- Page 1 AD-24 Parts Manual 24 VAC Phase 7 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450216-3...
- Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.
-
Page 3: Table Of Contents
Table of Contents Coin Control Door Assembly ... 4 Phase 7 Coin Microprocessor Control Panel Assembly ... 5 Phase 7 Coin Microprocessor Control Box Assembly ... 6 Microprocessor Coin Vault Assembly ... 7 Main Door “Steel” Assembly ... 8 Cold Rolled Steel Front Panel Assembly ... 9 Main Door Switch Assembly ... -
Page 4: Coin Control Door Assembly
Coin Control Door Assembly Illus. No. Part No. Qty. Description 883589 White Control Door without Locks (includes illus. nos. 1 through 3 and 6) 883590 Coral Blue Control Door without Locks (includes illus. nos. 1 through 3 and 6) 883591 Ivory Control Door without Locks (includes illus. -
Page 5: Phase 7 Coin Microprocessor Control Panel Assembly
Phase 7 Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 137250 Phase 7 Coin Ribbon Cable 137270 16” x 1” Large Character Display 883435 Phase 7 Coin Board 112575 Phase 7 Keyboard 153010 #6 Internal and External Star Washers 150005 #6-32 x 1/4”... -
Page 6: Phase 7 Coin Microprocessor Control Box Assembly
Phase 7 Coin Microprocessor Control Box Assembly Illus. No. Part No. Qty. Description 122681 10-Pin Connector 122676 8-Pin Connector 122646 2-Pin Connector 122640 9-Pin Connector 122669 Female Crimp Terminal 122706 #20-16 U.M.N.L. Socket * As needed. American Dryer Corporation 450216 - 3... -
Page 7: Microprocessor Coin Vault Assembly
Illus. No. Part No. Qty. Description 883596 Security Coin Vault Assembly Complete (includes illus. nos. 1 through 3) 802535 High Security Coin Vault ONLY 160022 High Security Screw Lock with Key 160113* Key ONLY for High Security Screw Lock 802534 High Security Coin Box ONLY 153050 1/2”... -
Page 8: Main Door "Steel" Assembly
Main Door “Steel” Assembly Illus. No. Part No. Qty. Description 881150 Black Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 102354 Door Gasket 170731 Black Gasket Adhesive (10.3 oz. cartridge) 881152 Black Top Hinge Block Assembly (includes illus. -
Page 9: Cold Rolled Steel Front Panel Assembly
Illus. No. Part No. Qty. Description 883598 White Front Panel Assembly (includes illus. nos. 1 through 3) 883599 Coral Blue Front Panel Assembly (includes illus. nos. 1 through 3) 883600 Ivory Front Panel Assembly (includes illus. nos. 1 through 3) 154215 1/8”... -
Page 10: Main Door Switch Assembly
Main Door Switch Assembly Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Door Switch ONLY 122636 Flag Terminal 881211 Black Main Door Switch Housing ONLY 881153 Black Main Door Switch Housing Complete (includes illus. -
Page 11: Tumbler / Support Assemblies
Illus. No. Part No. Qty. Description 800843 Tumbler and Support Assembly Complete (includes illus. nos. 1 through 9) 800717 Tumbler ONLY 154210 5/32” x 3/16” Large Flange Rivet 301318 Tapered Rib ONLY (low rib) 301317 Tapered Rib ONLY (high rib) 100916 5/16-18 x 25”... -
Page 12: Lint Door Assembly
Lint Door Assembly Illus. No. Part No. Qty. Description 883593 White Lint Door Assembly (includes illus. nos. 1 through 3) 883594 Coral Blue Lint Door Assembly (includes illus. nos. 1 through 3) 883595 Ivory Lint Door Assembly (includes illus. nos. 1 through 3) 170226 Slide Latch Flush Style (black) 117604... -
Page 13: Microprocessor Sensor Bracket Assembly
Illus. No. Part No. Qty. Description 880251 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 8) 130103 225º Large Automatic Reset Thermostat ONLY 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 122605 4-Pin Socket Connector ONLY... -
Page 14: Tumbler Bearing Assembly
Tumbler Bearing Assembly American Dryer Corporation 450216 - 3... - Page 15 Illus. No. Part No. Qty. Description 880209 1-3/4” Flange Bearing 153005 3/8” Lock Washer 152005 3/8-16 Hex Nut 883387 Pillow Block Bearing Assembly Complete (for micro models Only) (includes illus. nos. 4 through 18 and 23) 882544 Pillow Block Bearing Assembly Complete (for dual timer models Only) (includes illus.
-
Page 16: Lint Trap Assembly
Lint Trap Assembly Illus. No. Part No. Qty. Description 800429 Lint Trap Assembly Complete (includes illus. nos. 1 and 3 through 5) 801036 Lint Trap ONLY 154200 5/32” Pop Rivet 304102 Lint Screen Holder ONLY 150300 #10-16 x 1/2” Hex Washer TEK Screw 800503 Lint Screen ONLY 323724... -
Page 17: Idler Bearing Assembly
Illus. No. Part No. Qty. Description 100111 5L-650 V-Belt 101129 9” x 2-1/2” Compound Pulley 100105 4L-520 V-Belt (idler to motor) 154301 5/16-18 x 1” Allen Setscrew 100705 3/16” x 3/16” x 1-3/8” Key 882576 Idler Bearing Assembly Complete (includes illus. nos. 5 through 12) 150617 3/8-16 x 1”... -
Page 18: Motor Mount Assembly
Motor Mount Assembly Illus. No. Part No. Qty. Description 100105 4L-520 V-Belt (to idler bearing assembly) 101131 1/2” x 2-1/4” Motor Pulley (for use on 1Ø 60 Hz models Only) 150501 5/16-18 x 3/4” Tap Bolt 153002 5/16” Lock Washer 153001 5/16”... -
Page 19: Gas Burner Assembly
(includes illus. nos. 1 through 3 and 5 through 18) 882983 Direct Spark Ignition Burner Box – Liquid Propane Gas (includes illus. nos. 1 through 3 and 5 through 18) — 874058 AD-24 Liquid Propane Conversion Kit...Not Illustrated 450216 - 3 Gas Burner Assembly www.amdry.com... -
Page 20: Sail Switch / Hi-Limit Assemblies
Sail Switch / Hi-Limit Assemblies Illus. No. Part No. Qty. Description 154004 Twin Speed Nut 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 802799 Sail Switch Box Cover and Bracket ONLY 150303 #4 x 3/4” Pan Head “A” Machine Screw 122200 Sail Switch ONLY 105500... -
Page 21: Rear Electric Relay Panel Assembly
Illus. No. Part No. Qty. Description 151000 #6-32 Pal Nut 150300 #10-16 x 1/2” Hex Washer TEK Screw 150008 #6-32 x 1-1/4” Phillips Pan Head Machine Screw 120716 2-Position Terminal Block 322812 Rear Electric Mounting Plate ONLY 822796 Rear Electric Panel Assembly Complete – 115 Volt (includes illus. -
Page 22: Outer Top / Back Guard Assemblies
Outer Top / Back Guard Assemblies Illus. No. Part No. Qty. Description 322809 Back Electrical Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 330660 Top Back Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150309 #10-16 x 1/2”... -
Page 23: Additional Parts Available
Part No. Description 112280 “Clean Lint Screen” Label 114001 “CAUTION Exhaust / Lint Screen” Label 114548 “Phase 7 Coin Program Location Summary” Label 120100 3/8” Straight (BX) Connector 120300 3/8” x 45° (BX) Connector 120400 3/8” Red Jacket (BX) Insulator 120500 3/8”... - Page 24 ADC Part No. 450216 3 - 12/31/07 - 0...
