Table Of Content Unplugging the Power Cable Unplugging the Extruder Cable Unscrewing the Axis Block Covers, part 1 Unscrewing the Axis Block Covers, part 2 Extruder Removal Unscrewing the Belt Tensioners Loosening the Screws on the Self-Aligning Bearings Unscrewing the Self-Aligning Bearings Axis Removal Axis Assembly Securing the Self-Aligning Bearings...
Unscrewing the Belt Tensioners Unscrew the screw that secures the belt tensioner on each axis block and remove the belt from the block. The Y axis belt tensioners are placed on top of the Y axis blocks, whereas the X axis belt tensioners are placed on the bottom of the X axis blocks.
Unscrewing the Self-Aligning Bearings Unscrew the screws that secure the self-aligning bearings. Use a wrench or pliers to hold the nuts of the screws.
Securing the Self-Aligning Bearings Secure the self-aligning bearings with the screws. Do not fully tighten the screws yet. They need to be left slightly loose until the assembly of the axis is finished.
Securing the Axis Block Covers, part 1 Tighten one screw that secures the axis block cover on each block. Do not tighten the screws fully yet. They need to be tightened once the axis assembly is finished.
Page 17
Securing the Axis Block Covers, part 2 Tighten the other screws on top of each axis block. Do not tighten the screws fully yet. They need to be tightened once the axis assembly is finished.
