3.1 BASIC Mode
Level function
Click on the g sensor icon on the top-right of the screen to check
the level status of the optical sensor.
Reset button
17
Calibration button
Shows the angle of
inclination of the X
and Y axes
Back to
measurement page

3.2 SPECTRUM Mode

Click "SPECTRUM" icon in main menu to display spectrum in
range of 350~800nm.
Indicate peak wavelength
in range of 350∼800nm.
The strongest energy value
in range of 350∼800nm.
18
