Epson Stylus Pro 10000 Product Information

Epson stylus pro 10000: product information.
Hide thumbs

Advertisement

mounting
roll paper
roll paper
brackets
cover
spindles
lower cover
paper hammock
FireWire ® interface
optional interface
connectors
card slot
optional Automatic
Take-Up Reel
connector
parallel interface
connector
paper set lever
control
panel
ink cartridge compartment
Photo Printing
Accelerator slot
USB interface
AC inlet
connector
Printer Specifications
Printing
Printing method On-demand ink jet
Nozzle
180 nozzles
configuration
yellow, light cyan, light magenta)
Resolution
Maximum 1440
Maximum
43.78 inches on 44-inch paper
printable width
Maximum print
231 ft
speed
Print direction
Bidirectional
Control code
ESC/P
Line spacing
1/6 inch (default), programmable in
1/720-inch increments
Paper feed speed 215 ± 10 milliseconds per 1/6-inch line
RAM
128MB (fixed)
Engine Reliability
Total print
20,000 B0 images, 30% coverage
volume
Print head life
28 billion dots per nozzle
Periodic
Waste ink system requires replacement
maintenance
approximately every two years based on
25% duty cycle (parts and labor not covered
under warranty)
Cutter blade life Approximately 2000 B0+ sheets (EPSON
media up to 4.33 mil thick)
5/01

EPSON Stylus Pro 10000

6 black, cyan, magenta,
720 dpi
2
/hour
®
Raster
EPSON Stylus Pro 10000 - 1

Advertisement

   Related Manuals for Epson Stylus Pro 10000

   Summary of Contents for Epson Stylus Pro 10000

  • Page 1: Epson Stylus Pro

    Accelerator slot Engine Reliability Total print volume Print head life Periodic maintenance Cutter blade life Approximately 2000 B0+ sheets (EPSON AC inlet 5/01 EPSON Stylus Pro 10000 180 nozzles 6 black, cyan, magenta, yellow, light cyan, light magenta) Maximum 1440 720 dpi 43.78 inches on 44-inch paper...

  • Page 2

    Approx. 130.5 W (ISO/IEC 10561 Letter Pattern); 29 W or less in standby mode Note: This product is also made for IT power systems with phase-to-phase voltage 220 to 240 V. See the printer’s label for voltage information. Ink Cartridges Print yield Photographic Dye ink: Approx.

  • Page 3

    Revision 1.1, Universal Serial Bus Device Class Definition for Printing Devices Version 1.1 Approximately 12M bps (full speed device) NRZI USB Series B 6 feet Parallel IEEE 1394 (standard) (standard) (standard) OS 8.51 ® EPSON Stylus Pro 10000 - 3 ® Ethernet (optional)

  • Page 4

    64 to 90 gsm. For best results, use paper under the following conditions: Temperature: 59 to 77 °F (15 to 25 °C) Humidity: 40 to 60% RH 4 - EPSON Stylus Pro 10000 Dimensions in millimeters Thickness 1118 1580 3.15 to 19.7 mil (0.08 to .5 mm)

  • Page 5: Consumables And Accessories

    Consumables and Accessories Ink Cartridges Use these 500 ml ink cartridges before the expiration date on the package: EPSON Stylus Pro 10000 Photographic Dye Ink Cartridge Part number Black T499201 Cyan T502201 Light Cyan T504201 Magenta T501201 Light Magenta T503201...

  • Page 6

    Requires optional 3-inch high tension spindle for roll paper 13 × 19 (SB): S041456 ** Requires optional 2-inch high tension spindle for roll paper ***Not available at time of publication. Check the EPSON web site 24 × 30: S041434 (http://prographics.epson.com) for product codes and availability.

  • Page 7: System Requirements

    Windows 98, Me, or 2000 with a Windows compliant USB port and a shielded USB “AB” cable from Series A (computer) to Series B (printer) up to 6.6 ft (2 m) long For IEEE 1394 (FireWire) connection: IBM-compatible PC running Windows Me or 2000, with a compliant IEEE...

  • Page 8

    INK LOW Ink Out Ink cartridge(s) are light(s) flashing nearly empty (printing continues). 8 - EPSON Stylus Pro 10000 Error conditions (continued) Display Message/Light INK OUT light(s) on LOAD PAPER Paper Out light is...

  • Page 9: Printing A Status Check

    Follow these steps to print the status check: with both rows of holes. Resize your image or 1. Load a sheet of paper in the printer. (You can print test load wider paper. pages on roll paper, but you will waste paper.) Cut the paper at the 2.

  • Page 10: Replacing An Ink Cartridge

    You must replace the cartridge before you can continue printing. Note: You must use the EPSON ink cartridges designed for your printer. Other ink cartridges will not work and may cause damage not covered by your warranty. If you don’t use the cartridges designed for your model, you will see an error message.

  • Page 11: Running A Nozzle Check

    Follow these steps to print the nozzle check: 1. Load a sheet of paper in the printer. (You can print the nozzle check on roll paper, but you will use more paper.) 2.

  • Page 12: Aligning The Print Head From The Control Panel

    If you have installed the EPSON printer driver and utilities, you can run the Head Cleaning utility. See the EPSON Stylus Pro 10000 Printer Guide for instructions. Follow these steps to run the cleaning cycle from the control panel: 1.

  • Page 13: Preparing The Printer For Shipment

    Transporting or Storing the Printer Follow these guidelines for transporting or storing the printer: Contact EPSON if you need to store your printer for an extended period (two years for the Photographic Dye Ink model, or six months for the Archival Ink model). A service technician must drain all ink from the printer before it is stored.

  • Page 14: Setting Up The Printer After Transporting It

    EPSON Stylus Pro 10000 6. Have four people lift the printer off of the stand, using the hand grips located at the four corners of the printer. Lift the back of the printer first, tilt it slightly to the front, then slide it back to remove it.

  • Page 15: Replacing The Waste Ink System

    About every two years of normal usage (25% duty cycle) or after 12,000 B1-size prints, you must have your authorized EPSON servicer replace the waste ink system. This is necessary to prevent damage to the print head and maintain print quality. Parts and labor for this service are not covered under the terms of the limited warranty.
