Reference Section
Display
Display 18
Display
Display 19
Display
Display 20
NetGuardian ENV
2 Digital sensor 21 Minor Over
3 Digital sensor 21 Major Under
4 Digital sensor 21 Major Over
5 Digital sensor 21 Sensor not detected
9-16 Control
17-32 Value
33 Digital sensor 22 Minor Under
34 Digital sensor 22 Minor Over
35 Digital sensor 22 Major Under
36 Digital sensor 22 Major Over
37 Digital sensor 22 Sensor not detected
41-48 Control
49-64 Value
Point Description
1 Digital sensor 23 Minor Under
2 Digital sensor 23 Minor Over
3 Digital sensor 23 Major Under
4 Digital sensor 23 Major Over
5 Digital sensor 23 Sensor not detected
9-16 Control
17-32 Value
33 Digital sensor 24 Minor Under
34 Digital sensor 24 Minor Over
35 Digital sensor 24 Major Under
36 Digital sensor 24 Major Over
37 Digital sensor 24 Sensor not detected
41-48 Control
49-64 Value
Point Description
1 Digital sensor 25 Minor Under
2 Digital sensor 25 Minor Over
3 Digital sensor 25 Major Under
4 Digital sensor 25 Major Over
5 Digital sensor 25 Sensor not detected
9-16 Control
17-32 Value
33 Digital sensor 26 Minor Under
34 Digital sensor 26 Minor Over
35 Digital sensor 26 Major Under
36 Digital sensor 26 Major Over
37 Digital sensor 26 Sensor not detected
41-48 Control
49-64 Value
Point Description
1 Digital sensor 27 Minor Under
2 Digital sensor 27 Minor Over
3 Digital sensor 27 Major Under
4 Digital sensor 27 Major Over
5 Digital sensor 27 Sensor not detected
9-16 Control
17-32 Value
33 Digital sensor 28 Minor Under
34 Digital sensor 28 Minor Over
