4.
Pull out the white connectors with some tinny tools.
5.
Take away the fans from the cover and clean them thoroughly.
6.
When finishing cleaning, put back the fans in reverse order.
8.2 Exchange Fan
Sometimes the heat dissipation error occurred because the cooling fans failed, under such situation, you need to
exchange the cooling fans.
The procedure is similar to 8.1 Cleaning Cooling Fan and Grill (Step 1 ~ 6), step 7 should be exchanging the fans and
assembling the inverter in reverse order.
User Manual
Fig 8.1.7
50 / 61
Fig 8.1.6
CPS Mini Central series
