Operation

1. Take out the battery lid. According the sign " + ,-", insert four alkaline batteries or rechargeable batteries to the
battery socket, then cover the battery lid.
2. Set up the instrument on the floor or the tripod. When using tripod, put the bottom part of the instrument on the
tripod. Twist in the screw of the tripod into the centering nut of the instrument.
3. If you hear the sound alarm while turning on the instrument, it means that the inclination of the laser level is more
than ±2°. Adjust the instrument with the help of the instrument legs or tripod.
4. Aim the down point on the selected point on the floor. Move the upper part of the instrument to adjust vertical lines.
Use fine adjustment mechanism for accurate adjustment of the instrument.
5. ADA 3D Liner has several operating modes. Horizontal line is On when turning on the instrument. Press button V to
select the desired operating mode: H/V/2HV/3VH. There is no plumb down in the H mode.
