For a main digital monitor
If your main monitor uses digital input through a single-link DVI connector (such as Barco digital
ISIS and similar monitors) or a dual-link DVI connector (such as 30-inch Apple Cinema HD Display
monitors), you can use a standard DVI cable. This cable should be provided with your monitor.
Connect your main monitor
1
Connect your main monitor directly to the
main connector (
card.
Connect your secondary
2
analog monitor (optional)
Connect your analog computer monitor to
the secondary connector (
graphics card.
If your monitor cable has a DVI connector,
connect it directly to the secondary
connector of your Matrox graphics card.
Note:
connector as your secondary monitor,
make sure it supports analog input. For
more information, see your monitor
documentation.
If your monitor cable has an HD-15 connector, use the DVI-to-HD15 adapter included with
your Matrox product to connect your monitor to the secondary connector.
Make sure the connectors are firmly in place. Your Matrox card is now installed. Restart your
computer and install your Matrox software
8 Matrox ATC – User Guide
) of your Matrox graphics
A
) of your Matrox
B
To use a monitor with a DVI
(see "Software setup", page
Monitor cable (DVI)
Monitor cable
(DVI)
DVI-to-HD15
adapter
Monitor cable (HD-15)
9).
