3. The slope mode is activated when the pendulum is locked. Set the pendulum
switch (7) up to the (OFF) position. Press and hold button (13) for 2 sec to
activate a slope mode (upper horizontal laser line is ON, indicator is ON, all
switched on laser lines will blink one time per sec.). The tool can be installed
at any angle. Switch On/Off laser lines with the laser line buttons.
Press button (13) to switch off a slope mode. Indicator (14) will be switched off.
4. Press button (12) once. Detector mode is activated. Indicator (11) is ON.
Use a detector for operation in this mode. Follow an operating manual
to use the detector. Press button (12) to switch OFF the detector mode.
Indicator (11) is OFF.
5. Attach the line laser to the tripod with the help of the thread 1/4" on the
upper or bottom part of the tool.

USING THE REMOTE CONTROL

1. To control the functions of the device, the remote control must be paired
with the device. If the remote control does not control the instrument
functions, follow these steps:
• Be sure that the battery is full. If necessary, change it into new one:
unscrew the screws on the back cover of the remote and remove
it. Place new battery, observe the polarity. Screw the cover with the
screws. If you cannot replace the battery yourself, contact the nearest
service center.
• To connect the remote control to the device, unlock the pendulum:
move the pendulum switch (8) to the (ON) position. Press and hold
button (13) for more than 2 sec. Indicator (12) starts blinking frequently.
Press On/Off (2) button on the remote control. Indicator (12) will be
switched off/ The remote will be connected to the line laser.
2. Use the remote control to switch on/off laser lines:
• Press button (2) once – all laser beams on will be turned off. Press
button (2) once again – all laser beams that worked before turning
