Switch Administration
Enter the
4.
add ATMRoute
SmartSwitch # add atmroute
PortNumber(A1) : b2
AtmAddress() : 52:00:00:00:00:00:00:00:00:00:14:51:80
PrefixLength(104) :
Index(0) :
Type(Internal) :exterior
Scope(0) :
MetricsTag(0) :
SmartSwitch #
Note The
the route. For more on metrics and metric tags, see Section 4.2.3 "Route Metrics."
Enter the
5.
show ATMRoute
SmartSwitch # show atmroute
AddressNumber(ALL)
No. Port Route Address
================================================================================
1 B4 39:00:00:00:00:00:00:00:00:00:14:41:80:00:20:d4:14:41:80
2 B4 39:00:00:00:00:00:00:00:00:00:14:41:80:00:20:d4:14:41:81
3 -- 39:00:00:00:00:00:00:00:00:00:14:59:00
4 -- 39:00:00:00:00:00:00:00:00:00:28:e9:80
5 -- 39:00:00:00:00:00:00:00:00:00:28:f5:00
6 B4 47:00:79:00:00:00:00:00:00:00:00:00:00:00:a0:3e:00:00:01
7 B2 52:00:00:00:00:00:00:00:00:00:14:51:80
SmartSwitch #
The route to the IISP device appears on the last line (Route No. 7).
6. Create a route on the IISP device that refers to the net prefix
(
39:00:00:00:00:00:00:00:00:00:14:41:80
Note For IISP routes to work with certain devices, ILMI may also need to be disabled
on the SmartSwitch 9A100. Use the
on the SmartSwitch 9A100 on a per-port basis.

IISP Routing Considerations

When creating routes between the SmartSwitch 9A100 (running PNNI) and IISP devices, the criteria that characterize
IISP connectivity still apply. To reach a SmartSwitch 9A100 within the PNNI domain, the IISP device must have a
configured route that points directly to a port on the target SmartSwitch 9A100. Conversely, there must be a
SmartCell 9A100 that has a direct physical link (and a route over that link) to the IISP device. The following two
examples illustrate this point.
In Figure 4-1 Switch A is an IISP device connected to the PNNI domain through Switch B. Switch A contains an LEC,
which is a member of an ELAN whose LECS is on Switch C (within the PNNI domain). If the LEC on Switch A is to
make contact with the LECS on Switch C, Switch A must contain an IISP route (denoted by the dotted line) directly
to switch C. Furthermore, Switch B must contain a route to switch A over the physical link that connects the two
switches.
command to create a static route to the IISP device:
command allows you to specify a set of metrics to be used with
add ATMRoute
command to determine whether the route was created:
) of port
:
on the SmartSwitch 9A100.
b2
command to disable ILMI
set PortConfig
ATM Routing
Type Protocol
I MGMT
I MGMT
I PNNI
I PNNI
I PNNI
I MGMT
I MGMT
SmartSwitch 9A100 User Guide 4-3
