IP Routing
SmartSwitch 9A100 IP routing performance is inadequate for routing between
Note
VLANs. If you need to create routes between VLANs on your
SmartSwitch 9A100, use a router equipped with an ATM interface. Consult
Cabletron Customer Support for recommended routers.
For example,
•
Switch SW1 and the NMS are on an Ethernet network with address 128.205.99.0.
•
The IP address of SW1's Ethernet port is 128.205.99.254.
•
The IP address of SW1's LANE client is 90.1.1.254.
•
The IP address of SW2's LANE client is 90.1.1.33.
•
SW2 is not physically connected to the Ethernet network.
•
SW2 is connected to SW1 through PNNI, and are both part of the same emulated LAN.
To reach SW2 with the Ethernet-based NMS, create an IP route that assigns SW1's switch client as SW2's default
gateway to the network 128.205.99.0. Enter the following on SW2 (see Figure 4-3):
SmartSwitch # add route
DestNetIP() : 128.205.99.0
GatewayIP() : 90.1.1.254
SmartSwitch #
Switch SW2 can communicate with the NMS on the Ethernet network.
To see the route, enter the
SmartSwitch # show route
ROUTE NET TABLE
destination gateway
------------------------------------------------------------------------
0.0.0.0 0.0.0.0
90.1.1.0 90.1.1.33
128.205.99.0 90.1.1.254
------------------------------------------------------------------------
ROUTE HOST TABLE
destination gateway
------------------------------------------------------------------------
127.0.0.1 127.0.0.1
------------------------------------------------------------------------
SmartSwitch #
The NMS must contain a route that specifies the Ethernet interface of the Ethernet
Note
connected switch as the gateway to the ELAN subnet.
4-8 SmartSwitch 9A100 User Guide
< address of the Ethernet network to reach
< IP address of SW1's LANE client
command on SW2
show route
flags Refcnt
1 0
1 0
1 3
flags Refcnt
5 0
Use Interface
0 zn0
1688 zn1
5660 ei0
Use Interface
0 lo0
Switch Administration
