Third level menu and explanation
Working information
The followings are third level menu interfaces for each second level menu items of working information, shown in
The followings are third level menu interfaces for each second level menu items of working information, shown in
Fig6.3.15
Explanations of each item in third level menu interface of working information:
State information:
Second level menu
Inverter info
User Manual
Fig 6.3.15 Third level menu interface of working information
Table 6.2 Working information sub-items explanation
Third level items
State: Normal
Power: xxx.xx
E_day
E_all
Input info
V_pv: xxx/xxx
I_pv: xx.x/xx.x
P_pv: xxx/xxx
Output info
V: xxx.xxx.xxx
I: xx.x/xx.x/xx.x
P: xxx/xxx/xxx
38 / 61
Item explanation
Inverter running state
AC gross output power
Energy produced today
Energy produced since installation
Inverter input parameters
PV input voltage for each MPP tracker
PV input current for each MPP tracker
PV input power for each MPP tracker
Inverter output parameters
AC output voltage for each phase
AC output current for each phase
AC output power for each phase
