AQUA 580 BWS
PR-2597
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA 580 BWS and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting AQUA 580 BWS

Summary of Contents for PR Lighting AQUA 580 BWS

  • Page 1 AQUA 580 BWS PR-2597 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.

  • Page 2: Table Of Contents

    / or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.

  • Page 3: Safety And Warnings

    1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Warning Electrical Protective Flames High Goggles Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.

  • Page 4: Instructions

    cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ● power mains. ℃.After stable operation , After running for 30minutes, the temperature of the housing of the projector is ●...

  • Page 5: Troubleshooting

    TROUBLESHOOTING ● PROBLEM ACTION  Check the fuse on the power socket. The projector doesn’t switch on  Check the lamp. The lamp is on but the projector doesn’t respond  Make sure that the fixture’s start address is right ...

  • Page 6: Installation

    4. INSTALLATION RIGGING ● Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a projector with power while it is locked. Safety Cord Warning Please run the safety cord through the two safety cord holes to ensure safety safety Clamp cord holes...

  • Page 7: Dmx Control Connections

    DMX CONTROL CONNECTION: ● Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.

  • Page 8: Alignment/Installation/Replacement Of A Lamp

    ALIGNMENT/INSTALLATION/REPLACEMENT OF A LAMP ● Please hold the projector well before adjustment/installation/replacement of a lamp. As shown in figure1, remove fan cover of the head and heat sink. Removal/Installation of lamp as shown in figure2 Adjust the lamp as shown in figure3 Before the removal of the lamp, unplug the lamp wires.

  • Page 9: Setup And Configuration

    DANGER! Before replacement of gobos, the projector must be off the power. 5. SETUP AND CONFIGURATION FRONT PANEL OPERATION ● To browse through or change the projector ’s settings, press ENTER key for more than 3s(press ENTER key after power on) to key to enter the projector ’s function menus.

  • Page 10: Stand-Alone Mode

    STAND-ALONE MODE ● Operate the projector without connecting with a controller, enable the master mode through the operation panel, the projector will run in Stand-Alone mode automatically. DMX address can be set at any number within 512. MASTER/SLAVE MODE ● Many projectors can run synchronously in the Master/Slave mode by linking them with each other.
  • Page 11 Really Reset? Dimmer/Shutter reset Confirm or Cancel Really Reset? Zo.Fo. Fr. Pr. Reset Confirm or Cancel Short Mode Standard Mode DMX Channel Mode Extended Mode Ch.01 Strobe Ch.02 Dimmer View Selected Mode ..Ch.23 Control Function Lamp Control OFF/ ON On By Power On OFF/ ON Lamp Control...
  • Page 12 English\Chinese Language Setting Celsius Degree Temperature Unit Fahrenheit Degree Un-Link Wireless Really Un-Link? Confirm or Cancel Restore Defaults? Defaults Confirm or Cancel Pan DMX Invert OFF/ ON Tilt DMX Invert OFF/ ON Pan Tilt Swap OFF/ ON XY Feedback OFF/ ON Note: "Speed Mode"...
  • Page 13 Focus Focus Fine Zoom Zoom Fine Tilt Pan/Tilt Speed & Time XXX Power/Special Fun. XXX XXX H Lamp Hours Reset Lamp Hours Total Hours × × × × Display Board= × × × C Pan & Tilt board × × × C Driver Board1 ×...
  • Page 14 Prism 1 Rotation XXX Prism 2XXX Prism 2 Rotation XXX Focus XXX Focus Fine XXX Zoom XXX Zoom Fine XXX Pan XXX Pan Fine XXX Tile XXX Tilt Fine XXX Pan & Tilt Speed &Time Control Function XXX Position Calibrations …...
  • Page 15 Prism 1 Rotation XXX Prism 2XXX Prism 2 Rotation XXX Focus XXX Focus Fine XXX Zoom XXX Zoom Fine XXX Pan XXX Pan Fine XXX Tile XXX Tilt Fine XXX Pan & Tilt Speed &Time Control Fun. Delay Time XXX Delay time unit msec/s/m Link to Step XXX Strobe XXX...

  • Page 16: Dmx Protocol

    Open: the lamp is affected by the lamp fan. If the lamp fan fails, the lamp won’t be on. Close: the lamp is not affected by the lamp fan. Even if the lamp fan is not installed, the lamp will be on, but Pan and Tilt are without force .
  • Page 17 109-113 Color10(UV) 114-118 Color11(Light Yellow) 119-123 Color12(Dark Yellow) 124-127 White 128-191 Rotation ,Clockwise from slow to fast 192-255 Rotation, Anti-clockwise from fast to slow Color Wheel Fine 0000-255 Color Wheel in 16 Bit 000-019 White 020-025 Gobo1 026-031 Gobo2 032-037 Gobo3 038-043 Gobo4...
  • Page 18 248-251 Shake effect 17 from slow to fast 252-255 Shake effect 18 from slow to fast 000-015 White 016-031 Gobo1 032-047 Gobo 2 048-063 Gobo 3 064-079 Gobo 4 080-095 Gobo 5 096-111 Gobo 6 112-127 Gobo 7 Rotation （clockwise From slow to Fast） Rotating Gobo 128-156 Wheel l...

  • Page 19: Signs On The Touch Screen

    Stop 193-255 Rotation(Anti- Clockwise from slow to fast) 000-09 Frost 010-255 Frost In 000-255 Focus Linear Focus 000-255 Focus Fine Focus in 16 bit precision 000-255 Zoom Linear Zoom 000-255 Zoom Fine Zoom in 16 bit precision 000-255 Pan(0° ~540° ) Pan Fine 000-255 Pan in 16 bit...

  • Page 20: Error Messages

    Chinese-English Information Error messages Service Operation Mode Address Reset User Memories Config Settings 9. ERROR MESSAGES The system can detect some errors during the reset, if displayed, touch ENTER to view the error. The error messages are as follows: Name Type Correction Timeout/magnet Sensor/Encoder...

  • Page 21: Technical Data

    Driver Board 1 Error Check signal wire Driver Board2 Error Check signal wire Driver Board3 Error Check signal wire Acceleration Sensor Error Check signal wire Lamp on Timeout Check if he lamp is damaged Lamp Life Timeout Warning Lamp Off[Fan Error Check if all fans are normal Error]...
  • Page 22 Color 9 Color 10 Color8 Color 11 Color 7 Color 12 Color 6 Open Color 5 Color 1 Color 4 Color 2 Color 3 Code No. Colors 092550001A 092550002 A Light Green 092550003 A Blue 092550004 A Cyan 092550005 A Yellow 092550006 A Magenta...
  • Page 23 Gobo15 Gobo16 Gobo17 ROTATING GOBO WHEEL 1 Rotating gobo wheel: 7Interchangeable Gobos +Open Bi-directionally rotatable, and shakable at variable speeds Gobo Replaceable, Gobo diameter: Φ22.5mm ,Gobo image diameter: Φ12mm Gobo1 Gobo 2 Gobo 3 Gobo 4 Gobo 5 Gobo 6 Gobo 7 PRISM 4 pcs of prisms which can be overlapped (8 facet circular prism+ 4facet linear prism) (9 facet circular prism+ gradient prism) And other...
  • Page 24 DIMMER/STROBE 0-100% Linearly adjustable/ Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT Pan 540º , Tilt 270º with auto position correction BEAM ANGLE Beam Mode: 0° -- 2° Spot Mode: 2° -- 40° , Linear Adjustment Wash Mode: 3° -- 50° , Linear Adjustment CONTROL DMX512 5- pin interfaces(Optional 3-pin)

  • Page 25: Circuit Diagram And Pcb Connections

    LIGHT OUTPUT Beam/Spot Mode 1905 40° Lux 7618 2.0° Lux 231190 130045 2080712 520178 57798 83228 Distance (m) Diameter (m) 1.07 0.18 0.89 0.36 0.54 0.72 Diameter (m) 21.53 3.59 17.94 7.18 10.76 14.35 Wash Mode 1290 50° Lux 5161 3°...

  • Page 27: Pcb Connections

    PCB CONNECTIONS ● 8-Channel SLAVE1 ：P/N230060762 8 Channel Driver Board 1 M1-1 Motor 24V Input M1-2 Motor Reserved M1-3 Motor Reserved M1-4 Motor HALL1-6Magnet Sensor M1-5 Motor HALL1-5 Magnet Sensor M1-6 Motor HALL1-4 Magnet Sensor Reserved HALL1-3 Magnet Sensor Reserved HALL1-2 Magnet Sensor Reserved HALL1-1 Magnet Sensor...

  • Page 28: Component Order Codes

    12. COMPONENT ORDER CODES NAME PART NO. QTY. REMARKS STEPPER MOTOR 030040073B STEPPER MOTOR 030040114C STEPPER MOTOR 030040121A STEPPER MOTOR 030040136B STEPPER MOTOR 030040167A STEPPER MOTOR 030040212B STEPPER MOTOR 030040213B STEPPER MOTOR 030040246A STEPPER MOTOR 030040254A STEPPER MOTOR 030040221C STEPPER MOTOR 030040224C STEPPER MOTOR 030040257A...
  • Page 30 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020805...
