- Page 1 Solar Hybrid Inverter CPS1200EOH12SC CPS2200EOH24SC CPS3000EOH24SC User’s Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1 IMPORTANT SAFETY INSTRUCTIONS…………………………..3 2 INSTALLATION……..………………………………………………..4 2-1 Unpacking………………………………………………………....4 2-2 Product Overview & Outlook…………………………………………..4 2-3 Power Requirements of Your Equipment…...………………………..6 2-4 Hardware Installation Guide……..…………………………………….6 3 DEFINITIONS FOR ILLUMINATED LCD INDICATORS…...9 4 OPERATION & CONFIGURATION……………………………….10 Power On/Off..……………………………………………………………...10 View LCD Information…………...………………………………………...10 Audible Alarm On/Off…………………….…...………………....11 PV / Utility Priority…………..……..……………………………………….11 Charger Control…………………….…...……………………....11... -
Page 3: Important Safety Instructions
1 IMPORTANT SAFETY INSTRUCTIONS (SAFE THESE INSTRUCTIONS) Before attempting to unpack, install, or operate the product, please read and follow all instructions carefully. CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor area free of conductive contaminants. -
Page 4: Installation
2 INSTALLATION 2-1 Unpacking Inspect the product upon receipt. The box should contain the following: (a) This product; (b) User Manual; (c) Input Power Cord (except for CPS3000EOH24SC) CPS1200EOH12SC CPS3000EOH24SC User Manual CPS2200EOH24SC Input Power Cord (except for CPS3000EOH24SC) 2-2 Product Overview & Outlook CyberPower Solar Hybrid Inverter converts renewable solar energy from panels into usable AC and store excess power in batteries as backup power during blackout and emergencies. - Page 5 CPS1200EOH12SC / CPS2200EOH24SC CPS3000EOH24SC Application Diagram...
-
Page 6: Power Requirements Of Your Equipment
2-3 Power Requirements of Your Equipment Ensure that the equipment plugged into the AC outlet does not exceed the product’s rated capacity (1200VA/720W for CPS1200EOH12SC; 2200VA/1320W for CPS2200EOH24SC; 3000VA/1800W for CPS3000EOH24SC). If rated unit capacities are exceeded, an overload condition may occur and cause the unit to shut down or the circuit breaker trip. - Page 7 CAUTION! To reduce risk of injury, use appropriate cables for PV connection. The wiring can only be performed by trained personnel. Refer to below table for recommended cable size. Model PV Charging Current Wire Gauge CPS1200EOH12SC 12AWG CPS2200EOH24SC 12AWG CPS3000EOH24SC...
- Page 8 Connect the cables from PV module to the unit’s PV input terminals. Please check the polarity before connection. For more information about PV Module Selection, please refer to the APPENDIX section. Step 3 Connect the Product to Utility Connect the product to a wall outlet. Charging the battery for at least 8 hours is recommended to ensure that the battery’s maximum charge capacity is achieved.
-
Page 9: Definitions For Illuminated Lcd Indicators
3 DEFINITIONS FOR ILLUMINATED LCD INDICATORS LCD Display Icon Description This meter measures the AC input voltage that the unit is receiving from the utility wall outlet. In the event of a complete power loss, severe INPUT VOLTAGE brownout or over-voltage, the unit will rely on its external battery to supply consistent 230V output voltage. -
Page 10: Operation & Configuration
4 OPERATION & CONFIGURATION Power On/Off Power On： Press the POWER button to turn on the unit. Power Off： Press the POWER button again to turn off the unit. View LCD Information Short press the DISPLAY button to view the information about the unit. Display Pages LCD Readout Normal Mode (When the power button is pressed.) -
Page 11: Audible Alarm On/Off
CAUTION! The setting should be performed by trained personnel. Incorrect operation will damage the battery. Default: The charging voltage is 13.7V for CPS1200EOH12SC and 27.4V for CPS2200EOH24SC/CPS3000EOH24SC. Customized (for poor battery condition): The charging voltage is 13.3V for CPS1200EOH12SC and 26.6V for CPS2200EOH24SC/CPS3000EOH24SC. -
Page 12: Troubleshooting
5 TROUBLESHOOTING Problem Possible Cause Solution The unit is not connected to an The unit must be connected to a AC wall outlet. 220/230V outlet. The product will not turn on. The battery is worn out. Replace the batteries. Mechanical problem. Contact CyberPower Systems. - Page 13 Fault Code Table Fault Code Event Audible Alarm Overload Rapid beeping every 1/2 second PV Voltage High Beep every second Battery Low Beep every 2 seconds PV Current High Beep every second Output Voltage High Constant tone Output Short Constant tone Overload Fault Constant tone Fan Fail...
-
Page 14: Technical Specifications
6 TECHNICAL SPECIFICATIONS Model CPS1200EOH12SC CPS2200EOH24SC CPS3000EOH24SC Power Rating (VA/Watt) 1200VA/720W 2200VA/1320W 3000VA/1800W Input Narrow Mode: 170 - 280Vac Input Voltage Range Wide Mode: 90 - 280Vac Input Frequency 50/60Hz (Auto-sensing) Output Output Voltage 230Vac Output Frequency 50/60Hz Outlet Type... -
Page 15: Appendix Pv Module Selection
If one PV module cannot meet this requirement, connect multiple PV modules in series to increase the total voltage. Example for CPS1200EOH12SC After considering Voc of PV module not exceeds 40VDC and Max. Vmp within 15~18VDC, we can choose PV module with below specification. - Page 16 CAUTION! Ensure that Open Circuit Voltage (Voc) of PV modules not exceeds 40V for CPS1200EOH12SC and 55V for CPS2200/3000EOH24SC, or else the inverter may be damaged. If PV voltage or current is out of normal range, the unit will stop solar charging and send a warning...
