Cyber Power CPSPV7000ETL User Manual page 57

Protection Class
Relative humidity
Features
DC connection
AC connection
Display
RS232/RS485
Warranty: 5/10 years
Certificates
Input (DC)
Max. DC power
Max. input voltage
MPP voltage range /
Rated input voltage
Min. input voltage /
initial input voltage
Max. input current
Number of MPP input /
strings per MPP input
Output (AC)
Rated AC power
Max apparent AC
power
Max. output current
Nominal AC voltage
Rated frequency
Cos phi
Feed-in phases
Efficiency
Max efficiency
Euro-eta
MPPT efficiency
User Manual
0...95 % (non-condensing)
H4/MC4(opt)
Screw terminal
LCD
yes/yes
yes /opt
VDE 0126-1-1, VDE 0126-1-1/A1, PEA Thailand, VFR 2014
EN61000-6-2 / EN61000-6-3 / EN61000-3-2 /
EN61000-3-3 / EN61000-3-11 / EN61000-3-12
CPSPV- CPSPV-
10000ETL 12000ETL
10800 W 12960 W
1000 V 1000 V
400...800 V / 400...800 V /
600 V 600 V
300/350 V 300/350 V
15/15 A 17/17 A
2 / 2 2 / 2
10000 W 12000 W
10000 VA 12000 VA
16.0 A 19.0 A
3/N/PE, 220/380 V, 230/400 V, 240/415 V
0.8 over-excited ... 0.8 under-excited
98 % 98 %
97.5 % 97.5 %
99.5 % 99.5 %
56 / 61
IP65
H4/MC4(opt) H4/MC4(opt)
Screw terminal Screw terminal
LCD
yes/yes
yes /opt
CE, IEC 62109
CPSPV-
18000ETL
19440 W
1000 V
400...800 V /
600 V
300/350 V
23/23 A
2 / 3
18000 W
18000 VA
28.6 A
50 Hz, 60 Hz
3
98 %
97.5 %
99.5 %
LCD
yes/yes
yes /opt
CPSPV-
20000ETL
21600 W
1000 V
400...800 V /
600 V
300/350 V
26/26 A
2 / 3
20000 W
20000 VA
32.0 A
98 %
97.5 %
99.5 %
CPS Mini Central series
