AQUA 350 BEAM
PR-2368A
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA 350 BEAM and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting AQUA 350 BEAM

Summary of Contents for PR Lighting AQUA 350 BEAM

  • Page 1 AQUA 350 BEAM PR-2368A This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
  • Page 2 Any future technical changes are not subject to further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.

  • Page 3: Safety And Warnings

    1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Warning User Electrical Protective Flames High Goggles Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.

  • Page 4: Cleaning And Maintenance

    There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ● cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ●...
  • Page 5 To ensure smooth movement of gobos and focus lens, it’s advised rotators’ bearings and 2 sliding bars for focus lens be lubricated every 2 months. High quality and high temperature lubricant/grease is advised.. TROUBLESHOOTING ● PROBLEM ACTION  Check the fuse on the power socket. The projector doesn’t switch on ...

  • Page 6: Installation

    4. INSTALLATION RIGGING ● safety cord clamp Please run the safety cord through safety cord hole for safety control panel handle Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to each clamp.
  • Page 7 DMX CONTROL CONNECTION ● Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.
  • Page 8 INSTALLATION/REPLACEMENT OF A LAMP ● Lock the yoke before fitting/replacing the lamp. Just as Shown by Figure 1, after Opening the airflow cover as shown by loosening 4 tightening screws, the structure like figure 2 will be seen. Just as shown by the figure 2, loosen the 4 tightening screws of the bob-weight block, take it down and the structure like figure 3 will be seen.

  • Page 9: Setup And Configuration

    5. SETUP AND CONFIGURATION Front Panel Operation ● Projector configuration can be set conveniently via push button and LCD display. Launch the projector and press button ENTER for more than 3 seconds to unlock the panel, the LCD will show the function menu of the projector, each main menu has its submenus and each submenu has a specific function.

  • Page 10: Operation Menu

    STAND-ALONE MODE ● Operate the projector without connecting with a controller, enable the master mode through the operation panel, the projector will run in Stand-Alone mode automatically. DMX address can be set at any number within 512. MASTER/SLAVE MODE ● Many projectors can run synchronously in the Master/Slave mode by linking them with each other.
  • Page 11 Short Mode Standard Mode DMX Channel Mode Extended Mode Ch.01 Strobe Ch.02 Dimmer View Selected Mode …. Ch XX Power/special Fun Lamp Control OFF/ ON Lamp Control On By Power On OFF/ ON Control By DMX OFF/ ON XLR Only XLR First Signal Select (Only for the projectors with...
  • Page 12 Pan DMX Invert OFF/ ON Tilt DMX Invert OFF/ ON Pan Tilt Swap OFF/ ON XY Feedback OFF/ ON Option Pan/Tilt Settings Note: "Speed Mode" means Settings Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode"...
  • Page 13 Electronic SN XXXXXX AQUA 350 BEAM RDM Device Label ANSI E1.20 RDM Speed Status Lamp Fan xxx on/off Fan Status Color Fan xxx on/off Head Fan xxx on/off X Axis: XXX Y Axis: XXX Acceleration Sensor Z Axis: XXX Position : XXX...
  • Page 14 Change Operation Mode? User Memory 1 Confirm or Cancel Change Operation Mode? User Memory 2 Confirm or Cancel Change Operation Mode? Static Scene Confirm or Cancel Strobe XXX Dimmer XXX Dimmer Fine XXX Colour Wheel XXX Colour Wheel Fine XXX Fixed Gobo Wheel XXX Rot.

  • Page 15: Dmx Protocol

    Remark: 1. In the synchronous control of multiple projectors parameters can be transmitted from the master including: DMX mode, display setting, operation mode(user memory); 2. all projectors Accepting parameters will automatically be set to slave mode. Specifications for the SIGN on the top right: 7.
  • Page 16 122-123 CTO/color12 124-125 Color12 126-127 Color12/white 128-191 Rotation ,Clockwise from slow to fast 192-255 Rotation ,Anti-Clockwise from fast to slow Color wheel Fine 0-255 Color Wheel in 16 Bit 000-008 White 009-015 Gobo1 016-022 Gobo2 023-029 Gobo3 030-036 Gobo4 037-043 Gobo5 044-050 Gobo6...
  • Page 17 008-017 Gobo 1 018-027 Gobo 2 028-037 Gobo 3 Rotating Gobo 038-047 Gobo 4 Wheel 048-057 Gobo 5 058-067 Gobo 6 068-077 Gobo 7 078-087 Gobo 8 088-097 Gobo 9 098-107 Gobo 10 108-117 Gobo 11 118-127 Gobo 12 Rotation （clockwise From slow to Fast） 128-143 Reverse Rotation（anti-clockwise From slow 144-159...
  • Page 18 000-127 Indexing Prism Stop Prism Rotation 129-191 Rotation(Clockwise from slow to fast) Stop 193-255 Rotation(Anti- Clockwise from slow to fast) Focus 000-255 Linear frost Focus Fine 000-255 Focus in 16 bit precision 000-255 Pan(0° ~540° ) Pan Fine 000-255 Pan in 16 bit precision Tilt 000-255 Tilt(0°...

  • Page 19: Error Information

    8. ERROR INFORMATION The system can detect some errors during the reset, if displayed, touch the logo to view the error. The error messages are as follows: Name Type Correction Timeout/magnet Sensor/Encoder Check if wiring, positioning parts and motors are normal Timeout/magnet Sensor/Encoder Check if wiring, positioning parts and motors are normal Tilt...
  • Page 20 9. TECHNICAL DATA ELECTRICAL PARAMETERS Input voltage: 100V-240V AC，50/60Hz Input power: 550W@220V Maximum current: 6.7A Power factor: PF >0.9 SPECIFICATIONS OF LIGHT SOURCE Lamp USHIO NSL-350A 6800K Colour Temperature Manufacturers Rated Lamp Life 1500hrs COLOR S 1 Color Wheel 12Dichroic colour filters +CTO+ white Variable speed and bi-directional rainbow effect Linear colour changing is available Color 3...
  • Page 21 GOBOS 1 Fixed gobo wheel 16 static gobos+ white + Open hole of rotating gobo wheel Shaking and bi-directional wheel scrolling at variable speeds Rotating Gobo Wheel 1Rotating gobo wheel: 12 gobos+ White Shaking and bi-directional wheel scrolling at variable speeds Gobo changeable.
  • Page 22 PRISM/EFFECT WHEEL 3Prisms(standard 8facet prism+16facet prism+ linear prism) (bi-directional rotation with variable speeds ) + Frost+ Open (Optional 3-16 facet prism or gradient prism) FOCUS 0-100% linearly adjustable by DMX STROBE Double shutter blades, 0.3~20 F.P.S HEAD MOVEMENT Pan 540º , Tilt 240º with auto position correction CONTROL International standard DMX512 signal , 3 pin and 5 pin interfaces 16channels in short mode, 20channels in standard mode,21channel in extended mode...

  • Page 23: Light Output

    LIGHT OUTPUT: CIRCUIT DIAGRAM...

  • Page 25: Component Order Codes

    11. COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 040070138 350W BALLAST USHIO NSL-350A 100070046A 192010223 350W POWER SWITCH 270031095 FUSE 290151438 TILT DRIVER BELT1 TILT DRIVER BELT2 290151439 PAN DRIVER BELT 290151456 EFFECT WHEEL BELT 290151420 8-FACET PRISM BELT 290151434 COLOR WHEEL BELT 290151419...
  • Page 26 Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020965...
