XR 1400 Framing
PR-2737
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR 1400 Framing and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting XR 1400 Framing

Summary of Contents for PR Lighting XR 1400 Framing

  • Page 1 XR 1400 Framing PR-2737 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.
  • Page 2 INDEX SAFETY AND WARNINGS INSTRUCTIONS CLEANING AND MAINTENANCE ● LUBRICATION ● TROUBLESHOOTING ● 3. APPEARANCE 4. INSTALLATION RIGGING ● POWER CONNECTIONS ● DMX CONTROL CONNECTIONS ● DMX TERMINATOR ● ALIGNMENT/INSTALLATION/REPLACEMENT OF A LAMP ● GOBO/COLOR FILTER REPLACEMENT ● 5. SETUP AND CONFIGURATION FRONT PANEL OPERATION ●...

  • Page 3: Safety And Warnings

    Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty. 1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual.
  • Page 4 Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other ● electrical parts’ life will be shortened . There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ●...
  • Page 5  The project image appears to have a halo Carefully clean the lamp, optical lenses and other components.  Check if lens are in good condition(not cracked) Heavily Defective Beam  Clean dust or grease on the lens. 3. APPEARANCE HEAD BASE 4.
  • Page 6 E (earth) =yellow/green N (neutral) =blue Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each projector be connected with power separately so that they may be individually switched on and off. The earth wire(yellow/green) must be connected to the ground.
  • Page 7 electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120 (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain. The connections are illustrated below. DMX TERMINATOR CONNECTION Connect a 120...
  • Page 8 GOBO REPLACEMENT ● FRAMING MODULE ROTATING GOBO WHEEL 2 EFFECT WHEEL ROTATING GOBO WHEEL 1 COLOUR WHEEL Lock the tilt and loosen the 6 fast-fit screws on the upper cover ,After removing the cover, you will see the structures as the figure below.
  • Page 9 ◄,►,▲,▼ At the page to set the fixture’s functions, press or their respective icons to select the functions desired. keys ◄ ► key won’t work, and While at 2 and 4 level of menus, the key is for ESCAPE, but key is used for ENTER.

  • Page 10: Operation Menu

    SLAVE SLAVE MASTER DMX IN DMX IN DMX IN DMX OUT DMX OUT DMX TERMINATOR FIRMWARE UPGRADE VIA USB INTERFACE ● Copy the .PRS file for upgrading to U disk and plug it into USB interface. The upgrading file name or its file folder can be seen via the USB firmware upgrading interface under menu SERVICE.
  • Page 11 ArtNet Only ArtNet In/ XLR Out Normal time out Loss of DMX Hold Last Value Off After Delay Display Mode On Always Invert OFF Display Config Display Invert Invert ON Invert Auto English Language Setting Chinese Input Password 123 Touch Calibration Celsius Degree Temperature Unit Fahrenheit Degree...
  • Page 12 System= XXX Driver Board 4 Boot =XXX System= XXX Driver Board 5 Boot =XXX Electronic SN= Electronic SN ************ RDM Device Label RDM Device Label ANSI E1.20 RDM Version X.X Fan Status Strobe XXX Manual Effect Control Dimmer XXX Service …...
  • Page 13 CYM Macro The following functions can be used after CMY,CTO, Color Wheel1 and Color Wheel2 channels are disabled No Function Colour Macro 1 Colour Macro 2 Colour Macro 3 Colour Macro 4 Colour Macro 5 Colour Macro 6 Colour Macro 7 Colour Macro 8 Colour Macro 9 Colour Macro 10...
  • Page 14 LEE 90 (Dark Yellow Green) LEE 100 (Spring Yellow) LEE 101 (Yellow) LEE 102 (Light Amber) LEE 103 (Straw) Lee 104 (Deep Amber) LEE 105 (Orange) LEE 106 (Primary Red) LEE 111 (Dark Pink) LEE 115 (Peacock Blue) LEE 116 (Medium Blue-Green) LEE 117 (Steel Blue) LEE 118 (Light Blue) LEE 119 (Dark Blue)
  • Page 15 LEE 203 (Quarter C.T. Blue) LEE 204 (Full C.T. Orange) LEE 205 (Half C.T. Orange) LEE 206 (Quarter C.T. Orange) LEE 247 (LEE Minus Green) LEE 248 (Half Minus Green) LEE 281 (Three Quarter C.T. Blue) LEE 285 (Three Quarter C.T. Orange) LEE 352 (Glacier Blue) LEE 353 (Lighter Blue) LEE 715 (Cabana Blue)
  • Page 16 Colour 5(Pink) Colour 5（Pink））/colour 6（Orange） Colour 6(Orange) Colour 6(Orange)/ Colour 7(UV) Colour 7(UV) Colour 7(UV)/white Rainbow rotation speed from slow to fast Rainbow reverse rotation speed from slow to fast Colour Wheel 1 Fine Colour Continual positioning in 16 Bit precision Iris Linear Iris from small to big 0-100% Iris in 16 bit...
  • Page 17 Gobo2 shake from slow to fast Gobo3 shake from slow to fast Gobo4 shake from slow to fast Gobo5 shake from slow to fast Gobo6 shake from slow to fast Rotating gobo wheel 1 rotation Indexing 0-360° Stop Clockwise rotation from slow to fast Stop Anti-clockwise rotation from slow to fast Rotating gobo wheel 1 rotation in 16 bit...
  • Page 18 Framing blade 1 right in 16 bit Framing blade 1 right fine adjustment Framing blade 2 left Framing blade2 left linearly closing from big to small Framing blade 2 left in 16 bit Framing blade 2 left fine adjustment Framing blade 2 right Framing blade 2 right linearly closing from big to small Framing blade 2 right in 16 bit Framing blade 2 right fine adjustment...
  • Page 19 Prism2 Open position (hole) Prism Prism2 rotation Prism index Stop rotating Rotation speed from slow to fast Stop rotating Reverse rotation speed from slow to fast Dual Effect Wheel No effect wheel Proportional indexing Shake from open to full position with speed from slow to fast Shake from open to half position with speed from slow to fast Shake.
  • Page 20 Focus Fine Focus in 16 precision Zoom Linearly zooming Zoom Fine Zoom in 16 Bit precision Pan movement Pan Fine Pan movement in 16 bit precision Tilt Tilt movement Tilt fine Tilt movement 16 bit precision Pan/Tilt speed fast Speed Mode Pan &Tilt speed from fast to slow Power/Special functions No function:...

  • Page 21: Error Messages

    Reserved 1. The projector can’t be turned on within 1 minute after the lamp-off. 2. Fan error can cause lamp-off. 3. "Speed Mode" means Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode" means both Pan and Tilt will arrive at designated point at the same time.

  • Page 22: Technical Data

    Timeout Check if wiring, positioning parts and motors are normal Zoom Effect Wheel Timeout Check if wiring, positioning parts and motors are normal Effect Wheel Timeout Check if wiring, positioning parts and motors are normal Rotation Lamp Fan1 Error Check if fan and its wiring are normal Check if fan and its wiring are normal Lamp Fan2 Error...
  • Page 23 Code No. Colors Wave Length λ=620±5nm 090070041A λ=510/545±5nm 090070044A Yellow λ=500±5nm 090070043A Blue λ=540±5nm 090070042A Green λ=490/585±5nm 090070045A Pink λ=600±5nm 090070046A Orange λ=460/690±5nm 090070047A UV light 0-100% Linear CTO system GOBOS 2 Rotating gobo wheels, each 6 Interchangeable Gobos +Open, glass gobos or metal gobos Bi-directionally rotatable, scrolling and shakable at variable speeds, indexing Rotating gobo wheel1 (Gobo1-6) Rotating gobo wheel2 (Gobo1-6)
  • Page 24 FROST 2Pc frost filters(1 light frost filter and 1 heavy frost filter)linear adjustment and both can overlap EFFECT WHEEL Dual effect wheels, Each has independent and bi-directional rotation with variable speeds FOCUS DMX linear Focus DIMMER 0-100% Linearly adjustable IRIS 5-100%linear adjustment with macro STROBE Double blade strobe, 0.3-25 F.P.S .

  • Page 25: Circuit Diagram And Pcb Connections

    OPERATION TEMPERATURE Maximum ambient temperature: 40° C SIZES LIGHT OUTPUT 55°（lux） 2036 5°（lux） 5748 143700 35925 15967 8981 3992 55° 5° DISTANCE （m） 0m 5° DIAMETER （m） 0.46 0.92 1.38 1.84 2.30 2.76 55° DIAMETER （m） 0 4.90 9.79 14.69 19.59 24.49 29.38...

  • Page 27: Gobo Wheel2

    12. COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 230020689 PR-MP300 POWER SWITCH 193020008 POWER FILTER 20A 115/250VAC 190010150 THERMAL SWITCH 250V-16A 040070140 ELECTRONIC BALLAST ELECTRONIC BALLAST 040090066 IGNITER IGNITER 100070047 LAMP LOK-IT! HTI 1400/PS 290151205 PAN BELT 558-3M-11 290151207 TILT BELT 885-3M-12 PAN MOTOR...
  • Page 28 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020619...
