Specifications
Technical Specifications
CPUs
PowerPC
Intel i960 RISC-based microprocessor
Memory
8 MB Flash Memory (expandable to 16 MB)
32 MB DRAM (local)
4 MB Memory (Shared)
Network Interface
16 RJ45 Unshielded Twisted Pair ports (9H532-17) - 10BASE-T/100BASE-TX
16 MT-RJ multimode fiber ports (9H531-17) - 100BASE-FX
Performance
Module Switch Fabric bandwidth 3.3 Gbps
Module Throughput
Source Address Table
2.2 Mpps
16 K entries
Chapter 5
5-1
