DS 1010 PLUS
No-load speed
Pad diameter
Sanding sheet size
Weight
Sound emission values determined according to
EN 60745-1
Typically the A-weighted noise levels of the product are:
Sound pressure level
Sound power level
Uncertainty K
Vibration total values a
uncertainty K determined according to
EN 60745-1
Vibration level max:
a
h ,HD
K
IDENTIFICATION
1. On/off switch
2. Pad cover segment
3. Flexible hose + vacuum cleaner adapter Ø 57
mm
4. Backing pad (VELCRO)
5. Sanding disc
6. Sanding speed selection wheel
7. Vacuum cleaner adapter Ø 47 mm
8. Vacuum cleaner adapter Ø 35 mm
9. Double-ended screwdriver
10. Hex key
11. Safety button for On/Off switch
REPLACEMENT OF SANDING PAPER
Backing pads 4
Never run the tool without backing pad 4
Replace damaged backing pads immediately
ƒ
(loosen/fasten pad screw with hex key 10).
Unplug tool before removing/mounting back-
ƒ
ing pads.
Mounting sanding discs 5
Simply press sanding disc 5 onto backing pad with
ƒ
perforation in sanding disc corresponding with
perforation in backing pad. If necessary, clean
backing pad first
The dust suction requires the use of perforat-
ƒ
ed sanding discs.
REPLACEMENT OF GRINDING DISC STUCK
The output shaft is inserted into the adhesive disc
center with six angle wrench clockwise rotation
angle in the six-hex, and at the same time, the
hands hold the adhesive disc grinding, grinding
disc can be remove adhesive.
SPEED ADUSTMENT
The grinding of the grinding disc rotation speed
can be adjusted according to different conditions
min 1.000-2.350
-1
mm 210
mm 225
kg 3,25
dB(A) 83,4
dB(A) 94,4
dB
(triax vector sum) and
h
m/s 1,745
2
m/s 1,5
2
and grinding quality requirements.
The Drywall Sander is equipped with a variable
speed control. The speed is adjusted by turning
the control knob. The control knob is numbered
"MIN" through "MAX" with "MIN" being the slow-
est speed (Approximately 1000 RPM) and "MAX"
being the fastest speed (approximately 2350
RPM).
Use the higher speed settings for fast stock re-
moval. Use the lower speed selling to reduce re-
moval rate for more precise control.
ANGLE GRINDING
In order to do side grinding work, take off the
front part of plastic disc with screw driver.
3
TO START AND STOP DRYWALL SANDER
Make sure power circuit voltage is the same as
shown on the specification plate on the sander,
and that the sander switch is OFF. Connect sander
to power circuit.
To start the sander: Press the safety button and
press the ON/OFF switch.
To stop the sander: Release the ON/OFF switch.
HOLDING AND GUIDING THE TOOL
Always hold the tool firmly with both hands.
f
While working, always hold the tool at the grip
f
area.
Guide the tool parallel to the working surface and
f
move it in circles or in a cross pattern
Do not apply too much pressure on the tool; let
f
the sanding surface do the work for you
Do not tilt the tool in order to avoid unwanted
f
sanding marks.
Keep ventilation slots uncovered.
f
SANDING
The amount of material removed is determined
f
by the speed of the sanding disc and the grit size
used.
The speed of the sanding disc decreases relative
f
to the pressure applied to the tool.

MAINTENANCE

Keep tools clean, clean up debris and dust.
f
Always check the power cable, plug, switch, so
f
that the tools is in good condition.

ENVIRONMENTAL PROTECTION

Recycle raw materials instead of dispos-
ing as waste. Machine, accessories and
packaging should be sorted for envi-
ronment - friendly recycling. The plastic
components are labeled for categorized
recycling.
English | 9
