Introduction
1.2 Description
•
•
•
•
•
Universal Power Supply Options
•
•
•
•
•
1.2

Description

The RUGGEDCOM RSG2300F features various ports, controls and indicator LEDs on
the display panel for connecting, configuring and troubleshooting the device. The
display panel can be located on the rear, front or top of the device, depending on the
mounting configuration.
1
2
3
4
5
6
7
8
Figure 1.1
Communication Ports
Port Status Indicator LEDs
2
Zero-Packet-Loss™ technology
-40 to 85 °C (-40 to 185 °F) operating temperature (no fans)
Conformal coated printed circuit boards (optional)
18 AWG galvanized steel enclosure
Hazardous Location Certification: Class 1 Division 2
Fully integrated, dual-redundant (optional) power supplies
Universal high-voltage range: 88-300 VDC or 85-264 VAC
Popular low voltage ranges: 24 VDC (12-36 VDC), 48 VDC (36-59 VDC)
Screw or pluggable terminal blocks for reliable, maintenance-free connections
CSA/UL 62368-1 safety approved to 85 °C (185 °F)
1
Fiber or Copper Ethernet Ports
Copper Ethernet Port
Port Status Indicator LEDs
Mode Button
RS-232 Serial Console Port (RJ45)
Display Mode Indicator LEDs
Alarm Indicator LED
Power Module Indicator LEDs
RUGGEDCOM RSG2300F
2
Ports for communicating with other devices or accessing the
RUGGEDCOM RSG2300F operating system are described in
"Communication Ports (Page
Port status indicator LEDs indicate the operational status of each
port, dependent on the currently selected mode.
6
3 4 5
23)".
RUGGEDCOM RSG2300F
Installation Manual, 04/2021, C79000-G8976-1347-09
