Register online to extend your warranty an additional 12 months and to
receive one free calibration after your 1st year of use. (freight excluded)
上網登錄主機序號可延長主機保固12個月並享有第一年免費一次校正服務
(不含運費)
Webサイトに登録後、ホストのシリアル番号がある場合、12ヶ月保証
延長になります。初年度内に一回無料校正サービス(運賃を除く)をご
利用いただけます。
Registration Web Page :
登 錄 註 冊 網 址 :
登 録 W e b サ イ ト :
* To ensure your warranty validation, please place your agent's stamp in the box and fill in the
purchase date. If the agent stamp and purchase date cannot be supplied, the warranty period
will based on the manufacturing date of the product.
* 為確保您的權益,請要求經銷商蓋上店章及填寫購買日期;未蓋店章與購買日期者,則以出廠日期為依據。
* お客様の権利を確保するために、販売店に店の印章または、購入日を記入することを依頼してください。
販売店の印章または購入日のない場合、製造日に基とづいて取り扱いいたします。
Original / Authorized Agent Stamp
TEL : +886-37-580885
FAX : +886-37-580398
Address : No.38, Keyi St., Zhunan Township, Miaoli County 35059, Taiwan
www.uprtek.com/english/Register_00.asp
www.uprtek.com/big5/Register_00.asp
www.uprtek.com/english/RegisterJP_00.asp
Product Serial Number
Purchase
Date
52-72-00005-0100
Website : www.uprtek.com
MK350D
LED Me ter
LED 光譜計
The information contained herein is the exclusive property and confidential document of United Power
Research Technology Corporation, and shall not be distributed, reproduced,or disclosed in whole or in
part without prior written permission of United Power Research Technology Corporation.
User Manual and Warranty
使 用 說 明 書 與 保 固 手 冊
使 用 說 明 書 び 保 証 書
LEDメーター

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MK350D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for UPRtek MK350D

  • Page 1 The information contained herein is the exclusive property and confidential document of United Power TEL : +886-37-580885 FAX : +886-37-580398 Website : www.uprtek.com Research Technology Corporation, and shall not be distributed, reproduced,or disclosed in whole or in Address : No.38, Keyi St., Zhunan Township, Miaoli County 35059, Taiwan...
  • Page 2: Table Of Contents

    Contents ........Introduction ............ 1.1 Features ......... 1.2 Package Contents ........1.3 Product Description ......1.4 Annual Product Calibration ......1.5 Product Notes and Precautions ......... Getting Started ..........2.1 Product Setup ........2.2 Taking a Measurement Introduction ........2.3 Product Registration ....
  • Page 3: Features

    1.1 Features 1.2 Package Contentsns The MK350D is a lightweight, portable, easy-to-operate LED meter with Micro SDCard data storage. This product has basic features for fast, easy Light Measurements. ■ Records over 27 light unit-of-measures; Basic List items (CCT, RA, CIE1976 , CIE1931, LUX, FC, LambdaP, R9, Flicker);...
  • Page 4: Product Description

    1.3 Product Description 1.4 Annual Product Calibration This product is a high-precision measurement device with sensor cover sensitive components – please handle with care. To ensure sensor the accuracy of measurements, it is recommended to have the unit calibrated once a year. Please contact your agent or micro SD card slot our customer service department for calibration service.
  • Page 5: Product Notes And Precautions

    1.5 Product Notes and Precautions The MK350D LED Meter contains sensitive components. Please unpack with care, as any trauma to the unit may damage the equipment. Contact your agent if the unit appears not to be operating normally. Do not attempt any repairs –...
  • Page 6: Product Setup

    Charger cable to measurement. Note that some of the references to buttons the MK350D and the other end into a wall socket with the and lights are described in the Product Description section.
  • Page 7: Taking A Measurement

    – Dark Calibration usually takes about 10-11 seconds. Then turn on the MK350D by Slide the Sensor Cover so that pressing the On/Off button on the Sensor is visible again. the side of the unit.
  • Page 8 1. While your unit is charging, you can start taking measurements with the power adaptor plugged in or you can wait until the unit is fully charged. 2. To turn off the MK350D, press the On / Off button and keep it depressed for at least 3 seconds.
  • Page 9: Product Registration

    At this point, please register your product at our website to ensure maximum warranty and service benefits. When you initially turn on the MK350D, it will display the Optic number (OPT:). Write down the Optic number and, using a PC, access http://www.uprtek.com/english/RegisterPL_PC_00.asp ,...
  • Page 10: Microsd Card

    files (.xls). Even without a MicroSD Card, the connection to uSPECTRUM MK350D is able to capture data and keep the current measurement in memory. You can review the SD Card data by accessing it through a PC by using the USB cable provided in the packaging. After cable connection, the SD Card will display on your PC as a new drive letter.
  • Page 11: More About Dark Calibration

    Calibration is not performed. It is good practice to perform a dark calibration every time you turn on the MK350D, when you move to a different temperature environment (hot to cold or cold to hot), or when you move to a different light intensity environment (light to dark or dark to light).
  • Page 12: Tripod Attachment

    If you detach the lanyard screw on the bottom of the If for any reason you need to perform a system reset, you can MK350D, it will expose a screw hole where you can attach a use a pointer to press into the Reset Hole as shown right.
  • Page 13: Uspectrum Pc/Smart Device Apps

    To obtain the uSPECTRUM software, you must go to www.uprtek.com. connection to uSPECTRUM Specifications connection to Smart Device APPs The MK350D can also be remote controlled by an Apple IOS or Android smart device, using a Bluetooth connection. - 22 - - 23 -...
  • Page 14 Sensor CMOS linear image sensor Wavelength Data Increment 1 nm Spectral Bandwidth Approximately 12 nm(half bandwidth) Wavelength Reproducibility ± 1 nm Receptor Size Ø 6.6 ± 0.1 mm ( Input source must be a stable light source. ) Cosine Correction refer Figure 1.
  • Page 15: Warranty

    Figure 1:Cosine Correction MK350S Ideal Value Warranty - 26 - - 27 -...
  • Page 16 For products considered as “Dead on Arrival”, we will replace it ■ UPRtek shall in no event be liable for any defect, damage or data loss that with a new product (in whole package) at no charge and pay return and has occurred during the delivery of in-warranty products.
  • Page 17 Customers can return the product directly to the UPRtek factory for servicing. 2. Accessories : UPRtek RMA policy is only for LED Meter repair and does not cover Rules on Product Repairs After The Warranty Period maintenance or calibration services (aside from one time free calibration on UPRtek provides product services after warranty expiration at reasonable extended warranty).
  • Page 18: Warning Statement

    7.1 NCC Warning Statement Article 12 Without permission, any company, firm or user shall not alter the frequency, increase the power, or change the characteristics and functions of the original design of the certified lower power frequency electric machinery. Article 14 The application of low power frequency electric machineries shall not affect the navigation safety nor interfere a legal communication, if an interference is found, the service will be suspended until...
  • Page 19: Fcc Warning Statement

    7.2 FCC Warning Statement 7.2 FCC Warning Statement a. for FCC 15b devices (15.105) (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference This equipment has been tested and found to comply with the limits that may cause undesired operation.
