If the network operator stipulates a residual-current protective device, you must use a
residual-current protective device that triggers in the event of a residual-current of 100 mA or more.
Connection of a second protective conductor
In some installation countries, a second protective conductor is required to prevent a touch current in
the event of a malfunction in the original protective conductor.
For installation countries falling within the scope of validity of the IEC standard 62109, you must install
the protective conductor on the AC terminal with a conductor cross-section of at least 10 mm²Cu.
Or install a second protective conductor on the earth terminal with the same cross-section as the original
protective conductor on the AC terminal
Load disconnection unit
You must install a separate three-phase miniature circuit-breaker or other load disconnection unit for each inverter
in order to ensure that the inverter can be safely disconnected under load.

Measure the public grid voltage and frequency (Voltage: 400Vac; Frequency: 50Hz/60Hz; in 3-Phase);

Open the breaker between the PV inverter and utility;
Specification of AC breaker: CPSPV70000ETL: 16A/400V
Cable requirements:
Model
CPSPV70000ETL
CPSPV80000ETL
CPSPV90000ETL
CPSPV100000ETL
CPSPV120000ETL
CPSPV180000ETL
CPSPV200000ETL
Conductor
Cross section
6.0 mm²
10.0 mm²
16.0 mm²
AC connector type
Connector 1
Connector 2
User Manual
CPSPV8000ETL/ CPSPV9000ETL: 20A/400V
CPSPV10000ETL/ CPSPV12000ETL: 25A/400V
CPSPV18000ETL/ CPSPV20000ETL: 50A/400V
Diameter(mm)
2.05~4.11
2.05~4.11
2.05~4.11
2.05~4.11
2.05~4.11
2.59~4.11
2.59~4.11
CPSPV CPSPV CPSPV
7000ETL 8000ETL 9000ETL
70 60
140 125
220 200
Conductor cross-section
Area(mm²)
4~16
4~16
4~16
4~16
4~16
6~16
6~16
Max. cable length(m)
CPSPV CPSPV
10000ETL 12000ETL
54 48
110 72
175 105
(mm²)
4.0-6.0
4.0-6.0
23 / 61
Available wire gauge (AWG)
12~6
12~6
12~6
12~6
12~6
10~6
10~6
CPSPV CPSPV
18000ETL 20000ETL
40 27
60 40
88 59
Stripping length (mm)
8
8
