CENTURY SPOT
PR-2002
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
PR LIGHTING LTD.
Yingbin Road, Dashi Panyu, Guangzhou, 511430 China
h t t p : / / w w w . p r- l i g h t i n g . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CENTURY SPOT PR-2002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting CENTURY SPOT PR-2002

Summary of Contents for PR Lighting CENTURY SPOT PR-2002

  • Page 1 Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. Yingbin Road, Dashi Panyu, Guangzhou, 511430 China h t t p : / / w w w . p r- l i g h t i n g . c o m...

  • Page 2: Table Of Contents

    INDEX SECTION PAGE SAFE USAGE OF THE PROJECTOR STRUCTURE FITTING THE LAMP POWER SUPPLY – MAINS OPERATION STAND-ALONE MODE XLR CONNECTORS AND TERMINATOR MASTER/SLAVE MODE CONTROLLER MODE - DMX 512 OPERATION MAINTENANCE KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING TECHNICAL DATA ELECTRICAL DIAGRAM COMPONENT ORDER CODES Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice.

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR The following points are important for safety as well as for the smooth installation and performance of the unit. When unpacking and before disposing of the package check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus.

  • Page 4: Structure

    STRUCTURE FITTING THE LAMP Caution: For the safety reason, remove the sponge between the colour filters before the 1 application of luminaire. Position the projector-head facing the sky and lock it via locking knob. Remove the projector-head cover by loosening the 4 retaining clips. Open the dichroic-colour-filter bracket by undoing the 2 M6 knurled-screws.

  • Page 5: Operation

    OPERATION When the power is switched on, the apparatus automatically starts to run the programmes of self- test. After finishing these, the apparatus is ready for the following operation. Remove the cover of the control panel. You will see the panel as shown in the figure below. The right red LED flashes means there is a DMX signal receiving.

  • Page 6: Stand-Alone Mode

    CODE OPTION FUNCTION Auto-program enable Master/Slave mode enable Choose 1 of 7 built-in program Set time between scenes Reset enable STAND-ALONE MODE Without connecting the controller, when enable the function 1, the apparatus will run in stand- alone mode. In this mode, you can set the DMX start address to any value. XLR CONNECTORS AND TERMINATOR XLR CONNECTORS Connection between controller and projector and between one projector and another must be...

  • Page 7: Master/Slave Mode

    DMX TERMINATOR In the Controller mode or Master/Slave mode, the DMX output has to be connected with a DMX terminator at the last fixture in the chain. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain.

  • Page 8: Controller Mode - Dmx 512 Operation

    CONTROLLER MODE – DMX 512 OPERATION Century Spot adopts international standard DMX 512 protocol. You may control many luminaires via controller. When in controller mode, the function code 1 and 2 of all luminaires should be set to “ n” , and each apparatus should have specific address to receive the signal from the controller. Century Spot has 6 channels.

  • Page 9: Maintenance

    MAINTENANCE If the lamp becomes damaged or deformed in any way it must be replaced. If the light from the lamp appears dim this would normally indicate that it is reaching the end of its life and it should be changed at once, old lamps run to the extremity of their life may explode.

  • Page 10: Technical Data

    TECHNICAL DATA Power supply: 220/230V AC 50/60Hz Power consumption: 2800W Lamp: OSRAM HMI 2500W/SE, single end Colour temperature: 6000° K Manufacturers Rated Lamp life: 500 Hours Protocol: Standard DMX 512 Running mode: Stand-alone, Master/Slave, and DMX Controller DMX channels: 6 channels Colours: 3 basic colours, CYM 256 colours continuous mixing, white, blackout Beam coverage:...

  • Page 11: Electrical Diagram

    ELECTRICAL DIAGRAM 11/14 Century Spot manual_Last Revision_en.doc...

  • Page 12: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. REMARK TRANSFORMER 040010045 230V 50/60Hz IGNITOR 040090004 230V/50Hz BALLAST 040070033 230V/50Hz RELAY 192010009 230V/20A FILTER 193020001 THERMOSTAT 1 190010035 120 /1 ¡æ 5A THERMOSTAT 2 190010054 95 /10A ¡æ FAN (4 pcs) 030060019 230V/19W 030060042 220V 50/60Hz LAMP...

  • Page 13: Century Spot Manual_Last Revision_En.doc

    13/14 Century Spot manual_Last Revision_en.doc...
  • Page 14 PR LIGHTING LTD. No. 571, Yingbin Road, Dashi, Panyu, Guangzhou, China Post-Code: 511430 TEL: +86-20-8478 1888 FAX: +86-20-8478 6023 P/N: 320040047 Last Revision: 02:08:2004 14/14 Century Spot manual_Last Revision_en.doc...
