Summary of Contents for PR Lighting AQUA 480 BEAM
- Page 1 AQUA 480 BEAM PR-2469 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.
-
Page 2: Table Of Contents
/ or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty. -
Page 3: Safetyand Warnings
1. SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Goggles Warning Flames Manual shock Gloves Temperature ●... -
Page 4: Instructions
●All power cords must conform to related safety and regulations. ●If a projector is not water and dust proof, while being operated it should not be under rains or in humidity to avoid short circuit. ●Do not switch on and off a projector constantly in very short intervals, otherwise the light source’s and other electrical parts’life will be shortened . -
Page 5: Appearance
●Before any maintenance and cleaning, please ensure a project is off the power. ●Only a qualified person is allowed to do maintenance. ●To avoid sunlight or other light penetrating into the head via the front lens, resulting in high temperature internally causing damages to a projector. - Page 6 Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a projector with power while it is locked. Warning! For safety, please run the safety cord through its hole. Clamp Safety cord Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp.
- Page 7 Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.
- Page 8 Don’t touch the internal surface of the reflector and the burner of the lamp with bare hands so as not to impair the ● beam output. There is a protruding metal wire in the lamp, while installation do not damage it. Hold the lamp body well before its removal.
-
Page 9: Setupand Configuration
DANGER! Before replacement of gobos, the projector must be off the power completely. 5. SETUPAND CONFIGURATION FRONT PANELOPERATION ● To browse through or change the projector ’s settings, press ENTER key for more than 3s(press ENTER key after power on) to UP/DOWN key to enter the projector ’s function menus. -
Page 10: Operation Menu
UP or DOWN key to enter into the operation 1. Press ENTER for more than 3s to unlock the control panel, then press menu and select “Config Settings”. 2. Select “Wireless Only” from the menu of “Signal Select”. Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it, Press “Enter”... - Page 11 Really Reset? Pan&Tilt Reset Confirm or Cancel Really Reset? Colour System Reset Confirm or Cancel Really Reset? Gobo Reset Confirm or Cancel Really Reset? Dimmer/Shutter reset Confirm or Cancel Really Reset? Fo. Pr. Fr.Reset Confirm or Cancel Short Mode Standard Mode DMX Channel Mode Extended Mode View Selected Mode...
- Page 12 InvertAuto English\Chinese Language Setting Celsius Degree Temperature Unit Fahrenheit Degree Un-Link Wireless (Only for fixtures with wireless Really Un-Link? control) Confirm or Cancel Restore Defaults? Factory Defaults Confirm or Cancel Pan DMX Invert OFF/ ON Option Settings Tilt DMX Invert OFF/ ON Pan Tilt Swap OFF/ ON...
- Page 13 Tilt Tilt Fine Pan & Tilt Speed XXX Control Function XXX XXX H Lamp Hours Reset Lamp Hours Total Hours ×××× Display Board= ×××C Pan board ×××C Tiltboard ×××C Temperature DriverBoard1 ×××C DriverBoard 2 ×××C Head Sensor= ×××C Display Board xxx xxx xxx xxx Pan board Software Version...
- Page 14 Prism 2 Prism 2 Rotation XXX Focus Focus Fine Pan Fine Tilt Tilt Fine Pan & Tilt Speed XXX Factory Mode Change Operation Mode? DMX Mode Confirm or Cancel Change Operation Mode? Preset Memory Confirm or Cancel Change Operation Mode? Master Mode User Memory 1 Confirm or Cancel...
-
Page 15: Dmx Protocol
Strobe Dimmer Dimmer Fine CMY Macro Cyan Cyan Fine Yellow Yellow Fine Magenta Magenta Fine CTO Fine Color Wheel Color Wheel Fine XXX Fixed Gobo Wheel XXX Edit Static Scene Rot. Gobo Wheel XXX Rot. Gobo Rotation XXX Rot.GoboRotationFine XXX Prism 1 Prism 1 Rotation XXX Prism 2... - Page 16 Yellow 036-054 Yellow +Cyan=Green 055-073 Cyan 074-092 Cyan + Magenta= Violet 093-111 Magenta 112-128 CYM color mixing from slow to fast 129-255 Cyan Cyan (linear 0~100%) 000-255 Cyan Fine 000-255 Cyan in 16 Bit Yellow 000-255 Yellow (linear 0~100%) Yellow Fine 000-255 Yellow in 16 Bit Magenta...
- Page 17 079-085 Gobo11 086-092 Gobo12 093-099 Gobo13 100-106 Gobo14 Gobo15 107-113 114-120 Gobo16 121-124 Gobo17 125-127 Gobo18 128-157 Clockwise rotation from slow to fast 158-187 Anti Clockwise rotation from slow to fast Shake effect 1 from slow to fast 188-191 192-195 Shake effect 2 from slow to fast 196-199 Shake effect 3 from slow to fast...
- Page 18 246-255 Shake of Gobo 7 from slow to fast 000-128 Gobo Indexing(0~360degrees) 129-188 Rotation （Clockwise From slow to Fast） Gobo Rotation 189-195 Stop 196-255 Rotation （Anti-ClockwiseFromslowtoFast） Gobo Rotation Gobo Rotation in 16 Bit 000-255 Fine 000-016 Open Prism 1 017-127 Prism1 128-255 Prism2...
-
Page 19: Signs On The Touchscreen
150-159 Color System Reset 160-169 Gobo Wheel Reset Dimmer/Shutter Reset 170-179 Focus/Prism Reset 180-189 Reserved 190-199 200-209 Total Reset 210-229 Reserved 230-239 Lamp Off 240-255 Reserved Remarks: The projector can’t be turned on within 1 minute after the lamp-off. Fan error can cause lamp-off. Note: "Speed Mode"... -
Page 20: Error Message
9. ERROR MESSAGES The system can detect some errors during the reset, if displayed, touch to view the error. The error messages are as follows: Name Type Correction Timeout/magnet Sensor/Encoder Check if wiring, positioning parts and motors are normal Timeout/magnet Sensor/Encoder Check if wiring, positioning parts and motors are normal Tilt Timeout... -
Page 21: Technicaldata
10. TECHNICALDATA ELECTRIC PARAMETERS Input voltages 100V~240VAC，50/60Hz Input Power 650W @ 220V Current at Maximum 8A Power factor: PF〉0.9 LAMP SPECIFICATIONS Lamp PR480L 6900K Color Temperature Manufacturers Rated Lamp Life 1500hours COLORS CMY color mixing system with macros 1 Color wheel: 12colors+ Open, rainbow effect with bi-directional and variable speeds, Stepping/linear color changing Color 9... -
Page 22: Fixed Gobo Wheel
092550010A 092550011A Light Yellow 090071258 INDEPENDENT CTO SYSTEM 0-100% linear CTO FIXED GOBO WHEEL 1 Fixed gobo wheel: 18 gobos +Open Bi-directionally rotatable, and shakable at variable speeds Gobo1 Gobo2 Gobo3 Gobo4 Gobo5 Gobo6 Gobo7 Gobo8 Gobo9 Gobo10 Gobo11 Gobo12 Gobo13 Gobo14 Gobo15... - Page 23 FOCUS DMX linear Focus DIMMER/STROBE 0-100% Linearly adjustable/ Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction BEAMANGLE Beam angle 2° CONTROL DMX512, 5-pin interfaces(Optional 3-pin) 22channels in short mode, 26channels in standard mode , 30channels in extended mode Self-test mode OTHER FUNCTIONS Adjustable Pan &...
-
Page 24: Circuit Diagram And Pcbconnections
LIGHT OUTPUT （m） （m） 10. CIRCUIT DIAGRAMAND PCB CONNECTIONS . CIRCUIT DIAGRAM... - Page 25 PCB CONNECTIONS ●...
- Page 26 8-Channel SLAVE1 ：P/N230060735 8 Channel Driver Board 1 M1-1 Motor 24VInput M1-2Motor Reserved M1-3Motor Reserved M1-4Motor HALL1-6Magnet Sensor M1-5Motor HALL1-5 Magnet Sensor M1-6Motor HALL1-4 Magnet Sensor M1-7Motor HALL1-3 Magnet Sensor M1-8Motor HALL1-2 Magnet Sensor MEMS Sensor Board HALL1-1 Magnet Sensor LampFan1 Signal output LampFan2...
-
Page 27: Component Order Codes
12. COMPONENT ORDER CODES NAME PART NO. QTY. REMARKS STEPPER MOTOR 030040279 STEPPER MOTOR 030040284 STEPPER MOTOR 030040121A STEPPER MOTOR 030040221C STEPPER MOTOR 030040224C STEPPER MOTOR 030040246B STEPPER MOTOR 030040254A SCREWMANDREL MOTOR(WITH NUT) 030040243A STEPPER MOTOR 030040277 STEPPER MOTOR 030040278 BLOWER 030060094A PWN SPEED ADJUSTABLE FAN... - Page 28 1582 XingyeAvenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. CounterfeitingWill be Prosecuted! P/N: 320021297...
