XR 1400 WASH/FRAMING

PR-2736

The user manual contains important information about the safe installation and use of a projector. Please read

and follow these instructions carefully and keep the manual in a safe place for future reference.

PR LIGHTING LTD.

http://www.pr-lighting.com

1/26

Table of Contents

Need help?

Do you have a question about the XR 1400 WASH/FRAMING and is the answer not in the manual?

Questions and answers

Summary of Contents for PR Lighting XR 1400 WASH/FRAMING

Page 1 XR 1400 WASH/FRAMING PR-2736 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.
Page 2 Any future technical changes in the user manual won’t be with any further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.
Page 3: Safety And Warnings
1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Warning Flames Goggles Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.
Page 4 There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ● cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ●...
Page 5 3. APPEARANCE Fresnel lens Front Cover of the head front and back covers of the head U arm cover Pan Lock handle in the base Front side cover of the head Tilt lock Back side cover of the head lamp cove During transportation, the head should be locked-Pan lock (5) and Tilt Lock(6) should be in LOCK position.
Page 6: Installation
4. INSTALLATION RIGGING ● Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a projector with power while it is locked. safety cord warning clamp please run the safety cord through safety cord hole for safety safety cord hole operation...
Page 7 DMX CONTROL CONNECTION: ● Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 3 pin (which are included with the projector) or 3 pin XLR plugs and sockets.
Page 8 Lamp cover lamp fast fit screw Don’t touch the internal surface of the reflector and the burner of the lamp with bare hands so as not to impair the ● beam output. While lamp’s installation, do not damage the metal wire around the burner. Please read "Instructions "...
Page 9 ► key to enter into the fixture’s operation Switch on the Projector . Press OK key more than 3 seconds to unlock panel, then press menus. Select DMX Address icon and press OK key or touch the icon directly on the display and select DMX address at the 2 level menu for the address setting.
Page 10: Operation Menu
6. OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL 5th LEVEL 1-512 DMX Address Default IP Address 2.X.X.X /10.X.X.X IP Address Address Custom IP Address X.X.X.X SubNet Mask X.X.X.X ArtNet Universe 0-255 Total Reset Really Reset? Pan&Tilt Reset Really Reset? Colour System Reset Really Reset?
Page 11 View DMX Values Lamp Hours Reset Lamp Hours Total Hours Display Board XX℃/F Pan and Tilt XX℃/F Driver Board 1 XX℃/F Temperature Driver Board 2 XX℃/F Driver Board 3 XX℃/F Head Sensor XX℃/F System= XXX Display Board Boot =XXX Information System= XXX Pan and Tilt Boot =XXX...
Page 12: Dmx Protocol
7.DMX PROTOCOL Basic Standard Extended Decimal Decimal Function Description mode mode mode High Strobe Close(Lamp Switches to 1000 watt mode after shutter is closed for 5 seconds) Open Strobe speed from slow to fast Macro(Random strobe speed slow to fast) Open Dimmer Close...
Page 13 Colour Macro 26 Colour Macro 27 Colour Macro 28 Colour Macro 29 Colour Macro 30 LEE colour swatches LEE LEE 4 (Medium Bastard Amber) LEE 10 (Medium Yellow) LEE 19 (Fire) LEE 26 (Bright Red) LEE 58 (Lavender) LEE 68 (Sky Blue) LEE 71 (Tokyo Blue) LEE 79 (Just Blue) LEE 88 (Lime Green)
Page 14 LEE 154 (Pale Rose) LEE 157 (Pink) LEE 158 (Deep Orange) LEE 162 (Bastard Amber) LEE 164 (Flame Red) LEE 165 (Daylight Blue) LEE 169 (Lilac Tint) LEE 170 (Deep Lavender) LEE 172 (Lagoon Blue) LEE 179 (Chrome Orange) LEE 180 (Dark Lavender) LEE 181 (Congo Blue) LEE 197 (Alice Blue) LEE 201 (Full C.T.
Page 15 CTO in 16 Bit precision Colour Wheel 1 Continual positioning index 0-360° positioning White White/colour 1(Red) Colour 1(Red) Colour 1(Red)/colour 2(Yellow) Colour 2(Yellow) Colour 2(Yellow)/colour 3(Blue) Colour 3(Blue) Colour 3(Blue)/colour 4(Green) Colour 4(Green) Colour 4(Green)/colour 5(Pink) Colour 5(Pink) Colour 5（Pink））/colour 6（Orange） Colour 6(Orange) Colour 6(Orange)/ Colour 7(UV) Colour 7(UV)
Page 16 Colour 3(Light Magenta) Colour 3(Light Magenta)/colour 4(Light Yellow) Colour 4(Light Yellow) Colour 4(Light Yellow)/colour 5(Light Green) Colour 5(Light Green) Colour 5（Light Green））/colour 6（Deep Cyan） Colour 6(Deep Cyan) Colour 6(Deep Cyan)/ Colour 7(Light Cyan) Colour 7(Light Cyan) Colour 7 Light Cyan)/white Rainbow rotation speed from slow to fast Rainbow reverse rotation speed from slow to fast Colour Wheel 1 Fine...
Page 17 Framing blade 3 left fine adjustment Framing blade 3 right Framing blade 3 right linearly closing from big to small Framing blade 3right in 16 bit Framing blade 3right fine adjustment Framing blade 4 left Framing blade 4left linearly closing from big to small Framing blade 4left in 16 bit Framing blade 4 left fine adjustment Framing blade 4 right...
Page 18 Reserved 1.To activate following functions, stay in DMX value for at least 5 s 2.The lamp is allowed to be turned off 5 minutes after the lamp is on. And the lamp is allowed to be turned on 5 minutes after the lamp is off. 3.
Page 19: Error Messages
8. ICONS OF THE TROUCH SCREEN Option Settings Lamp Control Information Chinese/English Service Error Messages Operation Mode Address User Memories Reset Config Settings 9.ERROR MESSAGES The system can detect some errors during the reset, if displayed, touch to view the error. The error messages are as follows: Name Type...
Page 20 Lamp on Timeout Check if he lamp is damaged Lamp Life Timeout Warning Lamp Off[Fan Error] Error Check if all fans are normal Time IC Error 10. TECHNICAL DATA INPUT VOLTAGES Input voltage 200V~240V AC，50/60Hz Input power1700W @ 220V Current at maximum AC10.5A Power factor PF>90% LAMP SPECIFICATIONS...
Page 21 0-100% Linear CTO system 1 FRAMING MODULE 4 framing blades Continual framing module rotation, to make graphics of different sizes and shapes 4 framing blade to make full curtain effect FROST WHEEL 1Pc linear frost filter FOCUS DMX linear zoom ZOOM DMX linear zoom DIMMER...
Page 22 HOUSING High temperature ABS, IP20 WEIGHT 52Kg RIGGING Head up or Head down OPERATION TEMPERATURE Maximum ambient temperature: 40° C SIZES: LIGHT OUTPUT: 22/26...
Page 23: Circuit Diagram And Pcb Connections
11. CIRCUIT DIAGRAM AND PCB CONNECTIONS CIRCUIT DIAGRAM ● 23/26...
Page 24: Pcb Connection
PCB CONNECTION 8 channel motor driver board1: P/N 230060744 8 channel motor driver board M1-1motor 24V power input M1-2 motor Reserved M1-3 motor Reserved M1-4 motor Reserved M1-5 motor Reserved M1-6 motor HALL1-4 magnet sensor M1-7 motor HALL1-3 magnet sensor M1-8 motor HALL1-2 magnet sensor Thermal sensor...
Page 25: Component Order Codes
12. COMPONENT ORDER CODES NAME PART NO. REMARK 030040262 PAN MOTOR 030040262 TILT MOTOR 030040095A STORE MOTOR 030040186A DIMMER MOTOR 030040215A COLOR WHEEL1 MOTOR 030040215A COLOR WHEEL2 MOTOR 030040114A CMY MOTOR 030040213A FOCUS MOTOR 030040261 ZOOM MOTOR 030040029 FRAMING MODULE MOVE MOTOR 030040247 FRAMING BLADE MOTOR 030060104...
Page 26 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020630...
