PR Lighting PR-2001L Quick Start Manual

Century colour 2500l
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CENTURY COLOUR
2500L
PR-2001L
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
571 Yingbin Road Dashi Panyu Guangzhou 511430, China
http://www.pr-lighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR-2001L and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting PR-2001L

Summary of Contents for PR Lighting PR-2001L

  • Page 1 CENTURY COLOUR 2500L PR-2001L This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. 571 Yingbin Road Dashi Panyu Guangzhou 511430, China...
  • Page 2 SECTION PAGE SAFE USAGE OF THE PROJECTOR CONSTRUCTION FITTING THE LAMP POWER SUPPLY – MAINS OPERATION STAND-ALONE MODE XLR CONNECTIONS AND TERMINATOR MASTER/SLAVE SYNCHRO MODE CONTROLLER MODE - DMX OPERATION MAINTENANCE KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING TECHNICAL DATA ELECTRICAL DIAGRAM Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice.
  • Page 3 The following points are important for safety as well as for the smooth installation and performance of the unit. When unpacking and before disposing of the package check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus.
  • Page 4 Position the projector-head in vertical position and lock it via locking knob. Remove the projector-head cover by loosening the 4 retaining-clips. Open the dichroic-colour-filter bracket by undoing the 2 M4 knurled-screws. Insert the lamp in the lamp-holder, and ensure the little bubble on the lamp is at a right angle (90°) to the beam path.
  • Page 5 When the power is switched on, the apparatus automatically starts to run the programmes of self test. After finishing these, the apparatus is ready for operation. Remove the cover of the control panel, you will see the DIP switches with numbers from 1 to 4, and 3 rotary DIP switches for setting the start address and an LED display as shown in the figure below.

  • Page 6: Xlr Connectors

    Without connecting the controller, regulating the DIP switch as shown right, the apparatus will run in stand-alone mode. In stand-alone mode, you should only regulate the values of the rotary DIP switches with the tens and units, and then press the RESET button. After 30 seconds, the appratus will run automatically the selected one program of the 15 bulit-in programmes.

  • Page 7: Dmx Terminator

    DMX TERMINATOR In the Controller mode or Master/Slave mode, the DMX output has to be connected with a DMX terminator at the last fixture in the chain. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120 (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain.

  • Page 8: Dmx Control Channel Functions

    Century Colour adopts international standard DMX 512 protocol. You may use controller to control many luminaires via regulate the rotary DIP switches. (For detail please refer to “DMX start address setting table”.) Regulate all DIP switches as shown in the figure on the right.
  • Page 9 DMX START ADDRESS SETTING TABLE FOR 3 ROTARY DIP SWISHES The following table lists the address codes setting from 1 to 80 lumanaires. (Actually, the 3 rotary DIP switches may set address of 167 luminaires in all.) The setting way is to turn the 3 tuning- wheel switches to let the arrows of the switches allign respectively to values as shown in the following table.

  • Page 10: Light Output

    If the lamp becomes damaged or deformed in any way it must be replaced. If the light from the lamp appears dim this would normally indicate that it is reaching the end of its life and it should be changed at once, old lamps run to the extremity of their life can explode. If the projector does not function, check the fuse in the projector base, it should only be replaced by fuse of the same specified value 16A/380V (fast blow, ceramic).
  • Page 11 Power supply: 230V AC 50Hz Optional: 240V, 220V AC 50/60Hz Power consumption: 2800W at 220V Lamp: MSA2500 DE, double ends Colour temperature: 5600°K Manufacturers Rated Lamp life: 2000 Hours Protocol: Standard DMX 512 Running mode: Stand-alone, Master/Slave, and DMX Controller DMX channels: 6 channels Colours:...
  • Page 12 12/14...

  • Page 13: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. REMARK TRANSFORMER 040030022 230V/50Hz IGNITOR 040090004 230V/50Hz BALLAST 040070033 230V/50Hz RELAY 192010009 230V/20A FILTER 193020001 THERMOSTAT(2 pcs) 190010054 95 /10A FAN (4 pcs) 030069002 230V/23-24W LAMP FOR CENTURY COLOUR 2500 100050026 MSI 2500W LAMP FOR CENTURY COLOUR 2500L 100050042 MSA 2500 DE CAP (3 pcs)
  • Page 14 PR LIGHTING LTD 571 Yingbin Road Dashi Panyu Guangzhou 511430, China TEL: +86 (20) 8478 1888 FAX: +86 (20) 8478 6023 P/N: 320040043 Last Revision: 09:08:2003 14/14...
