Ethernet Interface
6.7.1.2
Filter type
It is recommended, to use averaging for statical measuring or slowly changing measuring values. An avera-
ging reduces noise or suppresses distortions in measuring values.
6.7.1.3
Filter
6.7.2
This menu item determines the trigger behavior. The triggering is released by an external electrical signal, see
Chap.
If the trigger mode is turned off, the capaNCDT 6222 will send the measuring values without interruption and
with the adjusted data rate.
Grey shaded
fields require a

Trigger mode

selection.
Dark-bordered
fields require
Value
you to specifie
a value.
capaNCDT 6222

Filter type / Averaging

No Averaging
Moving average
Arithmetic mean
Median
Dynamic noise rejection

Analog Low Pass Filter

active / inactive
Trigger Mode
Menu Settings > Measurement settings > Trigger
4.7.2 or by the command $ GMD, see Chap. 6.4.3.
Rising edge
Level high
Rising edge (gate) Starts resp. stops the measuring value output alternatively.
No trigger
Value
Filter width 2 / 3 /
Value
4 / 5 / 6 / 7 / 8
Value
Switches the deep pass filter with 20 Hz limit frequency on analog output
A measuring value is output per edge.
Level triggering. Measuring value output, as long as the level is active.
Controller sends measuring values continuously.
Designation of averaging type.
Averaging number indicates,
about how many current measu-
ring values should be averaged
in the controller, before a new
measuring value is output.
Page 77
