3.1.14 VSWR
3.1.14.1 Input
3.1.14.2 Output
3.1.15 Prime Power
3.1.16 Serial Interface
3.1.16.1 RS-232
3.1.16.2 RS-422/485 (2 or 4-Wire Mode)
3.1.17 Controls
This specification describes the control functions of the HPA. Many control functions can be applied
locally from the front panel of the HPA as well as remotely via the serial interface. Some of the control
functions can only be applied via the local controls on the HPA. The following paragraphs specify these
control functions and the LOCAL/REMOTE capability. Details of the communication protocol for serial
control and the menu system for the local control are detailed in the operation and installation manual for
this HPA product. Please refer to that document for detailed information.
3.1.17.1 Controls, Local
3.1.17.1.1
3.1.17.1.2
3.1.17.1.3
3.1.17.2 Controls, Local & Remote
3.1.17.2.1
3.1.17.2.2
3.1.17.2.3
3.1.17.2.4
3.1.17.2.5
3.1.17.2.6
3.1.17.2.8
3.1.17.2.10
3.1.17.2.11
3.1.17.2.12
Note: Heater Standby reduces the TWT's heater voltage for situations where the high voltage is
off. Using this mode significantly increases the life of the TWT where high voltage is off
for extended periods of time.
T HI S DOCUME NT I S T HE P ROP E RT Y OF XI COM T E CHNOLOGY. RE P RODUCT I ON OR RE LE AS E WI T HOUT E XP RE S S P E RMI S S I ON I S S T RI CT LY P ROHI BI T E D.
XTD-750C, 5.85-6.425 GHz, R01
Document No. 305-0389-201
EAR EXPORT CONTROLLED: The information contained in this Manual refers or relates to a product that is subject
to the U.S. Export Administration Regulations (EAR). Transfer of data herein by any means to a Foreign Person,
whether in the U.S. or abroad, may require an export license from the U.S. Department of Commerce.
Function
AC Prime Power
Local/Remote
HV ON/OFF
HV (ON/OFF)
Heater Standby (ON/OFF)
Gain
Minimum Power Alarm/Fault
Maximum Power Alarm/Fault
Power Measurement Units (Watts, dBm, dBw)
Fault Reset
COM 1 configuration (baud rate, parity, start/stop bits)
COM 2 configuration (baud rate, parity, start/stop bits)
HPA Address
1.6:1 max
1.3:1 max
180-260 VAC
2450 VA max
0.95 Power factor min
47 to 63 Hertz
Single Phase
COM1
COM2
