XR 380 BWS
PR-2393A
The user manual contains important information about the safe installation and use of a projector. Please read and
follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR 380 BWS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting XR 380 BWS

Summary of Contents for PR Lighting XR 380 BWS

  • Page 1 XR 380 BWS PR-2393A The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.

  • Page 2: Table Of Contents

    Any future technical change in the user manual won’t be with any notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty...

  • Page 3: Safety And Warnings

    1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Warning Goggles Flames Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.

  • Page 4: Instructions

    Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other ● electrical parts’ life will be shortened . There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord ●...

  • Page 5: Appearance

    ●TROUBLESHOOTING PROBLEM ACTION  Check the fuse on the power socket. The projector doesn’t switch on  Check the lamp.  The lamp is on but the projector doesn’t respond Make sure that the fixture’s start address is right  to the controller Replace or repair the XLR signal cable.
  • Page 6 Use the spanner supplied with a projector to help installation. WARNING: The projector MUST be lifted or carried by the HANDLES instead of clamps. ● .For safety the safety cord should afford 10 times the Projector’s weight. ●...
  • Page 7 It must use secondary safety accessory like appropriate net. The structures of the secondary accessory must ensure that while malfunction happens, the installed parts won’t fall to the ground. While rigging, mounting or maintaining, the projector mustn’t be placed in the areas listed hereinafter: the bridge, high work areas or other dangerous areas.
  • Page 8 POWER IN POWER OUT DMX IN DMX OUT POWER IN POWER OUT DMX IN DMX OUT POWER IN POWER OUT DMX IN DMX OUT FUSE 250V 8A FUSE 250V 8A FUSE 250V 8A DMX512 OUTPUT INPUT OUTPUT INPUT terminator ●DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator.
  • Page 9 ● GOBO REPLACEMENT 1. Disconnect the projector with mains power and let it cool 2. After loosening 4 1/4 fasteners of the head cover, remove it 3. Gently pull the gobo holder(3) from rotating gobo wheel upward. 4. Use appropriate tool like flat screwdriver of small size to remove spring lock(1). Do not use bare hand to touch pattern side of the gobo.

  • Page 10: Setup And Configuration

    5. SETUP AND CONFIGURATION ●FRONT PANEL OPERATION To browse through or view a projector’s function settings, push any key to activate the screen after power-on.. After screen unlocked, push both key and to enter into menus. Each main menu has its sub-menus with different special functions, for details please see the 5 point hereinafter OPERATION MENU.

  • Page 11: Operation Menu

    MASTER SLAVE SLAVE POWER IN POWER OUT DMX IN DMX OUT POWER IN POWER OUT DMX IN DMX OUT POWER IN POWER OUT DMX IN DMX OUT FUSE 250V 8A FUSE 250V 8A FUSE 250V 8A OUTPUT INPUT OUTPUT INPUT terminator 6.
  • Page 12 2）Push UP or DOWN key to select either of the options.3） Push ENTER key to save the selected. PUSH ESCAPE key to cancel the setting. GOBO1 GOBO2 1）Push ENTER key and the quantity of the shift will be GOBO3 shown on the display GOBO GOBO4 2）Push UP or DOWN key to set the shift quantity.

  • Page 13: Dmx Protocol

    Cancel Select“Channel control”options 1）Push ENTER key and the option will be shown on the display（all DMX channels） Channel 2）Push UP or DOWN key to enter into any of the DMX Channel control options(adjustable between 0 and 255). 3）Push ENTER key to save the selected. PUSH ESCAPE key to cancel the setting.
  • Page 14 Tilt Fine 0-255 0-100% Pan and Tilt speed 0-255 Fast ->Slow Strobe Close 4-103 Strobe: Slow->Fast 104-107 Open 108-207 Pulse strobe: Slow->Fast 208-212 Open 213-225 Strobe at random: slow speed 226-238 Strobe at random: medium speed 239-251 Strobe at random: fast speed 252-255 Open Dimmer...
  • Page 15 Effect wheel Open Flowing water effect ：Slow->Fast 10-255 Fixed gobo wheel Open GOBO1 10-14 GOBO2 15-19 GOBO3 20-24 GOBO4 25-29 GOBO5 30-34 GOBO6 35-39 GOBO7 40-44 GOBO8 45-49 GOBO9 50-54 GOBO10 55-61 GOBO1 SHAKE: Slow->Fast 62-68 GOBO2 SHAKE: Slow->Fast 69-75 GOBO3 SHAKE: Slow->Fast 76-82 GOBO4 SHAKE: Slow->Fast...
  • Page 16 150-202 Clockwise rotation: Fast->Slow 203-255 Anti-clockwise rotation: slow->fast GOBO Rotation 0-127 Positioning:0-360° 128-191 Clockwise rotation: Fast->Slow 192-255 Anti-clockwise rotation: slow->fast 16 facet prism 0-127 128-191 Prism 1 in 192-255 Prism 2 in 16 facet prism rotation 0-127 0-360° 128-191 Clockwise rotation: Fast->Slow 192-255 Anti-clockwise rotation: slow->fast 8 facet prism...

  • Page 17: Error Message

    8. ERROR MESSAGE Name Type Correction Optical sensor error: Pan Check if wiring, optical sensor and motors are normal Optical sensor error: Tilt Check if wiring, optical sensor and motors are normal Tilt Communication error: module1 Check if wiring, hall sensor and motors are normal Pan &...
  • Page 18 ROTATING GOBO WHEEL 1 rotating gobo wheel:7 gobos +open Gobo diameter Ф12.5mm, 2.2mm thick PRISM/FROST 1 8-facet prism and 1 16-facet prism, bi-directional rotation from slow to fast FOCUS DMX linear focus DIMMER /STROBE Strobe at variable speeds(15 F.P.S at maximum) 0-100% linear dimmer HEAD MOVEMENT Pan 540º...
  • Page 19 International standard DMX 512 protocol, 5-pin interface 19channels in short mode and 23channels in standard mode OPTIONAL WIRELESS CONTROL MODULE/RDM MODULE USITT DMX-512（1986 and 1990）and 512-A Full DMX for fidelity and DMX framing integrity Compliant with Auto-detecting DMX framing size and speed <5ms DMX delay Frequency range 2402-2480 MHz HOUSING...

  • Page 20: Circuitdiagram

    10. CIRCUITDIAGRAM...

  • Page 21: Component Order Codes

    11. COMPONENT ORDER CODES Name Code No. Remarks Pan Motor GL3802DY01 Tilt Motor GL3802DY02 GL3803TA01; GL3802TA03; GL3803TA02; Rotating gobo wheel 7 glass gobos GL3802TA01; GL3803TA03; GL3803TA04; GL3803TA05; GL3801YSP01; GL3801YSP02; GL3801YSP03; GL3801YSP04; GL3801YSP05; 11colors, each code no. stands for GL3801YSP06; Color wheel one color GL3801YSP07;...

  • Page 22: Appendix

    APPENDIX: SOME ITEMS REQUIRING ATTENTION AS FOR THE USE OF DISCHARGE LAMP For the effective extension of the lifespan of discharge lamp, some factors impacting its lifespan are specially listed below, based on manufacturing technology and working mechanism of discharge lamps., physical attributions of the lamps including lamp striking theory( ignited by focused high voltage---highly pressurized air broken down and burning---lamp on at high temperature with thermal protection--- stable running) and lamp off theory( lamp off power ---lamp off at high temperature and thermal protection-highly pressurized air vaporizing evenly----completion of lamp...
  • Page 24 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320021377...
