CHAMELEON
PR-2012H
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
PR LIGHTING LTD.
Yingbin Road, Dashi Panyu, Guangzhou, 511430 China
h t t p : / / w w w . p r- l i g h t i n g . c o m
Advertisement
Table of Contents
Related Manuals for PR Lighting CHAMELEON PR-2012H
Summary of Contents for PR Lighting CHAMELEON PR-2012H
- Page 1 Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. Yingbin Road, Dashi Panyu, Guangzhou, 511430 China h t t p : / / w w w . p r- l i g h t i n g . c o m...
-
Page 2: Table Of Contents
INDEX SECTION PAGE SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING THE LAMP POWER SUPPLY – MAINS OPERATION XLR CONNECTORS AND TERMINATOR STAND-ALONE MODE MASTER/SLAVE SYNCHRO MODE CONTROLLER MODE - DMX OPERATION MAINTENANCE KEEPING THE PROJECTOR CLEAN TROUBLE SHOOTING TECHNICAL DATA ELECTRICAL DIAGRAM Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change... -
Page 3: Safe Usage Of The Projector
SAFE USAGE OF THE PROJECTOR The following points are important for safety as well as for the smooth installation and performance of the unit When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Keep the carton well for future possible transportation. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. -
Page 4: Installing The Projector
INSTALLING THE PROJECTOR This unit has been designed to be hung. Mount the bracket provided on the body of the projector. There are 2 M8 knobs provided to tighten the body and the bracket. When you want to adjust the angle of the body of the projector, you only loosen the two M8 knobs carefully and then adjust the angle of the body. -
Page 5: Operation
OPERATION The projector can be controlled by sound, auto-programmes or a controller, and can be operated in Stand-Alone mode, Master/Slave synchro mode or Controller mode. When the power is on, the projector will reset automatically for operation. TO SET THE ADDRESS OF DIP SWITCHES The DIP switch of the CHAMELEON has 10 switches with the number from 1 to 10, which may be set on the “... -
Page 6: Stand-Alone Mode
STAND-ALONE MODE Without connecting a controller with the projector, the projector will run in Stand-Alone mode controlled by sound or auto programmes via setting the DIP switch as shown below. When sound activating, the projector will change the colours according to the rhythm of the music. You may rotate the audio sensitivity controller for the best receiving sound signal. -
Page 7: Controller Mode - Dmx Operation
CONTROLLER MODE – DMX OPERATION DMX512 CONTROL CHANNEL FUNCTIONS CHAMELEON has 2 channels and uses DMX 512 control protocol. They are listed in the following table. CHANNEL DMX 512 VALUE DESCRIPTION 0 - 16 Black-out 17 - 33 Strobe 34 - 50 White 51 - 67 Cyan... - Page 8 TABLE FOR SETTING ADDRESS OF DIP SWITCHES The following table lists the setting codes of the address of the DIP switches, and the luminaires are from No.1 to No. 256. Each DIP switch has 10 switches with the number of #1, #2, #3, #4, #5, #6, #7, #8, #9 and #10.
-
Page 9: Maintenance
MAINTENANCE If the projector’ s lens becomes damaged or broken it should be replaced. If the lamp becomes damaged or deformed in any way it must be replaced. If the light from the lamp appears dim this would normally indicate that it is reaching the end of its life and it should be changed at once, old lamps run to the extremity of their life can explode. -
Page 10: Technical Data
TECHNICAL DATA Power supply: 230V AC 50Hz Optional: 240V, 220V, 200V, 120V, 100V AC 50/60Hz Power consumption: 280W at 220V Lamp: ELC-7/X 24V/250W Channels: 2 channels Control signal: Standard DMX 512 Control mode: Sound activation / Auto programmes / Controller Running mode: Stand-Alone mode / Master/Slave synchro mode / Controller mode Colours:... -
Page 11: Electrical Diagram
ELECTRICAL DIAGRAM Chameleon manual.doc 11/12... -
Page 12: Component Order Codes
170040009 TTL LOGICAL CHIP 170050002 ARITHMETIC AMPLIFIER CHIP 170170038 DRIVER CHIP 230040026 MICROPROCESSOR 1 230040019 SPECIAL CHIP PR LIGHTING LTD. Yingbin Road, Dashi, Panyu, Guangzhou, China Post-Code: 511430 TEL: 020-8478-1888 FAX: 020-8478-6023 P/N: 321010111 Last Revision: 19:03:2003 Chameleon manual.doc 12/12...
