5.7
Mechanical Specifications
Weight
Ingress Protection
Enclosure
5.8
Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
Note
Dimensional tolerances are in accordance with ISO 2768-mK, unless otherwise
stated.
Figure 5.1
RUGGEDCOM RSG2300F
Installation Manual, 04/2021, C79000-G8976-1347-09
5.2 kg (11.5 lbs)
IP30
18 AWG Galvanized Steel
Overall Dimensions
5.7 Mechanical Specifications
438.15
Technical Specifications
35
