Summary of Contents for Cyber Power CPSHB300ETR-IN

  • Page 1 User’s Manual CPSHB300ETR-IN Cyber Power Systems, Inc. www.cyberpower.com...
  • Page 3: Table Of Contents

    Contents 1 Information on this Manual ......................1 1.1 Validity ............................1 1.2 Target Group ..........................1 1.3 Symbols Used ..........................1 2 Safety ..............................2 2.1 Intended Use ..........................2 2.2 Safety Precautions ........................2 2.3 Assembly Warnings ........................3 2.4 Electrical Connection Warnings ....................
  • Page 4 9 Decommissioning ..........................23 9.1 Dismantling the Unit ......................... 23 9.2 Packing the Unit ........................23 9.3 Disposing of the Unit ......................... 23 10 Specification ............................ 24 10.1 Specification of CPSHB300ETR-IN ................... 24 10.2 Torque Values .......................... 25 11 Contacts ............................26...
  • Page 5 Table of Figures Fig. 2-1 Energy storage system ....................... 2 Fig. 3-1 Layout of CPSHB300ETR-IN ....................5 Fig. 3-2 Dimensions of CPSHB300ETR-IN ..................5 Fig. 4-1 Components included in the scope of deliver ..............7 Fig. 5-1 Permitted and prohibited installation positions ............... 9 Fig.
  • Page 6 Table of Figures Table 6-1 Charge current setting ....................15 Table 6-2 LEDs indicators for On Grid operation ................ 16 Table 6-3 LEDs indicators for Off Grid operation................ 17 Table 10-1 Specification ....................... 24 Table 10-2 Torque values ......................25...
  • Page 7: Information On This Manual

    This installation guide contains installation, commissioning, basic troubleshooting and tech-support contact information regarding CyberPower’s CPS Solar Hybrid Power Generating System CPSHB300ETR-IN Using this guide, users will be able to install and operate the unit rather easily. This manual does not cover any details regarding equipment connected to the unit.
  • Page 8: Safety

    The CPS hybrid series is designed and tested according to international safety requirements; however, certain safety precautions must be observed when installing and operating this unit. Read and follow all instructions, cautions and warnings in this installation manual. User Manual Hybrid CPSHB300ETR-IN...
  • Page 9: Assembly Warnings

    Leftover energy may be fed into the public grid. If you choose this function and indeed there is left-over power fed into CAUTION the public grid, depending on your connection, the energy consumption meter might be spinning backwards! User Manual Hybrid CPSHB300ETR-IN...
  • Page 10: Operation Warnings

    Observe the documentation Observe all documentation supplied with product Danger to life due to high voltage Prior to performing any work on the product, always disconnect it from all sources and wait for 5 minutes. User Manual Hybrid CPSHB300ETR-IN...
  • Page 11: Product Description

    AC-out Power Outlet AC-in Power Outlet / GRID Tool for Removing PV Connectors 3.2 Size and Weight The dimensions of CPSHB300ETR-IN as Fig. 3-2, the weight is 9kg includes batteries. Unit: mm Fig. 3-2 Dimensions of CPSHB300ETR-IN User Manual Hybrid CPSHB300ETR-IN...
  • Page 12: Transportation

     After long term storage, local installer or service department of CyberPower should perform a comprehensive test before installation 3.5 The Advantage of CPS Solar Hybrid Power Generating Systems Features of CPSHB300ETR-IN are follows: User friendly handle, making carrying very convenient ...
  • Page 13: Unpacking

    Item Quantity Description Solar Hybrid Power Generating System Power cord for AC connection User manual & Warranty Card Even though packaging is made to be durable, please treat it gently and Information avoid tossing it around. User Manual Hybrid CPSHB300ETR-IN...
  • Page 14: Installation

    The ambient temperature of the unit should be -10℃~+50℃. The installation location must be freely and safely to get at all times. Vertically installation only. Never install in horizontal positions, and avoid forward and sideways tilting; (observe drawings below) User Manual Hybrid CPSHB300ETR-IN...
  • Page 15: Electrical Connections

    Hazardous voltage High voltages which may cause electric shocks are present in the WARNING conductive parts of the unit. Prior to performing any work on the unit, disconnect the unit on the AC and DC sides User Manual Hybrid CPSHB300ETR-IN...
  • Page 16: Wiring Pv Input

    The diagram drawing of DC side is shown as below, notice that the connectors are in pair (male and female connectors). Note: Please use 14-10AWG(2-6mm ) wires for the PV input connection. Check the DC connectors for correct polarity and connect them onto the unit. Fig. 5-3 Connect PV connectors to unit User Manual Hybrid CPSHB300ETR-IN...
  • Page 17: Wiring External Battery Input

    Tight connector screws after you insert battery-wires to lock them into place. An AWG14 wire type is recommended. Place the battery connector back to the unit and tight it into place. Fig. 5-4 Location of extended battery connector User Manual Hybrid CPSHB300ETR-IN...
  • Page 18: Wiring Ac Output

    2. Plug-in the load power cord if needed. Note: Please use the accessorial power cord. Electrical socket or... (Different area has different plug type) To loads (appliances) Fig. 5-5 Grid output and standalone output connections User Manual Hybrid CPSHB300ETR-IN...
  • Page 19: Commissioning

    In this mode, whenever the PV or Battery has sufficient power, the unit convers PV and/or battery power to loads when Grid power is no available. Fault Mode The internal intelligent unit can continuously monitor and adjust the system state. If unit finds any fault conditions, unit would shutdown immediately User Manual Hybrid CPSHB300ETR-IN...
  • Page 20: Charge Current Setting

    Note: It is not able to enter setting mode if user don’t release the button within 4s when all LEDs are orange, must release the button and redo the procedures. Now, user can change the charge current by pressing button (refer to Table 6-1 for the setting). User Manual Hybrid CPSHB300ETR-IN...
  • Page 21 When the charge current setting is changed to what user wants.  Press and hold the button  3s later, unit confirms the setting and exit setting mode, jump to Sleep mode and all LEDs off.  When all LEDs are Green, release the button immediately.  Unit goes back to normal operation. User Manual Hybrid CPSHB300ETR-IN...
  • Page 22: Leds Indicators

    50% and under Orange with Operating charging<24.5Vdc and ≧ slowly Green Green 23Vdc and charging flashing  Operating normally with battery <25% and under Red with charging Slowly flashing  Operating normally with failed or no battery User Manual Hybrid CPSHB300ETR-IN...
  • Page 23 Countdown and self-test for Green Orange Countdown the status of Off Grid operation   battery Green Flash  Discharging Before shutdown, unit    Inner discharges inner Bus capacitor Orange with Capacitor around 10s. fast flashing User Manual Hybrid CPSHB300ETR-IN...
  • Page 24 <22V if Pout <30W (*A) -> Color: depend on the remaining capacity. (*B) -> Flashing frequency: charging is slow, discharging is fast. (*C) -> If Off-Grid operation transfers from On-Grid mode and Grid is abnormal. User Manual Hybrid CPSHB300ETR-IN...
  • Page 25: Start-Up And Shut-Down The Unit

    2. Turn on the DC switch or connect PV connectors, press and hold the button of unit until Off-Grid LED is green (release the button immediately when that LED is green). 3. Unit will start Off-Grid operation if the input voltage is higher than 27V or battery voltage is higher than 22V. User Manual Hybrid CPSHB300ETR-IN...
  • Page 26: Shut-Down The Unit

    1. If unit is operating, press and hold the button until all LEDs are red, it takes around 3 seconds. 2. Disconnect the AC/Grid power cord. 3. Disconnect all PV connectors. 4. When all LEDs are OFF, the unit will totally shutdown. User Manual Hybrid CPSHB300ETR-IN...
  • Page 27: Maintenance

    Battery cover Battery Fig. 8-1 Procedure of replacing batteries Disconnect the 2 batteries from unit and replace them with new ones. Connect the new batteries to unit, notice the polarity! Assemble the unit in reverse order. User Manual Hybrid CPSHB300ETR-IN...
  • Page 28: Replace The Fuse

    Pull out the fuse holder underneath the AC/Grid socket. Replace the broken fuse with new one. Note the rating must be 6.3A/250V P Place the fuse assembly back into the AC/Grid socket. Fig. 8-2 Grid O/P fuse replacement User Manual Hybrid CPSHB300ETR-IN...
  • Page 29: Decommissioning

    Do not dispose of faulty units or accessories together with household waste. Please accordance with the disposal regulations for electronic waste which apply at the installation site at that time. Ensure that the old unit and, where applicable, any accessories are disposed of in a proper manner. User Manual Hybrid CPSHB300ETR-IN...
  • Page 30: Specification

    Specification 10.1 Specification of CPSHB300ETR-IN Table 10-1 Specification CPSHB300ETR-IN PV Input Max. input power 310W Absolute max. input voltage 50Vdc Full power voltage range 34-38Vdc Operating voltage range 28-48Vdc Rated input voltage 36Vdc Max. input current 9Adc MPP Tracker Short circuit current, Isc Max.
  • Page 31: Torque Values

    Relative humidity 0-95% Operating elevation 0-2000m (0-6666ft) Cooling Natural convection Overvoltage category Protective class Mechanical Dimension (W*H*D, mm) 292*186*202 Weight Package dimension (W*H*D, mm) 380*305*290 10.2 Torque Values Table 10-2 Torque values Battery cover screws 10kgf.cm (0.98N.m) User Manual Hybrid CPSHB300ETR-IN...
  • Page 32: Contacts

    Model Name Serial Number Detailed Error Description CyberPower Systems India Pvt.Ltd NO.1107, 11TH Floor, Mittal Commercia, Off Andheri Kurla Road, Marol, Andheri East, Mumbai, India 400059 T: 022-28566100 F: 022-28566110 E: Sales@cpsww.co.in www.cyberpower.com User Manual Hybrid CPSHB300ETR-IN...
  • Page 33 Note...
  • Page 34 Note...
  • Page 36 www.CyberPower.com K01-0000634-00...
