Technical Specifications
Table A-4
Media Port Speed
SMF-IR 155 Mbps or
622 Mbps
SMF-LR 622 Mbps
MMF 155 Mbps or
622 Mbps
Cat. 5 155 Mbps
UTP
75 ohm 44.7 Mbps
coax
75 ohm 44.7 Mbps
coax
75 ohm 34.3 Mbps
coax
Table A-5
Protocol
Signaling
ATM routing protocols
LAN protocols
A-4 SmartSwitch 9A100 User Guide
ATM port specifications
Framing Connector
STS-3 or STM-1 SC
STS-12 or STM-4
STS-12 or STM-4 SC
STS-3 or STM-1 SC
STS-12 or STM-4
STS-3 or STM-1 RJ-45
DS-3 BNC,
nonchannelized female
DS-3 BNC,
nonchannelized female
E-3 BNC,
nonchannelized female
Protocols standards and specifications
Standard
ATM Forum UNI 3.0
ATM Forum UNI 3.1
ATM Forum UNI 4.0
ATM Forum ILMI 3.0/3.1, 4.0
IISP
PNNI Phase 1.0
UNI
ATM Forum LANE 1.0 (Ethernet and Token Ring)
IETF RFC 1577 Classical IP-ATM
Max. Rx
Max. Tx Min. Tx
power
Power power
-8 dBm -15 dBm -7 dBm
-- -3 dBm -7 dBm
-19 dBm -14 dBm -14 dBm
v -- --
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
Specifications
Min. Rx Range
power
-28 dBm 15 Km
-28 dBm 40 Km
-31 dBm 2 Km
-- 100 m
n/a 150 m to
DSX
n/a 150 m to
DSX
n/a 150 m to
DSX
