- Page 1 SmartSwitch 9000 9F241-12 User’s Guide 9031203-01...
- Page 3 Notice Notice Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice.
-
Page 4: Fcc Notice
Notice FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. - Page 5 DECLARATION OF CONFORMITY Application of Council Directive(s): Manufacturer’s Name: Manufacturer’s Address: European Representative Name: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives. Manufacturer Mr.
- Page 6 Notice...
-
Page 7: Table Of Contents
Chapter 1 Introduction Features... 1-1 Related Manuals... 1-4 Getting Help ... 1-4 Chapter 2 Installing the MicroLAN Module Unpacking the Module... 2-1 User-Accessible Components... 2-1 Setting the Module Card DIP Switch ... 2-3 Installing the Module into the SmartSwitch 9000 Chassis... 2-5 The Reset Switch ... - Page 8 Contents...
-
Page 9: Chapter 1 Introduction
The 9F241-12 is ANSI FDDI-compliant with SMT (version 7.3), MAC, PHY, and PMD. This module attaches directly to the SmartSwitch 9000 FNB backplane, delivering up to 400 Mbps of bandwidth. The 9F241-12 module uses the Intel i960 microprocessor for all SMT and local/remote SNMP management functions. - Page 10 With LANVIEW LEDs, you can quickly identify the device, port, and physical layer status at a glance. Hot Swapping The 9F241-12 can be installed or removed from the chassis while the SmartSwitch 9000 is powered up, without affecting the operation of the rest of the network.
- Page 11 FDDI 9F241-12 Figure 1-1. The 9F241-12 module Introduction...
-
Page 12: Related Manuals
SmartSwitch 9000 9C300-1 Environmental Module User’s Guide SmartSwitch 9000 9C214-1 AC Power Supply User’s Guide SmartSwitch 9000 Module Local Management User’s Guide Local Management Appendix for the 9F241-12 Module Getting Help For additional support related to this device or document, contact the Cabletron Systems Global Call... -
Page 13: Installing The Microlan Module
Installing the MicroLAN Module This section describes how to unpack, configure and install the module into the SmartSwitch 9000 chassis. Unpacking the Module 1. Carefully remove the module from the shipping box. (Save the box and packing materials in the event the module must be reshipped.) 2. - Page 14 Installing the MicroLAN Module DIP Switch Figure 2-1. User-Accessible Components SMB-1 PROM i960 Processor Flash SIMM Socket Boot PROM...
-
Page 15: Setting The Module Card Dip Switch
Setting the Module Card DIP Switch An eight-position DIP switch is located on the module card, as shown in Figure 2-1 and Figure 2-2. The functions of the switches are listed in Table 2-1. Figure 2-2. Location of Module DIP Switch Installing the MicroLAN Module... - Page 16 Installing the MicroLAN Module See the Cautions at the end of this table. Switch Caution: Do not toggle Switch 8 unless you intend to reset the user-configured passwords to their factory default settings. CAUTION Caution: Do not toggle Switch 7 unless you intend to reset the user parameters to the factory default settings.
-
Page 17: Installing The Module Into The Smartswitch 9000 Chassis
Installing the Module into the SmartSwitch 9000 Chassis SmartSwitch 9000 MicroLAN Modules can be installed in any of the 14 slots that are available. To install, follow the steps below: 1. Switch off the power supplies and remove all power from the SmartSwitch 9000 chassis. - Page 18 Installing the MicroLAN Module Metal Back-Panel Figure 2-3. Installing the SmartSwitch 9000 Module Module Module Guides Warning: Ensure that the circuit card is between the card guides. Lock down the top and bottom plastic tabs at the same time, applying even pressure. Plastic Tab Jack for ESD Wrist Strap...
-
Page 19: The Reset Switch
The Reset Switch The Reset switch is located on the front panel, under the top plastic tab, as shown in Figure 2-4. It serves two functions: • Pressing the Reset switch twice within three seconds causes the processor (i960) to reset. •... - Page 20 Installing the MicroLAN Module...
-
Page 21: Chapter 3 Operation
Operation The 9F241-12 module, as shown in Figure 3-1, provides concentrator ports that connect directly to the FNB bus. Each port can connect to either ring (FNB-1 or FNB-2). This is software configurable via local or remote management. DC/DC Converter... -
Page 22: System Management Buses
Operation System Management Buses There are two management channels within the SmartSwitch 9000 system: the SMB-1 and the SMB-10. These buses provide out-of-band management and inter- module management communication. SMB-1 Bus The SMB-1 is a 1 Mbps management bus located within the SmartSwitch 9000. This bus is utilized by all diagnostic controllers in the system including connectivity modules, power supply modules and the environmental module. -
Page 23: Dc/Dc Converter
SmartSwitch 9000 modules are designed with one of two attachment policies. One allows dual attachment of a module to either FNB-1 or FNB-2; the second allows dual attachment to both FNB-1 and FNB-2. The 9F241-12 module has a dual attachment to the FNB backplane, connecting to both FNB-1 and FNB-2. The module can insert into the FNB or bypass it. - Page 24 Operation...
-
Page 25: Lanview Leds
The front panel LANVIEW LEDs indicate the status of the module and may be used as an aid in troubleshooting. Shown in Figure 4-1 is the LANVIEW LEDs of the concentrator modules. FNB Receive FNB Transmit FDDI 9F241-12 Figure 4-1. The LANVIEW LEDs Chapter 4 System Status and CPU FDDI Port... - Page 26 LANVIEW LEDs The functions of the System Management Bus (SMB) and the CPU LEDs are listed in Table 4-1. LED Color Green Yellow Yellow/Green Red (Flashing) The functions of the FNB Receive LEDs are listed in Table 4-2. Yellow (Flashing) The functions of the FNB Transmit LEDs are listed in Table 4-2.
- Page 27 There is one FDDI Port LED for each Master port. The functions of the FDDI Port LEDs are listed in Table 4-4. LED Color Green Yellow Red (Flashing) Table 4-4. FDDI Status LEDs State Link, Activity, Port enabled Link, No Activity, Port enabled No link, Port disabled Link, Port disabled No link, No activity, Port enabled...
- Page 28 LANVIEW LEDs...
-
Page 29: Chapter 5 Specifications
Specifications Safety It is the responsibility of the person who sells the system to which the module will be a part to ensure that the total system meets allowed limits of conducted and radiated emissions. CAUTION This equipment meets the following safety requirements: •... -
Page 30: Physical
Specifications Physical Dimensions: 35.0 D x 44.0 H x 3.0 W centimeters (13.8 D x 17.4 H x 1.2 W inches) Weight: Unit: Shipping: Link Distance Up to two kilometers on multimode fiber-optic cable as specified by ANSI MMF-PMD, using SC connectors specified by ANSI LCF-PMD. 1360.7 gr.
