  • Page 1 Hybrid Inverter CPS1200EO12LCD CPS2200EO24LCD User’s Manual...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 IMPORTANT SAFETY INSTRUCTIONS…………………………..4 2 INSTALLATION……..………………………………………………..5 2-1 Unpacking………………………………………………………....5 2-2 Product Overview & Outlook…………………………………………..5 2-3 Power Requirements of Your Equipment…...………………………..7 2-4 Hardware Installation Guide……..…………………………………….7 3 DEFINITIONS FOR ILLUMINATED LCD INDICATORS…..10 4 OPERATION & CONFIGURATION……………………………….13 Power On/Off..……………………………………………………………...13 Function Setup…………...………………………………………………...13 Audible Alarm…………………….…...…………………….…....13 Function Setup Guide…..………….…...……………………....13 Charger Control…..……………………………........18...

  • Page 4: Important Safety Instructions

    1 IMPORTANT SAFETY INSTRUCTIONS (SAVE THESE INSTRUCTIONS) Before attempting to unpack, install, or operate the product, please read and follow all instructions carefully. CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor area free of conductive contaminants.

  • Page 5: Installation

    2 INSTALLATION 2-1 Unpacking Inspect the product upon receipt. The box should contain the following: (a) This product; (b) User Manual; (c) Input Power Cord User Manual Input Power Cord Power Inverter 2-2 Product Overview & Outlook CyberPower Solar Hybrid Inverter System converts renewable solar energy from panels into usable AC and store excess power in batteries as backup power during blackout and emergencies.
  • Page 6 CPS1200EO12LCD / CPS2200EO24LCD 1. Multifunction LCD Readout 2. Power On/off Switch 3. Function Buttons 4. DC Input Cable(Black ”-”) 5. DC Input Cable(Red ”+”) 6. Input circuit breaker 7. Charger control 8. Input voltage range selector 9. AC outlet 10. AC inlet 11.

  • Page 7: Power Requirements Of Your Equipment

    Ensure that the equipment plugged into the AC outlet does not exceed the product’s rated capacity (1200VA/780W for CPS1200EO12LCD; 2200VA/1320W for CPS2200EO24LCD). If rated unit capacities are exceeded, an overload condition may occur and cause the unit to shut down or the circuit breaker trip.
  • Page 8 PV module. CAUTION! To reduce risk of injury, use appropriate cables for PV connection. The wiring can only be performed by trained personnel. Refer to below table for recommended cable size. Model PV Charging Current Wire Gauge CPS1200EO12LCD 12AWG CPS2200EO24LCD 12AWG...
  • Page 9 Connect the cables from PV module to the unit’s PV input terminals. Please check the polarity before connection. For more information about PV Module Selection, please refer to the APPENDIX section. Step 3 Connect the Product to Utility Connect the product to a wall outlet. Charging the battery for at least 8 hours is recommended to ensure that the battery’s maximum charge capacity is achieved.

  • Page 10: Definitions For Illuminated Lcd Indicators

    3 DEFINITIONS FOR ILLUMINATED LCD INDICATORS LCD Display The left half of the LCD screen displays the energy flow direction and the status of the Power Inverter. The right half of the LCD screen displays the input, output, and battery information. Icon Description Normal Mode (Power On)
  • Page 11 Fault This icon appears if there is a problem with the unit. Overload This icon appears and an alarm sounds to indicate the outlet is overloaded. Mute This icon appears whenever the unit is in silent mode. However, when there is a problem with the unit, the alarm will still beep even in silent mode.
  • Page 12 Operation Modes There are three types of modes regarding to the operation of the Power Inverter. The corresbonding LCD displays are as shown below. LCD Display Operation Mode Standby Mode(only AC) In this Mode, the Inverter is off and the Utility power bypasses to output and in the meantime charges the battery.

  • Page 13: Operation & Configuration

    Battery Mode1 During a severe brownout or blackout, the Utility Power is absent and the Power Inverter switches to Battery Mode. The battery will supply power to the load (connected equipment). Battery Mode2 During a severe brownout or blackout, the Utility Power is absent and the Power Inverter switches to Battery Mode.
  • Page 14 Page 2 –Load Priority If setting “Utility” priority, 1(Utility) 1(Utility) 2(PV) utility will provide power to loads as first priority. Solar and battery energy will provide power to loads only when utility power is not available.(default) If setting “PV” priority, solar energy will provide power to loads as first priority.
  • Page 15 If setting “Utility”, the utility power charging the battery first. Solar energy will charge battery only when utility power is not available. If setting “PV”, the solar power charging the battery first. Utility energy will charge battery only when solar power is not available. CPS1200EO12L 11.5V(23.
  • Page 16 setting voltage point in P05, unit will transfer back to PV mode. Page 6 – Auto Restart Voltage CPS1200EO12L When the utility power comes back and starts to Any/10.5/11.0/ charge the battery, the /11.5/12.0/12.5/ Power Inverter will auto 13.0/FUL restart at the setting battery voltage.
  • Page 17 Page 9 – Cycling Display 0.5 Min If the buttons are not touched in 0.5/1 minute, the 0.5/1 Min LCD will start cycling the Inverter information. Page 10 – Back to Default Select Yes to restore the factory default settings. Page 11 –...

  • Page 18: Charger Control

    CPS2200EO24LCD.  Customized (for poor battery condition): The charging voltage is 13.3V for CPS1200EO12LCD and 26.6V for CPS2200EO24LCD. If the battery is aging, lower the charging voltage to enhance the charging capability. Input Voltage Range Selector Input voltage range is defined in specification section. Output voltage is the same as input voltage in AC mode.

  • Page 19: Troubleshooting

    5 TROUBLESHOOTING Problem Possible Cause Solution The unit is not connected to an The unit must be connected to a AC wall outlet. 220/230V outlet. The product will not turn on. The battery is worn out. Replace the batteries. Mechanical problem. Contact CyberPower Systems.
  • Page 20 Fault Code Table Fault Code Event Audible Alarm Overload Rapid beeping every 1/2 second High Temperature Beep every second PV Voltage High Beep every second PV Current High Beep every second Output Voltage High Constant tone Output Short Constant tone Overload Fault Constant tone Fan Fail...

  • Page 21: Technical Specifications

    6 TECHNICAL SPECIFICATIONS Model CPS1200EO12LCD CPS2200EO24LCD Power Rating (VA/Watt) 1200VA/780W 2200VA/1320W Input Narrow Mode: 170 - 280Vac Input Voltage Range Wide Mode: 90 - 280Vac Input Frequency 50/60Hz (Auto-sensing) Output Output Voltage 230Vac Output Frequency 50/60Hz Outlet Type (1) UN...
  • Page 22 If one PV module cannot meet this requirement, connect multiple PV modules in series to increase the total voltage. Example for CPS1200EO12LCD After considering Voc of PV module not exceeds 40VDC and Max. Vmp within 15~18VDC, we can choose PV module with below specification.
  • Page 23 CAUTION! Ensure that Open Circuit Voltage (Voc) of PV modules not exceeds 40V for CPS1200EO12LCD and 55V for CPS2200EO24LCD, or else the product may be damaged. If PV voltage or current is out of normal range, the unit will stop solar charging and send a warning code.
