Operation

1. Take out the battery lid. According the sign " + ,-", insert four
alkaline batteries or rechargeable batteries to the battery socket, then
cover the battery lid.
2. Setting up the instrument on the loor or the tripod. When using tripod,
support the centering nut of the instrument with one hand and screw
the centering screw into the centering nut female thread. Tighten the
centering screw.
3. When the buzzer sounds while turn on the instrument (at the same
time the LED will blink), that means the instrument is over alarm range
based on the ground, please adjust the three leveling screw or tripod.
4. Make the loor point of the instrument aim at object on the loor, line to
aim at object. And then move ine adjustment mechanism and move
upper part of the instrument to roughly adjust vertical to ind objects
correctly.
5. When the instrument inclines over alarm range, because of certain reason during the operation, the laser and the When the instrument inclines over alarm range, because of certain reason during the operation, the laser and the
LED will blink and buzzer sounds at the same time, the laser line gleams. This time, please adjust the three leveling
screws to make the buzzer sound stop.
