Fetco CBS-2051e User Manual

Coffee brewing systems
Hide thumbs Also See for CBS-2051e:
Table of Contents

Advertisement

Quick Links

See also: Programming Instructions , Operating Instructions
www.fetco.com
Models:
CBS-2051
CBS-2052
Contact Information ................................................ 2
Description & Features ........................................... 2
Specifications.......................................................... 2
Requirements...................................................... 2
Weights and Capacities ...................................... 2
Dimensions & Utility Connections........................... 4
Installation............................................................... 5
Operating Instructions ............................................ 8
Programming .......................................................... 9
Batch Settings ..................................................... 9
Temperature Settings ....................................... 10
FETCO®, LUXUS®, and EXTRACTOR™ are trademarks or trade names of Food Equipment Technologies Company.
© 2002 Food Equipment Technologies Company
NOTICE TO INSTALLER: This book contains important
programming instructions that will be needed by the
customer. Please leave it with the manager or
responsible person at the machine location.

Table of Contents

User's Guide
Relay Test ......................................................... 11
Error Codes .......................................................... 12
Service.................................................................. 13
Cleaning & Maintenance ...................................... 13
Wiring Diagram..................................................... 15
Parts - Brewer ...................................................... 16
Parts - LUXUS Dispensers ................................... 23
LUXUS LS & LD Series .................................... 23
LUXUS TPD-1.5................................................ 23
Part # P013
Revised July 15, 2002

Advertisement

Table of Contents
loading

Related Manuals for Fetco CBS-2051e

Summary of Contents for Fetco CBS-2051e

  • Page 1: Table Of Contents

    Programming ... 9 Batch Settings ... 9 Temperature Settings ... 10 FETCO®, LUXUS®, and EXTRACTOR™ are trademarks or trade names of Food Equipment Technologies Company. © 2002 Food Equipment Technologies Company User’s Guide customer. Please leave it with the manager or responsible person at the machine location.

  • Page 2: Contact Information

    Brew basket safety locks Brew temperature protection Universal wiring – single or three phase Specifications Electrical: See electrical configuration chart. Coffee Filters: 15” X 5 ½ ” FETCO Product # F001 Weight Dispenser (filled) Weight, ea. 46 lbs.

  • Page 3: Electrical Configuration And Brewing Efficiency

    Electrical Configuration and Brewing Efficiency US & Canada CBS-2051 Electrical Heater Config. Code Configuration E51016 2 X 3 KW CBS-2052 Electrical Heater Config. Code Configuration E52016 Option 1 Universal 2 X 3 KW (Factory Setting) Wiring Option 2 Total 3 X 3 KW Heaters 3 X 3 KW E52026...

  • Page 4: Dimensions & Utility Connections

    Dimensions & Utility Connections CBS-2051 CBS-2052...

  • Page 5: Installation

    Here are the key points to consider before installation: Electrical: All FETCO brewers require NEUTRAL. Ground is not an acceptable substitute. Installation without neutral may cause damage to the electronic components. Universal wiring: This brewer can be configured for single or three phase operation. Conversion instructions are described later in this section.
  • Page 6 Electrical Connection 1. Verify that the actual voltage at the electrical service connection is compatible with the specifications on the brewer’s serial number label. Make sure the electrical service includes neutral. 2. The temperature and water tank fill level are pre-set at the factory. There is no need to turn off the heaters during the installation process.
  • Page 7 Final Setup 1. Turn on the incoming water supply line and inspect both inside and outside of the brewer for leaks in all fittings and tubes 2. Turn on the incoming power. 3. Press the brewer’s main power switch, which is hidden behind the front leg of the brewer.

  • Page 8: Operating Instructions

    Control Panel Functions Only switches that are active are illuminated. Switches that are inactive or disabled are invisible. Main Power Switch Controls all power to brewer Indicator lamp at top of panel. Control Panel On/Off Switch Secondary power switch. Does not disconnect main power.

  • Page 9: Programming

    Batch Settings Turn the brewer off by pressing the main power switch. Press the main power switch again to turn the unit on. Quickly hold the STOP button for 3 seconds. The display will show the software version for 3 seconds. Example: Batches are numbered 1 –...

  • Page 10: Temperature Settings

    Temperature Settings Parameter Name Water Temp. (°F) Hot Water Service Brew at Set Temperature Parameter Name Enter Advanced Settings & Diagnostics Important! To save your changes, press Advanced Settings and Diagnostics Address Description Water Level in Tank Water Resistance Brew Basket Sensor State (left / right) Power Relay State...

  • Page 11: Relay Test

    Address Description Left Brew Valve Flow Rate Right Brew Valve Flow Rate Left Bypass Valve Flow Rate Right Bypass Valve Flow Rate Keypad Test Relay Test Press to save the settings and exit Diagnostic mode. Press again to exit Programming mode and return to Operating mode. Relay Test Tests the individual relays which control various components.

  • Page 12: Error Codes

    Code Description Possible Cause Internal Error Control board System had to failure. reload default settings. Power Failure Relay on control Power state does board has failed. not match feedback loop state. Shorted Probe failure. temperature probe. Open temperature Bad probe probe.

  • Page 13: Service

    45 seconds. Utilize only qualified beverage equipment service technicians for service. A Service Company Directory may be found on our web site, http://www.fetco.com. Companies listed as “Extractor Authorized” stock parts for these models. When changing the control board, check the software version on the chip. Example- V1.40. If the chip on the replacement board has an older software version than the board being replaced, carefully remove the chip from the old board and place it in the new board.
  • Page 14 Care of Stainless Steel (These procedures were developed by NAFEM and Packer Engineering.) 1. Use the proper tools. When cleaning your stainless steel products, take care to use non-abrasive tools. Soft cloths and plastic scouring pads will not harm the steels passive layer. Stainless steel pads can also be used but the scrubbing motion must be in the direction of the manufacturers polishing marks.

  • Page 15: Wiring Diagram

    Wiring Diagram CBS-2052 (CBS-2051 wiring diagram not availabel at time of publication)

  • Page 16: Parts - Brewer

    CBS-2051 Main assembly and tank assembly drawings were not available at time of publication. Spray housing assembly – see figure 3. Brew basket assembly – see figure 4. CBS-2051 Major Components: PART NO DESCRIPTION 51023 CONTROL BOARD, 2000 SERIES 51026 INPUT BOARD, 2051 54022 TEMPERATURE PROBE ASSY, 8”...
  • Page 17 Figure 1 – CBS-2052 FIG. # 3 FIG. # 4 SEE FIG. # 2 Drawing for CBS-2051 was not available at time of publication.
  • Page 18 Parts List – Figure 1 – CBS-2052 ITEM PART NO. DESCRIPTION 22037 CBS-2052 TANK INSULATION- BACK 22036 CBS-2052 TANK INSULATION-FRONT 102013 TANK COVER ASSY 24002 TANK COVER GASKET 102134 WATER LEVEL PROBE ASSY., 2.6" 104016 CBS-2052 TANK ASSEMBLY (SEE FIGURE 2) 25042 VENT SILICONE TUBE 32049 S.S.
  • Page 19 101165 BREW BASKET ASSY. (SEE FIGURE 4) 46011 BREW BASKET WARNING LABEL 46028 INSTRUCTION LABEL 46029 MAIN POWER SWITCH LABEL 44019 SINGLE PHASE CONFIGURATION LABEL 44020 THREE PHASE CONFIGURATION LABEL For current parts pricing, visit www.fetco.com. (COIL, DIAPHRAGM, SPRING, & PLUNGER)
  • Page 20 Figure 2 – Tank Assembly – CBS-2052 ITEM PART NO. DESCRIPTION 31129 3/8'' X 1/4'' MPT CONNECTOR 31117 1/4'' LOCKNUT 31116 1/8'' LOCKNUT 31005 1/4'' HOSE X 1/8''MPT 90 DEG HOSE BARB ELBOW 31151 1/2'' LOCKNUT 31118 3/8'' LOCKNUT 83043 FLAT WASHER I.D. .688 X O.D. 1.125 31077 3/8'' BARB X 3/8'' MPT 83048 .835 I.D.
  • Page 21 57075 COIL ASSY. REPAIR KIT, DSV-10, 240 VAC (EXPORT VERSION ONLY) 57072 VALVE REBUILD KIT, DSV10 102113 SPRAY HOUSING ASSY. 24035 O-RING, 5.5 I.D. X 5 11/16 O.D. X 3/32 102108 SPRAY PLATE ASSY., 5 7/8" DIA. For current parts pricing, visit www.fetco.com.
  • Page 22 Figure 4 – Brew Basket Assembly, 16” X 6”, Part # 101165 For current parts pricing, visit www.fetco.com. ITEM SHOWN PART # DESCRIPTION 82096 HANDLE SCREW 23117 BREW BASKET HANDLE 9006 WIRE INSERT, 16 X 6 F001 PAPER FILTERS, 15” X 5.5”...

  • Page 23: Parts - Luxus Dispensers

    10-5/16" (plastic) 71038 sight gauge tube 10-5/16" (glass) 82015 faucet shank screw-2 required 101038 twist lock cover assembly 101052 brew funnel assembly 23024 plastic bottom 41011 LUXUS label For current parts pricing, visit www.fetco.com. Parts - LUXUS Dispensers...
