XR 230 Beam
PR-2205
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR 230 Beam and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting XR 230 Beam

Summary of Contents for PR Lighting XR 230 Beam

  • Page 1 XR 230 Beam PR-2205 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
  • Page 2 INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS STAND-ALONE MODE MASTER/SLAVE MODE OPERATION MENU DMX PROTOCOL INDICATION OF LED DIGITAL TUBE MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN...

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check if there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20.

  • Page 4: Fitting The Lamp

    INSTALL THE PROJECTOR SAFETY CORD WARNING CLAMP To pass 1 SAFETY CORD through 2 holes for safety CONTROL PANEL HANDLE Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to each clamp.

  • Page 5: Power Supply-Mains

    POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Use the plug provided to connect the mains power to the projector paying attention to the voltage and frequency marked on the panel of the projector.

  • Page 6: Dmx Terminator

    DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain.

  • Page 7: Standalone Mode

    STAND-ALONE MODE Operate the projector without connecting a controller, enable the master mode in the operation panel, the projector will run in Stand-Alone mode automatically. MASTER/SLAVE MODE Without using a controller, many projectors can run synchronously in the Master/Slave mode by linking them with each other.

  • Page 8: Operation Menu

    OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL AddR (1~499) Reset Are you sure STd 14 CNFG (DMX Mode (DMX Mode Standard) ,Default: STD) (Config Settings) SHRT 10 (DMX Mode Short) EXT 16 (DMX Extended Mode) Lamp Control Set ByControlChanne (Lamp Control (By Control Channel)
  • Page 9 Self Test TEST Strobe (Without Strobe) Mode 1 Mode 2 Color Wheel (White) Cw1-CW14 (Color Wheel1-Color Wheel14) FORw (Rotation) STOP (Rotation Stops) REVE (reverse Rotation) Fixed Gobo Wheel Manual Test (White)_ Gobo1-Gobo17 Rotation Reverse Rotation Shake Effect 1-10 (Test Modes) Effect Wheel Effect 1 Effect 2...
  • Page 10 0-255 (Dimming) 0-255 (Color Wheel) 0-255 (Fixed Gobo Wheel) 0-255 (Effect Wheel) 0-255 (Effect Wheel Rotation) 0-255 (Focusing) 0-255 (Pan Location) 0-255 (Tilt Location) CH10 0-255 (Pan and Tilt Speeds) CH11 0-25 Seconds Scene hold time Turn Lamp On Lamp Manual Control Turn Lamp Off Remark: 1.

  • Page 11: Dmx Protocol

    DMX PROTOCOL Short Standard FUNCTION DESCRIPTION mode mode Open 000-015 Strobe from Slow to Fast 016-239 Strobe Macro 1 240-244 Macro 2 245-249 Macro 3 250-255 Dimmer From dark to bright 000-255 000-011 White 012-015 White+Color 1 016-019 Color 1 020-023 Color 1+Color 2 024-027...
  • Page 12 000-007 White 008-015 Gobo 1 016-023 Gobo 2 024-031 Gobo 3 032-039 Gobo 4 040-047 Gobo 5 048-055 Gobo 6 056-063 Gobo 7 064-071 Gobo 8 072-079 Gobo 9 Fixed Gobo 080-087 Gobo 10 Wheel 088-095 Gobo 11 096-103 Gobo 12 104-111 Gobo 13 112-119...
  • Page 13 Tilt Fine 000-255 Tilt in 16 bit precision Pan & Tilt 000-255 Pan & Tilt Speed from Fast to Slow Speeds Reserved 000-031 032-063 Lamp Off (stop in DMX value for 2 s) 064-095 Reserved Lamp On ( stop in DMX value for 2 s) 096-127 Reserved 128-159...
  • Page 14 120-123 Color 14 124-127 Color 14/White 128-255 Rotation （From slow to Fast） Open 000-003 Strobe from Slow to Fast 004-103 104-212 Open Strobe 213-225 Macro1 226-238 Macro 2 239-251 Macro 3 251-255 Open Dimming 000-255 From dark to Bright 000-003 White 004-007 Gobo 1...
  • Page 15 212-217 Shake 9（From Fast to slow） 218-223 Shake 10（From Fast to slow） 224-255 Stop at White 000-127 White Effect Wheel 128-255 Eight-facet Prim 000-127 Stop Rotation （From Fast to Slow） 128-190 Prism Rotation Stop 191-192 193-255 Reverse Rotation （From slow to Fast） Reserved 0-255 0-127...

  • Page 16: Indication Of Led Digital Tube

    INDICATION OF LED DIGITAL TUBE DMX signal OK Decimal point of the first digital tube No DMX signal Master / slave signal is OK Decimal point of the third digital tube No master / slave signal When setting master mode Decimal point of the fourth digital tube When setting slave mode Parameters that LED digital tubes display...

  • Page 17: Troubleshooting

    TROUBLESHOOTING PROBLEM ACTION Check the fuse on the power socket. The projector doesn’t switch on Replace the lamp. The lamp comes on but the projector doesn’t Make sure that the fixture’s start address is right respond to the controller Replace or repair the XLR singal cable. The projector only functions intermittently Make sure the fan is working well or fans and their filters not blocked Make sure the lamp is within its life limit...

  • Page 18: Technical Data

    TECHNICAL DATA VOLTAGES: 100V/200V/220V/230V/240V AC，50/60Hz POWER CONSUMPTION: 310W@220V LAMP: Osram SIRIUS HRI 230W Colour Temperature 8000°K 2000Hours Manufacturers Rated Lamp Life COLORS: 1 Color Wheel 14 dichroic colour filters plus white variable speed and bi-directional rainbow effect linear colour changing is available GOBOS: 1 Fixed gobo wheel : 17 interchangeable gobos+ white...
  • Page 19 10 channels in short mode, 14channels in standard mode, 16modes in Extended Mode Self-test mode OTHER FUNCTIONS: Adjustable Pan & Tilt speed Fixture and lamp usage time display HOUSING: Composite plastic, IP20 WEIGHT: 16Kg SIZES: LIGHT OUTPUT 68600 1097600 274400 121956 43904 30489...
  • Page 20 AC-IN...

  • Page 21: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 230W BALLAST 040070112 100070029 230W LAMP 190010133 200W POWER SWITCH 190010116 400W POWER SWITCH 270041065 T20A250V 6.3*32mm FUSE 290151322 HTD-531-3M PAN DRIVER BELT TILT DRIVER BELT 290151331 HTD-399-3M 290151255 HTD-270-3M PRISM WHEEL BELT 290151310 72MXL FOCUSING BELT...
  • Page 22 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020239 Version: 20150327(Preliminary) 22/22...
