LANVIEW LEDs
Green
Yellow (Flashing)
Red
Red (Flashing)
Off
The functions of the Speed and Full Duplex LEDs are list in Table 4-6 and
Table 4-7. These LED indications are only valid when the LED MODE switch is in
the DPX-SPD position.
Green
Yellow
Green
Yellow
4-4
Table 4-5. Ethernet Receive LEDs
LED Color
Link, No activity
Link, Activity (Flashing rate indicates rate of activity)
Port disabled no link
Port disabled with link
No link, No activity
Table 4-6. DPX Status LEDs (9H532-17 only)
LED Color
Port is operating in full duplex mode (20 Mbps or 200
Mbps).
Port is in standard (half duplex) mode (10 Mbps or
100 Mbps).
Table 4-7. SPD LEDs (9H532-17 only)
LED Color
Port is linked and operating at 100 Mbps.
Port is linked and operating at 10 Mbps.
State
State
State
