FEATURES
1. Vertical laser beam (V) / Horizontal laser beam (H)
2. Detector mode
3. Battery compartment
4. Tripod mount 1/4''
5. Compensator switch (ON/X/OFF)
6. Vertical laser window
7. Horizontal laser window
8. Power socket

SAFETY INSTRUCTIONS

• Please follow up instructions given in operating manual.
• Do not stare into beam. Laser beam can lead to eye injury (even from
greater distances).
• Do not aim laser beam at persons or animals.
• The laser plane should be set up so that the beam path is not at normal
eye level.
• Use the instrument for measuring jobs only.
• Do not open instrument housing. Repairs should be carried out by
authorized workshops only. Please contact your local dealer.
• Do not remove warning labels or safety instructions.
• Keep instrument away from children.
• Do not use instrument in explosive environment.

OPERATION

Cube 360-2V is a reliable and convenient tool. It will be irreplaceable in-
strument for many years.
1. Before use, remove battery compartment cover. Insert three batteries
into battery compartment with proper polarity, then put the cover back.
WARNING: Never use charger for ordinary batteries. Do not leave
the instrument unattended while using charger. Parameters of the
charger must correspond to the parameters of domestic electricity.
Output voltage must be no more than 5V.
2. Set the compensator locking grip (5) into ON position. Horizontal beam is ON.
