment. The message ®... - Page 64 Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI [4]. Click the [Internet] button to also transmit the message to a Web portal. In addition, you can also specify the analog values that are to be transmitted along with the error message.
-
Page 65: Acknowledgement
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI 7.6.4 Acknowledgement Acknowledgment is the confirmation that a message has actually been sent to the ® recipient. Select the TO-PASS telecontrol module from the project tree using the identifier. Select the entry Acknowledgment under the option Special Functions. -
Page 66: Transmission Repeat Times
Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Transmission Repeat Times ® Select the TO-PASS telecontrol module from the project tree using the identifier. Select the entry Repeat times under the option Special Functions. The input fields for the Web interval, the Web outputs and the SMS interval and buttons for target addresses are located on the right side. -
Page 67: Table 30: Configuring The Transmission Repeat Times
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Table 30: Configuring the transmission repeat times Web settings Web interval In this field enter the cycle time in minutes to define the ® intervals that the TO-PASS telecontrol module is to send data to the Internet. - Page 68 Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Table 30: Configuring the transmission repeat times SMS Settings SMS interval Here, enter the cycle time in minutes to define the intervals ® that the TO-PASS telecontrol module is to send data to the addresses defined under Address.
-
Page 69: Time Adjustment
WAGO-TO-PASS® 761 Parameterizing 761-111 Telecontrol Module Compact, 2 AI Time Adjustment ® Select the TO-PASS telecontrol module from the project tree using the identifier. Select the entry Acknowledgment under the option Time setting. The buttons for various settings pertaining to time adjustment are located on the right side. -
Page 70: Writing Parameters To The Module
Parameterizing WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Writing Parameters to the Module ® After you have adapted all parameters for the TO-PASS telecontrol module to your requirements, you have to write the parameters to the connected module. Select the menu option Edit > Write Parameters. The software then writes all ®... -
Page 71: Operation
WAGO-TO-PASS® 761 Operation 761-111 Telecontrol Module Compact, 2 AI Operation Remote Query of Process Values ® The TO-PASS telecontrol module offers two options for remote inquiry of the process values available: • Query via SMS ® • Query with the TO-PASS... -
Page 72: Remote Polling Via Sms
Operation WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 8.1.1 Remote Polling via SMS For remote polling via SMS, send an SMS containing the text "State" to the TO- ® PASS telecontrol module. ® The TO-PASS telecontrol module responds promptly with an SMS to your mobile phone containing all of the current process values. -
Page 73: Table 34: Counter Status
WAGO-TO-PASS® 761 Operation 761-111 Telecontrol Module Compact, 2 AI Table 34: Counter status Status Explanation Digital input not configured as a counter. e:ZW Counter is active: Counter value. d:ZW Counter is not active: Counter value. o:ZW Counter overflow: Counter vlaue. -
Page 74: Remote Polling Using The To-Pass
Operation WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI ® 8.1.2 Remote Polling using the TO-PASS Operating Program ® To display the process values with the TO-PASS operator program, select the menu item Visualization > Process values. The program establishes a link to the ®... -
Page 75: Inputs/Outputs
WAGO-TO-PASS® 761 Operation 761-111 Telecontrol Module Compact, 2 AI 8.1.2.1 Inputs/Outputs Press the [I/O] button to display the process values of the inputs and outputs. The process values displayed are valid if the on-line display is green. Figure 30: Visualization of the process values... -
Page 76: Counters
Operation WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 8.1.2.2 Counters To display the counter process values, click the [Counter] button (possible only when inputs have been configured as counters). The process values displayed are valid when the on-line indicator is highlighted in green. -
Page 77: Telecontrol
WAGO-TO-PASS® 761 Operation 761-111 Telecontrol Module Compact, 2 AI Telecontrol ® TO-PASS telecontrol modules offer the option of influencing a process remotely with the help of their analog and digital outputs. There are two methods available: • Telecontrol via SMS ®... -
Page 78: Telecontrol Via Sms
Operation WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 8.2.1 Telecontrol via SMS 8.2.1.1 Setting or Resetting a Digital Output To set or reset a digital output, send an SMS with the text that is entered under ® Activation text or Deactivation text for the output to the TO-PASS telecontrol ®... -
Page 79: Changing The Counter Value Or Status
WAGO-TO-PASS® 761 Operation 761-111 Telecontrol Module Compact, 2 AI 8.2.1.2 Changing the Counter Value or Status To change the value or the status of a counter, send an SMS containing the text "Counter" and the corresponding control commands (more than one can be sent) ®... -
Page 80: Telecontrol With The To-Pass
Operation WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI ® 8.2.2 Telecontrol with the TO-PASS Operator Program ® To display the process values with the TO-PASS operator program, select the menu item Visualization > Process values. The program establishes a link to the ®... -
Page 81: Inputs/Outputs
WAGO-TO-PASS® 761 Operation 761-111 Telecontrol Module Compact, 2 AI 8.2.2.1 Inputs/Outputs Press the [I/O] button to display the process values of the inputs and outputs. The process values displayed are valid if the on-line display is green. Figure 32: Visualization of the process values... -
Page 82: Counters
Operation WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI 8.2.2.2 Counters To display the counter process values, click the [Counter] button (possible only when inputs have been configured as counters). The process values displayed are valid when the on-line indicator is highlighted in green. -
Page 83: Acknowledging Error Messages
WAGO-TO-PASS® 761 Operation 761-111 Telecontrol Module Compact, 2 AI Acknowledging Error Messages If a waiting time not equal to 0 has been set for the acknowledgment of error ® messages, the TO-PASS telecontrol modules expects an acknowledgment of error messages from the recipient. -
Page 84: Switching To Standby
Operation WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Switching to Standby Standby authorization Switching standby on and off is only possible by subscribers whose telephone number has been entered in the address list! Using the "Standby" function, it is optional to change all messages sent by the ®... -
Page 85: Diagnostics
WAGO-TO-PASS® 761 Diagnostics 761-111 Telecontrol Module Compact, 2 AI Diagnostics Test Inputs and Outputs To test the inputs and outputs select the menu option Controller > Test I/O. The following window is displayed: Figure 34: Test inputs and outputs The process values of the inputs are displayed in the upper area and the process values of the outputs are displayed in the lower area. -
Page 86: Testing The Counter Inputs
Diagnostics WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Testing the Counter Inputs To test the counter inputs, select the menu item Edit > Test counters. Figure 35: Testing counters The counter statuses are shown at the top of the window, while the counter values, the starting and end values and the limits are shown at the bottom. -
Page 87: Testing The Connection
WAGO-TO-PASS® 761 Diagnostics 761-111 Telecontrol Module Compact, 2 AI Testing the Connection Direct serial link required ® The connection may only be tested with a direct serial link to the TO-PASS telecontrol module. To test the connection, select the menu option Edit > Test SMS/GPRS. The... -
Page 88: Testing The Modem
Diagnostics WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Testing the Modem Direct serial link required ® The modem test may only be performed with a direct serial link to the TO-PASS telecontrol module. To test the mode, select the menu item Modem > Test. -
Page 89: List Of Figures
Figure 2: Antenna connection ................18 Figure 3: Terminal assignment for operating voltage ........... 19 Figure 4: Example of the WAGO shield connecting system ........ 22 Figure 5: Terminal assignment for digital inputs ..........23 Figure 6: Counter input pin assignments ............... 24 Figure 7: Terminal assignment for analog inputs .......... -
Page 90: List Of Tables
Table 3: Overview of functions ................16 Table 4: Terminal assignment for operating voltage ..........19 Table 5: WAGO ground wire terminals ..............20 Table 6: Terminal assignment for digital inputs ........... 23 Table 7: Counter input pin assignments ..............24 Table 8: Terminal assignment for analog inputs ........... - Page 91 WAGO-TO-PASS® 761 761-111 Telecontrol Module Compact, 2 AI Manual Version 2.0.0...
