Monitoring via the Web Browser
15.2 Controls
Use the following rules to operate the NetGuardian ENV's control:
1. Select Controls from the Monitor menu.
2. Under the State field, you can see the current condition of the control.
3. To issue the control, click on a command (OPR - operate, RLS - release, or MOM - momentary)
4. If a Derived Description is assigned to a control ID, the command buttons for that control ID will be
disabled.
ID
Description
State
Command
NetGuardian ENV
View and operate control relays from the Monitor > Controls menu
ID number for the control relay.
Description for the NetGuardian ENV's control relay defined in the Provisioning >
Controls menu.
Status of the control relay. Can either be Released or Latched.
OPR - Latch the relay.
RLS - Release the relay.
MOM - Momentarily latch the relay, then automatically release the relay. The duration
the latch is defined in the Provisioning > Controls menu.
Control Relay Operation
