- Page 1 Maintenance Guide SOURCE: https://support.zortrax.com/m200-maintenance-guide/...
-
Page 2: Table Of Contents
Table Of Content Main Hotend Platform X/Y Axes; Extruder Guide Rails Extruder Z axis Lifespan of particular components... -
Page 3: Main
Main ACTIVITY FREQUENCY Cleaning the machine, its interior and Before each surroundings, especially the bottom plate printing under the platform Cleaning the motherboard and the power Every 300 supply unit from dust using compressed air working hours... -
Page 4: Hotend
Hotend ACTIVITY FREQUENCY Checking if the hotend and the nozzle are Before each not clogged printing process Cleaning the nozzle After finishing one spool of material Checking if the screws that secure the Every 300 heater and thermocouple are tightened working hours... -
Page 5: Platform
Platform ACTIVITY FREQUENCY Cleaning the perforated plate Before each printing process Checking the perforated plate for Before each deformation printing process Calibration Every 200 working hours Cleaning the heatbed and the underside of Every 300 the perforated plate working hours... -
Page 6: X/Y Axes; Extruder Guide Rails
X/Y Axes; Extruder Guide Rails ACTIVITY FREQUENCY Checking if the axes and the extruder guide Before each rails are clean from material remains and printing process dust Checking the tension of the drive belts on Every 300 the X/Y axes working hours Checking the tension of the drive belts Every 300... -
Page 7: Extruder
Extruder ACTIVITY FREQUENCY Checking if the extruder top cover and the Before each start- material guide are properly installed up of the printer Checking if the material guide is properly Before each start- secured to the extruder cable with the up of the printer material guide clamps If you use the HEPA Cover, check if it does... -
Page 8: Z Axis
Z axis ACTIVITY FREQUENCY Checking if the Z-axis screw and rails are Before each clean from material remains printing Lubricating the Z-axis screw and rails Every 400 working hours... -
Page 9: Lifespan Of Particular Components
Lifespan of particular components The table shows an approximate lifespan of parts that are exposed to natural wear and tear. In order to maintain the printer in good condition and to provide the highest priting quality, it’s advisable to replace particular components after an appropriate period of time indicated in the table.
