Non-Coin Programming _______________

To Enter Programming Mode
Press
And
O
To Exit Programming Mode Press
Until Display Returns to "Ready".
0:
SELECT LANGUAGE
1:
SELECT SYSTEM PARAMETERS
0:
DRYER SETUP
0: SELECT MODEL
1: SYSTEM TEMP
2: ENTER LINT COUNT 1 TO 5
3: ENTER AUDIO ALERT ON TIMES 0 TO 10
4: ROTATION SENSOR
1:
REVERSING SETUP
0: ENTER SPIN TIME 30 TO 120 SECONDS
1: ENTER STOP TIME 5 TO 10 SECONDS
WRINKLE GUARD SETUP
2:
0: WRINKLE GUARD AUDIO ALERT
3:
STEAM INJECTION SETUP
2:
PROGRAM A - F CYCLES
ENTER A - F
SELECT CYCLE TYPE
AUTO
0:
REVERSE MODE
1:
ENTER DRY TEMP 160 (71) TO 200 F (94 C) *
2:
ENTER DRYNESS LEVEL
3:
ENTER CYCLE ADJUSTMENT VALUE 0 TO 99
4:
CONTROLLED COOL DOWN
5:
ENTER COOL DOWN TIME 0 TO 99 MINUTES
6:
ENTER COOL DOWN TEMP 70 (21) TO 100 F (38 C)
MANUAL
0:
REVERSE MODE
1:
ENTER DRY TIME 0 TO 99 MINUTES
2:
ENTER DRY TEMP 100 (38) TO 200 F (94 C) *
3:
CONTROLLED COOL DOWN
4:
ENTER COOL DOWN TIME 0 TO 99 MINUTES
5:
ENTER COOL DOWN TEMP 70 (21) TO 100 F (38 C)
6:
STEAM INJECTION
3:
PROGRAM 0 - 40 CYCLES
ENTER 0 - 40
SELECT CYCLE TYPE
AUTO
0:
REVERSE MODE
1:
ENTER DRY TEMP 160 (71) TO 200 F (94 C) *
2:
ENTER DRYNESS LEVEL
3:
ENTER CYCLE ADJUSTMENT VALUE 0 TO 99
4:
CONTROLLED COOL DOWN
5:
ENTER COOL DOWN TIME 0 TO 99 MINUTES
6:
ENTER COOL DOWN TEMP 70 (21) TO 100 F (38 C)
MANUAL
0:
REVERSE MODE
1:
ENTER DRY TIME 0 TO 99 MINUTES
2:
ENTER DRY TEMP 100 (38) TO 200 F (94 C) *
3:
CONTROLLED COOL DOWN
4:
ENTER COOL DOWN TIME 0 TO 99 MINUTES
5:
ENTER COOL DOWN TEMP 70 (21) TO 100 F (38 C)
6:
STEAM INJECTION
4:
DEFAULT SETTING
FAULT HISTORY
5:
SAFE SYSTEM VALVE TEST
DISPLAY:
O
SAFE TEMP
* 160 F (71 C) MAXIMUM TEMP ON AXIAL MODELS
Phase 7.2 Non-Coin Diagnostic Codes
MAIN DOOR OPENED – A main door or door circuit is open.
EXHAUST HIGH TEMP FAULT – Tumbler is above 220° F
(104° C).
LINT ACCESS OPEN – Lint drawer or lint door circuit is open.
EXHAUST HIGH LIMIT FAULT – Temp. disk under tumbler is
open.
SAIL SWITCH CLOSED FAULT – Sail switch is closed – should
be open at the start of a cycle.
30
Keys Together
O
Multiple Times
OR
O
+ A
TUMBLER TEMP
CTL VAC / RPM
American Dryer Corp.
SAIL SWITCH OPEN FAULT – Sail switch remained open
after the cycle started. Should have closed.
BURNER HIGH LIMIT FAULT – Burner temp. disk has opened.
BURNER IGNITION CONTROL – No signal to gas valve from
(DSI) module during trial for ignition time. DSI module is
bad.
IGNITION FAULT – Gas valve did not remain open after trial
for ignition. Indicates that no flame was detected.
FLAME FAULT – Flame was detected during trial for ignition
but failed later.
ROTATION FAULT – Indicates the tumbler is not rotating.
OPEN EXHAUST TEMPERATURE PROBE – Indicates the
exhaust temperature probe is open or shorted.
OPEN FIRE SUPPRESSION SYSTEM (F.S.S.) PROBE FAULT
– Indicates the temperature probe for the F.S.S. is open or
shorted.
LOW VOLTAGE FAULT – Volt dropped below the operating
value.
EE PROM FAULT ### – Error in memory location. Fault
correction:
Enter the program mode by pressing the UP and STOP keys.
Press "4" and ENTER keys in password "FAA" Press UP
ARROW.
Press enter to confirm reset of EE PROM.
Inputs (Red L.E.D.s)
All indications are with L.E.D. lit
ESTOP – Indicates E-STOP has been pressed.
GAS_V – Indicates the gas valve is open (ON).
BRHL – Indicates the burner high limit disk is closed
(temperature below 330° F [166° C]).
SAIL – Indicates the sail switch is closed.
EXHL – Indicates the exhaust high limit disk is closed
(temperature below 225° F [107° C]).
MAIN – Indicates the status of main door is closed.
LINT – Indicates the lint drawer is closed.
FUSE – Indicates the status of the control voltage after
POWER ON button has been pressed.
Outputs (Green L.E.D.s)
All indications are with L.E.D. lit
AUX – This is for a spare output to be programmed.
STEAM – Indicates the status of the steam injection output.
_HEAT – Indicates the status of the heat output.
AIR – Indicates the status of the air jet output.
REV – Indicates the status of the tumbler reverse direction
output.
If the request to tumble the drum in the reverse direction is
made, then the L.E.D. is ON.
FWD – This L.E.D. will indicate the status of the tumbler
forward direction output.
FAN – This L.E.D. will indicate the status of the fan output.
113237 - 15
