EdgeStore NAS400 User Manual

Managing Backups

This category includes the following topics:
• Viewing a List of Snapshot Backups (page 84)
• Setting up a Snapshot Backup (page 84)
• Scheduling a Snapshot Backup (page 85)
• Recovering Snapshot Backups (page 85)
• Viewing the NAS Replication Schedule (page 86)
• Setting up NAS Replication (page 86)
• Enabling One Touch Backup (page 87)

Viewing a List of Snapshot Backups

To view the list of Snapshot backups:
1. In the Tree, click the + beside the Backup icon.
2. Click the Snapshot Backup icon.
The current list of Snapshots displays on the Information tab.

Setting up a Snapshot Backup

To setup a Snapshot Backup:
1. In the Tree, click the + beside the Backup icon.
2. Click the Snapshot Backup icon.
3. Click the Setup tab.
4. From the Volume dropdown menu, choose the RAID Volume you want to
backup.
5. Next to Snapshot Status, click the Enable option.
6. In the Reserve Capacity dropdown menu, choose a portion in GB of the
RAID Volume you want to reserve for snapshots.
7. Click the OK button.
8. In the confirmation box, type yes into the filed provided than click the OK
button.
The snapshot backup settings are applied. The process takes a few
moments. Click the Schedule tab for scheduling options.
Setting up a Snapshot will delete all existing Snapshots.
Caution
84
