- Page 1 XR130 Beam PR-2133 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
-
Page 2: Table Of Contents
INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING THE LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS OPERATION MENU ERROR MESSAGE REPLACING GOBOS DMX PROTOCOL LED INDICATION MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING... - Page 3 SAFE E USAGE E OF THE PROJEC CTOR When unpackin ng and before d disposing of the carton check th here is no transp portation dama age before using g the projector. Should there be any damage cau used by transpor rtation, consult your dealer and d do not use the...
-
Page 4: Control Panel
INSTALL THE PROJECTOR Safety Cord WARNING Please run safety cord through safety hook Safety Hook Digital Handle Control Panel Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp. -
Page 5: Fitting The Lamp
FITTING THE LAMP Lock the yoke before fitting/replacing the lamp just as Shown by Figure 2, after Opening the head’s cover of a projector by loosening 4fastfit screws. Pull out the lamp from the bottom of the head after rotating it anti-clockwise after holding the lamp’s bottom. Installation and removal are in reverse orders. -
Page 6: Power Supply – Mains
POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Before connection with mains power, make sure that the voltage and frequency marked on the rating plate of the projector match what are supplied. It is recommended that each projector be supplied separately so that they may be individually switched on and off. NOTE: If the fixtures’... -
Page 7: Dmx Terminator
DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain. -
Page 8: Operation Menu
OPERATION MENU First Menu Secondary Menu Third Menu Fourth Menu DMX Address Short 1～501 （XXX:1~497） Standard 1～497 Reset Are You Sure Standard16 DMX Channel Mode （Default：Standard） Short 12 When DMX is Lost Normal Time out Loss of DMX When DMX is Lost Hold Last value By Control Channel Config Settings... - Page 9 Lamp Hours Hours：xx Reset Lamp Hours Are You Sure Total Hours Hours：xx Temperature Temperature XX℃ Display Board= Information Display Board X.X.X Software Version Fan Board= Fan Board X.X.X DMX Channel View DMX Values 1=XXX Electronic SN= Electronic SN ******** Test Modes Self Test Turn Lamp On Lamp Manual Control...
-
Page 10: Error Message
ERROR MESSAGES In the course of launch, Projector examines automatically whether there are errors and if there are, it will display information as follows: Head Fan 1 Fail Head Fan 2 Fail REPLACING GOBOS Disconnect from power ,loosen 4 fastfit screws of the side cover, and open the cover as shown by the figure below. Replace an old gobo of the rotating gobo wheel with a new gobo. -
Page 11: Dmx Protocol
DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode Mode Close 000-010 011-025 Open 026-225 Strobe speed from slow to fast Strobe Macro 1 226-239 240-241 Macro 2 Macro 3 242-246 Open 247-255 000-255 Dimmer Linear dimming White 000-008 009-016 Color 1 017-024 Color 2... - Page 12 Shake of Gobo 2 from slow to fast 176-183 184-291 Shake of Gobo 3 from slow to fast 192-199 Shake of Gobo 4 from slow to fast 200-207 Shake of Gobo 5 from slow to fast 208-215 Shake of Gobo 6 from slow to fast 216-223 Shake of Gobo 7 from slow to fast 224-231...
-
Page 13: Led Indication
LED INDICATION DMX signal OK Green LED indication No DMX signal Flash DMX signal error Wireless Signal OK Blue LED indication Not linked with any transmitters Flash Loss of connection or being linked with a transmitter MAINTENANCE If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes damaged or deformed in any way it must be replaced. -
Page 14: Technical Data
TECHNICAL DATA VOLTAGES: 100V~240V AC，50/60Hz POWER CONSUMPTION: 240W@220V LAMP: OSRAM SIRIUS HRI 132W 8800K Colour Temperature 6000hours Manufacturers Rated Lamp Life COLOURS: 1 Color Wheel:13colors + CTO +white Optional Stepping/linear color changing ROTATING GOBO WHEEL 1Rotating Gobo Wheel: 11 gobos(8pcs rotatable)+ white Shake effects with variable speeds, bi-directional wheel scrolling at variable speeds Gobos replaceable Gobos’... - Page 15 CONTROL: DMX512, 3-pin and 5-pin interfaces RDM Protocol 12 channels in short mode, 16channels in standard mode Self-test mode OTHER FUNCTIONS: Adjustable Pan & Tilt speed The display for the fixture’s and the lamp’s hours respectively English and Chinese LCD display with its brightness and contrast adjustable Energy saving ballast Auto-Diagnosis by Sensors Isolated Input DMX signal...
- Page 16 SIZES: 303.6 PR-2133 PR-2133 XR 130 Beam XR 130 Beam LIGHT OUT: 416352 104088 46261 26022 16654 11565 3.0 °lux Disrance( m ) 3.0 ° Diameter( m ) 0.27 0.54 0.81 1.08 1.35 1.62 16/20...
-
Page 17: Electrical Diagram
Electrical Diagram: 17/20... - Page 18 omponent Order Code NAME PART NO. QUANTITY REMARK PAN MOTOR 030040174 TILT MOTOR STROBE MOTOR 030040220 COLOR WHEEL MOTOR ROTATING GOBO WHEEL MOTOR 030040222 GOBO ROTATION MOTOR 030040236 PRISM ROTATION MOTOR EFFECT WHEEL MOTOR 030040154 FOCUS MOTOR 030040116 TURBO- FAN 030060072 LAMP FAN 030060055...
- Page 19 19/20...
- Page 20 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020264 Version: 20150127 (Preliminary） 20/20...
