Table Of Contents - ADC AD-25V Installation Manual

WARNING
!
Proposition 65
Use of this product could expose you to substances
from fuel combustion that contain chemicals
known to the State of California to cause cancer,
birth defects and other reproductive harm.
IMPORTANT
You must disconnect and lockout the electric supply and
the gas supply or the steam supply before any covers or
guards are removed from the machine to allow access for
cleaning, adjusting, installation, or testing of any
equipment per OSHA standards.
Please observe all safety precautions displayed on the
equipment and/or specified in the installation manual
included with the dryer.
Before installation, check that the local distribution
conditions, nature of gas and pressure, and adjustment
of the appliances are compatible.
CAUTION
Dryer(s) should never be left unattended while in operation.
When discarding or storing your old clothes dryer,
remove the door.
Lorsque vous entreposez ou mettez votre sécheuse
au rebut, enlevez-en la porte.
"Caution: Label all wires prior to disconnection when
servicing controls. Wiring errors can cause improper
operation."
«Attention: Au moment de l'entretien des commandes,
étiquetez tous les fils avant de les débrancher. Des erreurs
de câblage peuvent entraîner un fonctionnement
inadéquat et dangereux.»
WARNING
Children should not be allowed to play on or near the
dryer(s). Children should be supervised if near dryer(s)
in operation.
Under no circumstances should the dryer door switch(es),
lint door/drawer switch(es), or heat safety circuit(s) ever
be disabled.
Do not modify this appliance.
The dryer must never be operated with any of the back
guards, outer tops, or service panels removed. Personal
injury or fire could result.
The dryer must never be operated without the lint filter/
screen in place, even if an external lint collection system
is used.
If the hi-limit switch trips, a service call is required to
investigate the reason and resolve the issue.
FOR YOUR SAFETY
Do not dry mop heads in the dryer. Do not use dryer
in the presence of dry cleaning fumes.
The dryers must not be installed or stored in an area where
it will be exposed to water and/or weather.
The wiring diagram for the dryer is located in the front
electrical control box area.
113237 - 15
In the State of Massachusetts, the following
installation instructions apply:
Installations and repairs must be performed by
a qualified or licensed contractor, plumber, or
gasfitter qualified or licensed by the State of
Massachusetts.
If using a ball valve, it shall be a T-handle type.
A flexible gas connector, when used, must not
exceed 3 feet.

Table of Contents _________________

Safety Precautions ....................................... 4
Specifications .............................................. 6
Installation Procedures ................................ 8
Unpacking / Setting Up ........................................................ 8
Location Requirements ....................................................... 8
Dryer Enclosure Requirements .......................................... 8
Fresh Air Supply Requirements ......................................... 9
Exhaust Requirements ........................................................ 9
Electrical Information ......................................................... 12
Gas Information ................................................................. 15
Steam Information ............................................................. 17
Preparation for Operation / Start-Up ................................ 19
Preoperational Test ........................................................... 20
Preoperational Instructions .............................................. 20
Shutdown Instructions ..................................................... 21
Service / Parts Information ....................... 22
Service .............................................................................. 22
Parts ................................................................................... 22
Warranty Information ................................. 22
Returning Warranty Cards ............................................... 22
Warranty ........................................................................... 22
Returning Warranty Parts ................................................ 22
Routine Maintenance ................................. 23
Data Label Information .............................. 24
Procedure for Functional Check
of Replacement Components .................... 25
Manual Reset Burner Hi-Limit Instructions 26
S.A.F.E. System ........................................... 27
Non-Coin Programming .............................. 30
Coin Programming ...................................... 31
List of Acronyms ________________________
D.M.S.
DSI
HVAC
in WC
L.C.D.
L.E.D.
L.P.
OSHA
R.M.A.
S.A.F.E.
U L
www.adclaundry.com
Drill Measurement Size
Direct Spark Ignition
Heating, Ventilating, and Air-Conditioning
Inches of Water Column
Liquid Crystal Display
Light Emitting Diode
Liquid Propane
Occupational Safety and Health Administration
Return Material Authorization
Sensor Activated Fire Extinguishing
Underwriters Laboratory
3
